NEC MultiSync 2A Service Manual page 20

DATA FO R MAT FOR USING Quantum 801C
TIMING PARAMETERS:
Rear Time Parameters
Dot Rate
Horizontal Rate
Vertical Rate
Non-Real Time Parameters
Horizontal
Dots/Character
Total
Characters
Drive Delay
Drive Width
O PTION PARAMETERS
Signal Gating
Composit Sync.
Vertical Step
Horizontal Drive
Vertical Drive
Signal Polarity
Composite Sync.
Vertical Step
Horizontal Drive
Vertical Drive
Video
Interlace Mode
Video Mode
Duty Cycle
Character Clocking Mode
Horizontal Skew
Vertical Skew
Cursor
Signal No.
MHz
KHz
Hz
Vertical
Lines/Character
Total
Rows
Drive Delay
Drive Width
Step Width
OP 1.-0=off 1=on
OP 2.-0=off 1=on
1=on
OP 3 -0=off
OP 4.-0=off 1=on
OP 5.-0=non-inverted 1=inverted
OP 6.-0=non-inverted 1=inverted
OP 7.-0=non-inverted 1 =inverted
OP 8.-0=non-inverted 1=inverted
OP 13.-0=non-inverted/positive
1 =inverted/positive
2=non-inverted/negative
3=inverted/negative
OP 9.-0=non-interlace
1=interlaced sync only
3=interlaced sync & video
OP 10.-0=monochrome 1=color
OP 11.-0=50% 1 =100% (OP 12.0)
0 or 1=100% (OP 12.2)
OP 12.-0=single-phase
2=dual-phase
OP 14.-skew right 0-3 dots
OP 15.-skew down 0-9 lines
OP 16.-0=off
1=fast blink
2=slow blink
3=on continuous
-18 -
Description
V
1. H: 31.47KHz 70Hz (350 Lines)
2. V
H: 31.47KHz 70Hz (400 Lines)
V
3. H: 31.47KHz 60Hz (480 Lines)
V
4. H: 35 OOKHz 67Hz
V:
5. H: 35.16KHz 56Hz
