Chapter 1
1. 2. 1.
You can check the extender's working status by following the LED Explanation table.
2.4GHz/5GHz
1. 2. 2.
Ports or Buttons
WPS Button
Power Button
LED Button
Reset (Hole)
Ethernet Port
Downloaded from ManualsNet.com

LED Explanation

Name Status
Solid blue
Solid red
(Signal)
Flashing
Off
On
Off
On
POWER Flashing
Off

Port and Button Description

Press the WPS button on your host router, and immediately press the
button on the extender. The Signal LED
solid blue, indicating successful WPS connection.
Press the Power button to turn on or off the extender.
Press the LED button to turn on or off all the LEDs.
Use a pin to press and hold the Reset button until all the LEDs turn on
momentarily to reset the extender.
Connect your Ethernet-only device to the Ethernet port of the extender to join
the Wi-Fi network.
search engine
Get to Know About Your Extender
Indication
The extender is connected to your router's wireless network
and is in a suitable location.
The extender is experiencing poor signal strength. Try
relocating it closer to your router.
WPS connection is being established.
No wireless connection is established.
The extender is connected to the 2.4GHz/5GHz wireless
network of your host router.
No wireless connection has been established.
The extender is on.
The extender is starting up or firmware is being upgraded.
The extender is off.
Description
of the extender should change to
