SIGNAL WIRING AND PRO-BUS INSTALLATION INSTRUCTIONS
NOTE: Refer to "Illustration 1, NET-164 Typical Playback System Diagram," in the "Overview of NET-164 Wiring
Connections" section of this quick guide and the illustrations on this page.
Start
Connect the following to your NET-164:
●
Input (source) equipment video cables (A)
●
Input (source) equipment audio cables (B)
●
Output (destination) equipment video cable(s) (C)
●
Output (destination) equipment audio cable(s) (D)
Will NET-164 be used for
device control?
If using, connect Tascam DV-D6500
DVD player cables (E) to your NET-164.
Connect one end of a RJ-11 cable to
Event Controller's PRO-BUS output (F)
and the other cable end into the input of
a PRO-BUS interface.
Using attached device cable, connect
PRO-BUS interface to VCR/DVD player.
Is there another VCR/
DVD player connected to
NET-164?
Set the DIP switches on each PRO-BUS
(see instructions included with PRO-BUS).
DIP Switches
Page 4 of 7
Connect power supply
No
(G) to NET-164 and
plug Event Controller
Yes
Connect an RJ-11
cable from the
Yes
output of the first
PRO-BUS to input of
another PRO-BUS.
No
Connect power supply
(G) to NET-164 and
plug Event Controller
A
B
Ethernet network access (H).
See the "Ethernet Network
Configuration Instructions"
into AC outlet.
section of this quick guide.
Ethernet network access (H).
into AC outlet.
Rear View of NET-164
D
Configure NET-164 for
PRO-BUS Interface Connections
Configure NET-164 for
See the "Ethernet Network
Configuration Instructions"
section of this quick guide.
C
E
F
H
G
End
NET-164
Input
(Source)
Equipment
PRO-BUS
Interfaces
End
2007-09-10
