Summary of Contents for Clevo PB70DDS

  • Page 1 PB70DDS / PB70DF1 / PB70DF2 / PB71DDS / PB71DF1 / PB71DF2...
  • Page 3 Preface Notebook Computer PB70DDS / PB70DF1 / PB70DF2 / PB71DDS / PB71DF1 / PB71DF2 Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the PB70DDS / PB70DF1 / PB70DF2 / PB71DDS / PB71DF1 / PB71DF2 series notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
  • Page 7 Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.
  • Page 9 Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
  • Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 130°...

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 HDD ....................A-6 LCD ....................A-7 Overview ..................1-1 Schematic Diagrams......... B-1 Specifications ..................1-2 External Locator - Top View with LCD Panel Open ......1-4 System Block Diagram ..............B-2 External Locator - Front & Right Side Views .........1-5 Processor 1/6 ...................B-3 External Locator - Left Side &...
  • Page 12 Preface Misc, GPIO, I2C & ROM ............B-29 VDD3, VDD5 ................B-61 GPU VDD ..................B-30 PWR 2.5V, VDDQ, VTT .............B-62 GPU GND ..................B-31 1.8VA, 1.05VA ................B-63 GPU Decoupling ................B-32 VCCIO ..................B-64 GPU CTRL, Level Shift ............... B-33 VCore ....................B-65 PCH A ..................

  • Page 13: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the PB70DDS / PB70DF1 / PB70DF2 / PB71DDS / PB71DF1 / PB71DF2 series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about dri-vers (e.g. VGA & audio) is also found in the User’s Manual.

  • Page 14: Specifications

    Two 260 Pin SO-DIMM Sockets Microsoft DirectX®12 Compatible mented in order to protect the battery. Supporting up to 3200MHz DDR4 Memory NVIDIA® GeForce RTX 2060 (PB70DDS / PB71DDS) Memory Expandable from 8GB (minimum) up to 64GB 8GB GDDR6 Video RAM (maximum) Microsoft DirectX®12 Compatible...
  • Page 15 Introduction Storage M.2 Slots Environmental Spec One changeable 2.5" (6cm) 7.0mm (h) SATA (Serial) Hard Slot 1 for Combo WLAN and Bluetooth Module Temperature Disk Drive/Solid State Drive (SSD) ° ° Slot 2 for SATA or PCIe Gen3 x4 SSD Operating: 5 C - 35 (Factory Option) One M.2 2280 SATA Solid State Drive...

  • Page 16: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. PC Camera 2. *PC Camera LED *When the PC camera is in use, the LED will be illuminated. 3. Built-In Array Microphone 4. LCD 5. Power Button 6.

  • Page 17: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Indicator 2. Multi-in-1 Card Reader FRONT VIEW Figure 3 Right Side View 1. USB 3.2 Gen 2 Type-C Port (Factory Option) RIGHT SIDE VIEW Thunderbolt 3 Port 2.

  • Page 18: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. Security Lock Slot 2. Vent 3. *Powered USB LEFT SIDE VIEW 3.2 Gen 1 Type-A Port 4. 2-In-1 Audio Jack (Microphone and S/PDIF Optical) 5. 2-In-1 Audio Jack (Headphone and Microphone) 6.

  • Page 19: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Vent 2. Battery 3. Speakers 4. Subwoofer 5. Multi-in-1 Card Reader  Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use.

  • Page 20: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. KBC-ITE IT5570 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 21: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. PCH 2. GPU 3. CPU 4. Memory Slots DDR4 SO-DIMM 5. Mini-Card Connector (M.2 PCIE/SATA SSD Module) 6. Mini-Card Connector (M.2 PCIE Module) 7. Mini-Card Connector (WLAN Module) Mainboard Overview - Bottom (Key Parts) 1 - 9...

  • Page 22: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. Per Key Cable Connector 2. Keyboard Cable Connector 3. RGB Keyboard Cable Connector 4. Power Switch Connector 5. Multi-in-1 Card Reader 6. USB 3.2 Gen 2 Type-C Port (Factory Option) Thunderbolt 3 Port...

  • Page 23: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. RJ-45 LAN Jack 2. HDMI-Out Port 3. Mini DisplayPort 4. DisplayPort 1.3 over USB 3.2 Gen 2 Type-C Port 5. USB 3.2 Gen 1 Type-A Port 6. DC-In Jack 7.
  • Page 24 Introduction 1 - 12...

  • Page 25: Disassembly

    Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the PB70DDS / PB70DF1 / PB70DF2 / PB71DDS / PB71DF1 / PB71DF2 series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (un- less otherwise indicated).

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other components Warning could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Wireless LAN Module: 1. Remove the battery page 2 - 5 1.

  • Page 29: Removing The Battery

    Disassembly Removing the Battery Figure 1 Battery Removal 1. Turn off the computer, turn it over. 2. Remove screws (Figure 1a). a. Remove the screws. 3. Carefully lift the battery up in the direction of the arrow at point (Figure 1b b.

  • Page 30: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 2 Keyboard-1 Keyboard-1 Removal Procedure Removal 1. Turn off the computer, turn it over. a. Remove the screws from 2. Remove screws from the bottom of the computer. the bottom of the compu- 3. Open it up with the LCD on a flat surface before pressing at point to release the keyboard module (use the spe- ter and then eject the cial eject stick...
  • Page 31 Disassembly Keyboard-2 Removal Procedure Figure 3 1. Turn off the computer, turn it over. Keyboard-2 2. Remove screws from the bottom of the computer. Removal 3. Open it up with the LCD on a flat surface before pressing at point to release the keyboard module (use the spe- a.
  • Page 32 Disassembly Removing the Hard Disk Drive Figure 4 HDD Assembly The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 7mm Removal (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk.

  • Page 33: Removing The Hard Disk Drive

    Disassembly 5. The HDD will be visible at point on the mainboard (Figure 5d Figure 5 6. Remove screws from the HDD assembly and disconnect the ribbon cable from the locking collar HDD Assembly socket by using a flat-head screwdriver to pry the locking collar pins away from the base (Figure 5e).

  • Page 34: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 6 RAM Module The computer has four memory sockets for 260 pin Small Outline Dual In-line Memory Modules (SO-DIMM) support- Removal ing DDR4 Up to 3200 MHz. The main memory can be expanded up to 64GB. The total memory size is automatically detected by the POST routine once you turn on your computer.

  • Page 35: Removing The M.2 Ssd Module

    Disassembly Removing the M.2 SSD Module Figure 7 M.2 SSD-1 Module M.2 SSD-1 Removal Procedure Removal 1. Turn off the computer, remove the battery (page 2 - 5), keyboard (page 2 - 6) and bottom case (page 2 - 2. The M.2 SSD module will be visible at point on the mainboard (Figure 7a).

  • Page 36: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 8 Wireless LAN 1. Turn off the computer, remove the battery (page 2 - 5), keyboard (page 2 - 6) and bottom case (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard (Figure 8a).

  • Page 37: Wireless Lan, Combo Module Cables

    Disassembly Wireless LAN, Combo Module Cables Note that the cables for connecting to the antennae on WLAN, WLAN & Bluetooth Combo modules are not labelled. The cables/covers (each cable will have either a black or transparent cable cover) are color coded for identification as outlined in the table below.
  • Page 38 Disassembly 2 - 14...

  • Page 39: Part Lists

    Appendix A:Part Lists This appendix breaks down the PB70DDS / PB70DF1 / PB70DF2 / PB71DDS / PB71DF1 / PB71DF2 series note- book’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings.

  • Page 40: Part List Illustration Location

    Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A - 1 Part List Illustration Part Location page A - 3 Bottom page A - 4 page A - 5 Main Board page A - 6 page A - 7 A - 2...

  • Page 41: Top

    Figure A - 1 Top A - 3...

  • Page 42: Bottom

    Bottom Figure A - 2 Bottom A - 4 Bottom...

  • Page 43: Main Board

    Main Board Figure A - 3 Main Board Main Board A - 5...

  • Page 44: Hdd

    Figure A - 4 A - 6 HDD...

  • Page 45: Lcd

    Figure A - 5 LCD A - 7...
  • Page 46 A - 8...

  • Page 47: Schematic Diagrams

    Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the PB70DDS / PB70DF1 / PB70DF2 / PB71DDS / PB71DF1 / PB71DF2 note- book’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Diagram - Page...

  • Page 48: System Block Diagram

    Schematic Diagrams System Block Diagram 3.3VA, 5V, 3.3V, 5VS, 3VS PWR SW SHEET 59 PB50DF2 Comet Lake System Block Diagram SY6288E1AAC VCCSFR_OC, VCCST, VCCSFR, VCCSTG SHEET 65 NV3V3 CONN VDD3, VDD5 TYPE-C 3"~8" SHEET 60 DP REPEATER PEG x16 SHEET 52 PS8330B Comet Lake-H 1.2V(VDDQ), 0.6VS(VTT), 2.5V(VPP)

  • Page 49: Processor 1/6

    Schematic Diagrams Processor 1/6 Zo=50ohm, L<4.4" Zo=50ohm, L<4.4" M_A_DQ[63:0] M_B_DQ[63:0] U41A DIFF=88ohm, L<4.4" U41B DIFF=88ohm, L<4.4" M_A_DQ0 M_B_DQ0 BT11 M_A_CLK_DDR0 M_B_CLK_DDR0 M_A_DQ1 DDR0_DQ_0/DDR0_DQ_0 DDR0_CKP_0/DDR0_CKP_0 M_B_DQ1 DDR1_DQ_0/DDR0_DQ_16 DDR1_CKP_0/DDR1_CKP_0 BR11 DDR0_DQ_1/DDR0_DQ_1 DDR0_CKN_0/DDR0_CKN_0 M_A_CLK_DDR#0 DDR1_DQ_1/DDR0_DQ_17 DDR1_CKN_0/DDR1_CKN_0 M_B_CLK_DDR#0 M_A_DQ2 M_B_DQ2 DDR0_DQ_2/DDR0_DQ_2 DDR0_CKP_1/DDR0_CKP_1 M_A_CLK_DDR1 DDR1_DQ_2/DDR0_DQ_18 DDR1_CKP_1/DDR1_CKP_1 M_B_CLK_DDR1 M_A_DQ3...
  • Page 50 Schematic Diagrams Processor 2/6 From NV To NV DIFF=85ohm, L=3"~8" U41C DIFF=85ohm, L=3"~8" U41D PEG_TX_0 C1289 0.22u_10V_X5R_04 To PS8331 MUX SW [14] PEG_RX15 PEG_RXP_0 PEG_TXP_0 PEG_TX15 [14] PEG_TX#_0 C1290 0.22u_10V_X5R_04 DIFF=85ohm, L <=2~4" [14] PEG_RX#15 PEG_TX#15 [14] PEG_RXN_0 PEG_TXN_0 IEDP_TX_0 [11] PEG_TX_1 DDI1_TXP_0...

  • Page 51: Processor 3/6

    Schematic Diagrams Processor 3/6 High DESCRIPTION U41E Stall reset sequence after PCU No Stall Stall PLL lock until de-asserted DIFF=85ohm, L=4"~9" BN25 CFG0 [38] PCH_CPU_BCLK_R_DP BCLKP CFG_0 BN27 [38] PCH_CPU_BCLK_R_DN BCLKN CFG_1 NORM Reversed PEG Static x16 Lane Numbering Reversal BN26 CFG2 R126...
  • Page 52 Schematic Diagrams Processor 4/6 U41F U41G U41H BJ15 VSS_1 VSS_82 VSS_163 VSS_244 VSS_325 VSS_409 AL10 AY12 BJ18 VSS_2 VSS_83 VSS_164 VSS_245 VSS_326 VSS_410 AL12 AY33 BJ22 BP12 VSS_3 VSS_84 VSS_165 VSS_246 VSS_327 VSS_411 AL14 AY34 BJ25 BP14 VSS_4 VSS_85 VSS_166 VSS_247 VSS_328 VSS_412...

  • Page 53: Processor 5/6

    Schematic Diagrams Processor 5/6 20180509 VCORE VCORE follow PA70 VCORE VCORE U41I U41J AA13 AH13 VCC1 VCC64 22u_6.3V_X6S_08 2 *3 AA31 AH14 VCC2 VCC65 VCC1 VCC64 AA32 AH29 VCORE VCC3 VCC66 VCC2 VCC65 10u_4V_X6S_06 9 *1 AA33 AH30 VCC4 VCC67 VCC3 VCC66 AA34...
  • Page 54 Schematic Diagrams Processor 6/6 VCCGT VCCGT VCCSA VDDQ U41K U41L U41M 11.1A AT14 BD35 VCCGT1 VCCGT80 AT31 BD36 CPU Domain CPU Voltage CPU ICCMAX VR output Board Edge cap Backside cap VCCGT2 VCCGT81 VCCSA1 VDDQ1 SRVD_TP5 AT32 BE31 AE12 VCCGT3 VCCGT82 VCCSA2 VDDQ2...

  • Page 55: Ddr4 Cha So-Dimm_0

    Schematic Diagrams DDR4 CHA SO-DIMM_0 Channel A SO-DIMM_0 STD TYPE H=8mm VDDQ VTT_MEM J_DIMMA_1A J_DIMMA_1B M_A_DQ[63:0] M_A_DQ5 Zdiff=88ohm M_A_CLK_DDR0 CK0_T M_A_DQ0 VDD19 VDDQ Zo=50ohm 2.5V PLACE NEAR TO DIMM L<4.4" M_A_CLK_DDR#0 CK0_C VDD18 M_A_DQ2 L<4.4" M_A_CLK_DDR1 CK1_T VDD17 M_A_DQ3 M_A_CLK_DDR#1 CK1_C VDD16 VPP2...

  • Page 56: Ddr4 Chb So-Dimm_0

    Schematic Diagrams DDR4 CHB SO-DIMM_0 STD TYPE Channel B SO-DIMM_0 H=4mm J_DIMMB_2A J_DIMMB_2B VTT_MEM VDDQ M_B_DQ[63:0] M_B_DQ0 Zdiff=88ohm M_B_CLK_DDR0 CK0_T VDD19 VDDQ M_B_DQ5 2.5V L<4.4" Zo=50ohm PLACE NEAR TO DIMM M_B_CLK_DDR#0 CK0_C VDD18 M_B_DQ7 L<4.4" M_B_CLK_DDR1 CK1_T M_B_DQ3 VDD17 M_B_CLK_DDR#1 CK1_C VDD16 VPP2...

  • Page 57: Edp, Panel Pwr

    Schematic Diagrams eDP, Panel PWR PANEL CONNECTOR PANEL VLED POWER PLVDD >3A 20191205 Follow common PLVDD Del C1258 I2CB_SDA_DDS R594 2.2K_04 C1260 W / DDS DEFAULT SHORT VLED I2CB_SCL_DDS R573 2.2K_04 1u_6.3V_X5R_02 >3A W / DDS FRAME_LOCK#_R R529 10K_04 OPTION_W / NVSR C1495 C124 I2CB_SCL_DDS...

  • Page 58: Ps8331

    Schematic Diagrams PS8331 PS8331B 5*9mm Frome Intel CAP NEAR PS8331B DIFF=85ohm, L=2"~4" IEDP_TXP_0_R C211 0.1u_10V_X7R_04 FROM PCH (GPP_F9) 3.3VS IEDP_TX_0 IN1_D0P VDD3 IEDP_TXN_0_R PS8331_IN1_AEQ# C223 0.1u_10V_X7R_04 HIGH=PS8331B PORT2 (dGPU) IEDP_TX#_0 IN1_D0N IN1_AEQ# PS8331_IN2_AEQ# LOW=PS8331B PORT1 (iGPU) (DEFAULT) [37] SB_IEDP_HPD IN1_HPD IN2_AEQ# IEDP_TXP_1_R C232...

  • Page 59: Hdmi Port

    Schematic Diagrams HDMI Port HDMI CONNECTOR HDMI_5VS HDMI_5VS 100mA VOUT RB751S-40H 22u_6.3V_X5R_06 *22u_6.3V_X5R_06 *10u_6.3V_X5R_06 APL3517A J_HDMI1 PCB Footprint = m-sot23-123 R478 R477 2K_04 2K_04 HDMI_SCL-C HDMI_SCL-J HDMI_HPD-J HDMI_SDA-C HDMI_SDA-J HOT PLUG DETECT HDMI_5VS TMDS_DATA0 TMDS_DATA0J HDMI_HPD-C HDMI_HPD-J DDC/CEC GND TMDS_DATA0# TMDS_DATA0#J HDMI_SDA-J Sheet 12 of 85...

  • Page 60: Mini Dp Port

    Schematic Diagrams Mini DP Port mini-Display Port E (BACK) CLOSE TO CONNECTOR D_MDP_E3 D_MDP_E3_L From NV Port_E D_MDP_E#3 D_MDP_E#3_L D_MDP_E#2_L D_MDP_E#2J DIFF=90ohm, L<4" D_MDP_E#3 D_MDP_E2_L D_MDP_E2J C1211 0.1u_10V_X7R_04 *DVI2012F2SF-900T05_08-SHORT [27] MDP_E#3 D_MDP_E3 C1212 0.1u_10V_X7R_04 [27] MDP_E3 D_MDP_E#2 D_MDP_E#2_L D_MDP_E#3_L D_MDP_E#3J D_MDP_E#2 D_MDP_E3_L D_MDP_E3J...

  • Page 61: Gpu A Pcie

    Schematic Diagrams GPU A PCIE Place Under GPU Place between NV PCI EXPRESS 1/22 PCI_EXPRESS PEX_VDD GPU and PS BK44 PEX_WAKE 3.3V NV3V3 NV3V3 BB35 PEX_DVDD GPU_PEX_RST# BK26 BB36 PEX_RST PEX_DVDD [32] GPU_PEX_RST# BC35 C392 C393 C394 C445 C471 C499 C500 C768 C421...

  • Page 62: Gpu Frame Buffer Partition A/B

    Schematic Diagrams GPU Frame Buffer Partition A/B GPU FRAME BUFFER PARTITION A/B GDDR6 Mode 1 Mapping GB4B-256 ch0 Bytes0,1 ch0 Bytes2,3 2/22 FBA 3/22 FBB CMD0 CA0_A FBA_D0 FBA_CMD0 FBB_D0 FBB_CMD0 CMD1 CA9_A CA9_B FBA_D0 FBA_CMD0 FBB_D0 FBB_CMD0 FBA_D1 FBA_CMD1 FBB_D1 FBB_CMD1 FBA_D1...

  • Page 63: Frame Buffer Partition A

    Schematic Diagrams Frame Buffer Partition A FRAME BUFFER PARTITION A 31..0 VRAM=K4Z80325BC-HC14 FBVDDQ NORMAL NORMAL FBA_D4 DQ0_A FBA_D7 FBA_D30 DQ0_B DQ1_A FBA_D1 FBA_D29 DQ1_B DQ2_A FBA_D5 FBA_D28 DQ3_A DQ2_B FBA_D3 FBA_D31 DQ3_B DQ4_A FBA_D6 FBA_D25 DQ4_B DQ5_A FBA_D2 FBA_D27 FBA_CMD0 DQ5_B CA0_A VREFC...
  • Page 64 Schematic Diagrams Frame Buffer Partition A FRAME BUFFER PARTITION A 63..32 VRAM=K4Z80325BC-HC14 FBVDDQ NORMAL NORMAL FBA_D39 DQ0_A FBA_D35 FBA_D57 DQ0_B DQ1_A FBA_D32 FBA_D56 DQ1_B DQ2_A FBA_D38 FBA_D59 DQ3_A DQ2_B FBA_D34 FBA_D58 DQ3_B DQ4_A FBA_D33 FBA_D61 DQ4_B DQ5_A FBA_D37 FBA_D60 FBA_CMD20 DQ5_B CA0_A VREFC...

  • Page 65: Frame Buffer Partition B

    Schematic Diagrams Frame Buffer Partition B FRAME BUFFER PARTITION B 31..0 VRAM=K4Z80325BC-HC14 FBVDDQ NORMAL NORMAL FBB_D1 DQ0_A FBB_D6 FBB_D24 DQ0_B DQ1_A FBB_D2 FBB_D30 DQ1_B DQ2_A FBB_D4 FBB_D29 DQ2_B DQ3_A FBB_D5 FBB_D31 DQ3_B DQ4_A FBB_D3 FBB_D25 DQ5_A DQ4_B FBB_D0 FBB_D26 FBB_CMD0 DQ5_B CA0_A VREFC...
  • Page 66 Schematic Diagrams Frame Buffer Partition B FRAME BUFFER PARTITION B 63..32 VRAM=K4Z80325BC-HC14 FBVDDQ NORMAL NORMAL FBB_D35 FBB_D62 DQ0_B DQ0_A FBB_D33 FBB_D59 DQ1_B DQ1_A FBB_D32 FBB_D57 DQ2_A DQ2_B FBB_D36 FBB_D63 DQ3_B DQ3_A FBB_D39 FBB_D56 DQ4_B DQ4_A FBB_D34 FBB_D61 DQ5_B DQ5_A FBB_D37 FBB_D60 FBB_CMD20 DQ6_A...

  • Page 67: Frame Buffer Partition C/D

    Schematic Diagrams Frame Buffer Partition C/D GDDR6 CMD Mapping GPU FRAME BUFFER PARTITION C/D x16 Mode Lower 0..31 Upper 32..63 DRAM1 DRAM2 CHA-Byte 0,1 CHA-Byte 4,5 4/22 FBC 5/22 FBD CA0_A CMD0 CMD20 CA1_A CMD9 CMD28 FBC_D0 FBC_CMD0 FBD_D0 FBD_CMD0 FBC_D0 FBC_CMD0 FBD_D0...

  • Page 68: Frame Buffer Partition C

    Schematic Diagrams Frame Buffer Partition C FRAME BUFFER PARTITION C 31..0 VRAM=K4Z80325BC-HC14 FBVDDQ NORMAL NORMAL FBC_D1 DQ0_A FBC_D7 FBC_D25 DQ1_A DQ0_B FBC_D5 FBC_D29 DQ2_A DQ1_B FBC_D4 FBC_D28 DQ2_B DQ3_A FBC_D6 FBC_D31 DQ3_B DQ4_A FBC_D3 FBC_D26 DQ4_B DQ5_A FBC_D0 FBC_D24 FBC_CMD0 DQ5_B CA0_A VREFC...
  • Page 69 Schematic Diagrams Frame Buffer Partition C FRAME BUFFER PARTITION C 63..32 VRAM=K4Z80325BC-HC14 FBVDDQ NORMAL NORMAL FBC_D38 DQ0_A FBC_D34 FBC_D56 DQ0_B DQ1_A FBC_D36 FBC_D57 DQ2_A DQ1_B FBC_D39 FBC_D58 DQ2_B DQ3_A FBC_D35 FBC_D59 DQ3_B DQ4_A FBC_D32 FBC_D60 DQ4_B DQ5_A FBC_D33 FBC_D61 FBC_CMD20 DQ5_B CA0_A VREFC...

  • Page 70: Frame Buffer Partition D

    Schematic Diagrams Frame Buffer Partition D FRAME BUFFER PARTITION D 31..0 VRAM=K4Z80325BC-HC14 FBVDDQ NORMAL NORMAL FBD_D5 DQ0_A FBD_D1 FBD_D30 DQ1_A DQ0_B FBD_D0 FBD_D28 DQ1_B DQ2_A FBD_D3 FBD_D26 DQ2_B DQ3_A FBD_D6 FBD_D31 DQ3_B DQ4_A FBD_D7 FBD_D25 DQ5_A DQ4_B FBD_D2 FBD_D27 FBD_CMD0 DQ5_B CA0_A VREFC...
  • Page 71 Schematic Diagrams Frame Buffer Partition D FRAME BUFFER PARTITION D 63..32 VRAM=K4Z80325BC-HC14 FBVDDQ NORMAL NORMAL FBD_D35 DQ0_A FBD_D33 FBD_D56 DQ0_B DQ1_A FBD_D32 FBD_D59 DQ1_B DQ2_A FBD_D37 FBD_D58 DQ2_B DQ3_A FBD_D34 FBD_D60 DQ3_B DQ4_A FBD_D39 FBD_D57 DQ5_A DQ4_B FBD_D36 FBD_D62 FBD_CMD20 DQ6_A DQ5_B CA0_A...

  • Page 72: Straps, Xtal

    Schematic Diagrams Straps, XTAL MULTI-LEVEL STRAPS XTAL [26,27] GPU_PLLVDD_XS_SP 13/22 XTAL/PLL Near the GPU BD12 1V8_RUN SP_PLLVDD Strap5 HCB1608KF-300T60 C655 C769 C358 C799 BC12 VID_PLLVDD 1V8_AON 1V8_AON STRAP[0:2] non-Gsync = L Setting RAM type Gsync = H R182 R181 R180 R631 R622 R626...

  • Page 73: Ifp I/O Interface

    Schematic Diagrams IFP I/O Interface N18E 7/22 IFPAB R147 R142 IFP I/O INTERFACE DL-DVI DVI/HDMI 100K_04 100K_04 To TBT DIFF=90ohm, L<4" BH11 IFPA_AUX MDP_A_AUX#_SDA [49] BG11 IFPA_AUX MDP_A_AUX_SCL [49] BF21 IFPA_L3 MDP_A#3 [49] T XC T XC R131 1K_1%_04 BD23 BG21 IFPAB_RSET IFPA_L3...

  • Page 74: Mdp

    Schematic Diagrams 10/22 IFPE R581 R587 To mDP_E DVI/HDMI 100K_04 100K_04 DIFF=90ohm, L<4" BD17 R136 1K_1%_04 IFPE_RSET IFPE_AUX MDP_E_AUX#_SDA [13] IFPE_AUX MDP_E_AUX_SCL [13] 20 mil HCB1608KF-300T60 BG14 IFPE_L3 MDP_E#3 [13] IFPE_PLLVDD BD15 BH14 [25,26] GPU_PLLVDD_XS_SP IFPE_PLLVDD IFPE_L3 MDP_E3 [13] C752 BF14 IFPE_L2 TXD0...

  • Page 75: Misc, Gpio, I2C & Rom

    Schematic Diagrams Misc, GPIO, I2C & ROM 1V8_AON VBIOS ROM 8M IVGA_DVGA ROM SWITCH MISC, GPIO, I2C and ROM (OPTIMUS) IVGA_ROM_CS#_R R586 33_04 1V8_AON R111 14/22 MISC 2 10K_04 HOLD VGA_ROM_CS# Q56B 3.3VS C296 ROM_CS IVGA_ROM_CS# IVGA_ROM_CS#_R IVGA_ROM_CS#_R *MTDK3S6R R107 *33_04 VGA_ROM_SI ROM_SI...

  • Page 76: Gpu Vdd

    Schematic Diagrams GPU VDD NVVDD NVVDD NVVDD NVVDD FBVDDQ FBVDDQ NVVDD NVVDD 17/22 VDD_1/3 18/22 VDD_2/3 19/22 FBVDDQ 22/22 VDD_3/3 AA13 AE28 AH39 AP23 AA10 AT43 FBVDDQ FBVDDQ AA14 AE29 AH40 AP24 AA11 BG45 FBVDDQ FBVDDQ AA15 AE30 AJ13 AP25 AA42 BG46 FBVDDQ...

  • Page 77: Gpu Gnd

    Schematic Diagrams GPU GND 20191114 Del 45491_PWR 15/22 GND_1/3 16/22 GND_2/3 21/22 GND_3/3 20191207 Del R360 AR20 BL40 PWR_SRC_VINP_R AR21 BL43 R792 75K_1%_04 BS_IN1 NV3V3 AJ14 AR22 BA48 AJ15 AR23 C1486 1000p_50V_X7R_04 R789 649_1%_04 C1492 1u_6.3V_X6S_04 AJ16 AR24 BB49 AJ17 AR25 BC13 PWR_SRC_NV_VINP_R...

  • Page 78: Gpu Decoupling

    Schematic Diagrams GPU Decoupling NVVDD 1V8_AON NVVDD NVVDD NVVDD NVVDD 1V8_AON C484 C690 C1375 330U_2V_D2_D 330U_2V_D2_D *330U_2V_D2_D COMMON COMMON COMMON 2V@105degC 2V@105degC 2V@105degC C315 C318 C734 C300 C276 C620 C681 AL-Polymer AL-Polymer AL-Polymer C849 C761 C814 C763 C770 C790 C743 C832 C842 3.5A@105degC,100KHz...

  • Page 79: Gpu Ctrl, Level Shift

    Schematic Diagrams GPU CTRL, Level Shift GPIO14_IFPA_HPD_R Voltage Requlator CTRL COMPLEX 1V8_AON GPU_PEX_RST# FROM TBT R138 10K_04 GC6_FB_EN_PCH R244 10K_04 R169 *10K_04 1V8_AON 3.3VA FBVDDQ_EN [70] FBVDDQ_EN DGPU_RST#_PCH DP_A R139 *10K_04 PEXVDDEN GPIO14_IFPA_HPD_R [28] [42] NV_EN_DOW N VIN_DOWN PEX_VDD_EN DGPU_PW R_EN R146 *10K_04 GPIO20_FL_SYNC_GPU_FGC6...

  • Page 80: Pch A

    Schematic Diagrams PCH A CONSENT STRAP Pin Straps(2) U30A LOW=ENABLE GPP_A11 BE36 AV29 GPP_A11/PME#/SD_VDD2_PWR_EN# GPP_B13/PLTRST# PLT_RST# [32,41] ESPI FLASH SHARING MODE SPI_IO2 R826 *4.7K_04 HIGH=SLAVE ATTACEHD FLASH SHARING (SAFS) RSVD2 GPP_K16/GSXCLK LOW=MASTER ATTACHED FLASH SHARING (MAFS) SPI_IO3 RSVD1 R825 *1K_04 GPP_K12_PLVDD_SEL [10] GPP_K12/GSXDOUT...

  • Page 81: Pch B

    Schematic Diagrams PCH B U30B USB_P1# [52] DMI_MT_IR_0_DN DMI0_RXN USB2N_1 USB3.1 GEN2 TYPE C+DP DIFF= 85ohm, L=3"~12" DMI_MT_IR_0_DP DMI0_RXP USB2P_1 USB_P1 [52] USB_P3# [50] DMI_IT_MR_0_DN DMI0_TXN USB2N_2 USB3.1 GEN2 TYPE C DIFF= 85ohm, L=3"~9" USB_P3 [50] DMI_IT_MR_0_DP DMI0_TXP USB2P_2 DMI_MT_IR_1_DN DMI1_RXN USB2N_3 USB_P2#...

  • Page 82: Pch C

    Schematic Diagrams PCH C 3.3VS 0_06 R368 10K_04 [42] SCI# R326 *0_04 SCI#_GPP_A7 [37] SCI#_GPP_K3 R382 0_04 3.3VA RB751S-40H R693 10K_04 [42] SW I# R694 *0_04 SW I#_GPP_G6 [33] SW I#_GPP_K6 R697 0_04 BIOS RECOVERY LOW=ENABLE 3.3VS GPP_F10 R355 *100K_04 U30C [55] CL_CLK1...

  • Page 83: Pch D

    Schematic Diagrams PCH D VDDQ DDR4_DRAMRST# CLOSE TO PCH R397 470_04 Zo=50ohm, L <=14" <500mil U30D HDA_BITCLK_R BD11 BF36 R705 22_04 [44] HDA_BITCLK HDA_BCLK/I2S0_SCLK GPP_A12/BM_BUSY#/ISH_GP6/SX_EXIT_HOLDOFF# BE11 AV32 ECCLKRUN# 3.3VS [44] HDA_SDIN0 ECCLKRUN# [42] HDA_SDOUT_R HDA_SDI0/I2S0_RXD GPP_A8/CLKRUN# R707 22_04 BF12 [44] HDA_SDOUT HDA_SDO/I2S0_TXD HDA_SYNC_R...

  • Page 84: Pch E

    Schematic Diagrams PCH E U30E AL13 TBT_GPIO_RST# [46] GPP_I5/DDPB_CTRLCLK [32,52] MDP_B_HPD GPP_I0/DDPB_HPD0/DISP_MISC0 GPP_I6/DDPB_CTRLDATA AN10 AN13 [12,32] HDMI_HPD GPP_I1/DDPC_HPD1/DISP_MISC1 GPP_I7/DDPC_CTRLCLK AL10 [13,32] MDP_E_HPD GPP_I2/DDPD_HPD2/DISP_MISC2 GPP_I8/DDPC_CTRLDATA SSD1_PWR_EN [54] AL15 [46,49] PS8330B_HPD SSD2_PWR_EN [54] GPP_I3/DDPF_HPD3/DISP_MISC3 GPP_I9/DDPD_CTRLCLK GPP_I10/DDPD_CTRLDATA 20191212 MDP_A_TBT_HPD change to PS8330B_HPD AN40 DGPU_PWR_EN [32,42,49] GPP_F23/DDPF_CTRLDATA...

  • Page 85: Pch F

    Schematic Diagrams PCH F 24 MHz XTAL24_IN_PCH C1392 12p_50V_NPO_04 U30G BE33 GPP_A16/CLKOUT_48 PCH_XDP_CLK_DN DIFF= 85ohm, L=4"~9" R691 CLKOUT_ITPXDP PCH_XDP_CLK_DP CPU_24MHZ_R_DP CLKOUT_CPUNSSC_P W76-147_24MHZ CLKOUT_ITPXDP_P CPU_24MHZ_R_DN CLKOUT_CPUNSSC PCB Footprint = FSX3M 200K_1%_04 PCH_CPU_PCIBCLK_R_DN CLKOUT_CPUPCIBCLK 24MHz XTAL PCH_CPU_BCLK_R_DP CLKOUT_CPUBCLK_P CLKOUT_CPUPCIBCLK_P PCH_CPU_PCIBCLK_R_DP P/N: 6-22-24R00-1BA PCH_CPU_BCLK_R_DN CLKOUT_CPUBCLK DIFF= 85ohm, L=4"~9"...

  • Page 86: Pch G

    Schematic Diagrams PCH G U30H +VCCPRIM_1P05 5.95A AA22 0.182A +VCCPHVC_3P3 1.05VA 3.3VA VCCPRIM_1P051 VCCPRIM_3P32 AA23 C1071 1u_6.3V_X5R_02 VCCPRIM_1P052 AB20 BF47 +VCCRTCEXT C1496 1u_6.3V_X5R_02 VCCPRIM_1P053 DCPRTC1 AB22 BG47 VCCPRIM_1P054 DCPRTC2 AB23 VCCPRIM_1P055 AB27 0.095A +VCCPUSB2_3P3 3.3VA Follow intel spec_611574 Page31 VCCPRIM_1P056 VCCPRIM_3P35 AB28 C1509,C1510...

  • Page 87: Pch H

    Schematic Diagrams PCH H U30I U30L AL12 VSS_1 VSS_73 AL17 VSS_145 VSS_196 BG33 VSS_2 VSS_74 AL21 VSS_146 VSS_197 BG37 VSS_3 VSS_75 AL24 VSS_147 VSS_198 VSS_4 VSS_76 AL26 VSS_148 VSS_199 BG48 VSS_5 VSS_77 AL29 VSS_149 VSS_200 VSS_6 VSS_78 AL33 VSS_150 VSS_201 VSS_7 VSS_79 AL38...

  • Page 88: Pch I

    Schematic Diagrams PCH I U30J BOARD_ID1 DGPU BOARD_ID (GPP_C10,GPP_A23) RSVD7 0=PB50xx 00=PBxxDD2 RSVD8 1=PB70xx 10=PBxxDF1 11=PBxxDF2 RSVD6 RSVD5 3.3VS 3.3VS 3.3VS RSVD3 RSVD4 20191230 ADD BOARD_ID AH15 RSVD2 R293 R279 R775 AH14 RSVD1 100K_04 100K_04 100K_04 BOARD_ID1 GPP_A23 DGPU_Model PB70xx BOARD ID OPTION_DGPU BOARD_ID0_G2R G1R=stuff OPTION_DGPU BOARD_ID0_G2R = stuff BOARD_ID2...

  • Page 89: Ec Ite5570

    Schematic Diagrams EC ITE5570 VDD3 RGBKB-DET# PERKB-DET# R417 10K_04 IT5570 VDD3 PIN71 PIN83 MODEL_ID R418 10K_04 L: W/ RGB KB L: W/ PER-LEY [42,64,67,71] SMC_BAT VDD3 AIRPLAN_LED# [58] H: W/O RGB KB H: W/O PER-KEY BAV99 RECTIFIER C1164 C1171 C1139 C1127 MODEL_ID KBC_AVDD...

  • Page 90: Tpm

    Schematic Diagrams SLB9670 & Z32H330TC COLAY 3.3VA R425 C1137 C1152 C1134 4.7K_04 0.1u_6.3V_X5R_02 0.1u_6.3V_X5R_02 1u_6.3V_X5R_02 W/ TPM TPM_GPIO GPIO0 TPM_PP R420 4.7K_04 R437 0_04 3.3VA C1151 [41,42,45,46,54,55,58] BUF_PLT_RST# RST# VSS_3 0.1u_6.3V_X5R_02 [36] TPM_PIRQ# PIRQ# NC_1 NC_2 R422 56_1%_04 [33] TPM_SPI_SCLK_R SPI_CLK NC_3 NC_4...

  • Page 91: Audio Alc1220

    Schematic Diagrams Audio ALC1220 For 3.3V HDA Link. 20191205 Follow common 3.3VS_AUD DVDD_IO R234 *short-p_04 PI2S_DOUT1 R231 33_04 [58] P_I2S_DOUT1 PI2S_SCLK R232 33_04 [58] P_I2S_SCLK PI2S_LRCK R233 33_04 C1007 C991 [58] P_I2S_LRCK Spilt by DGND 10u_6.3V_X5R_06 0.1u_6.3V_X5R_02 POST I2S Digital Analog 3.3VS 3.3VS_AUD...

  • Page 92: Lan Rtl8111H

    Schematic Diagrams LAN RTL8111H T PWRON =3.3Vaux power on time LAN Board (GLAN RTL8111H) =0.5~100ms If support RTD3, IC Change to RTL8111H 3.3Vaux 3.3V Main Power TPVPERL RSET 2.49K_1%_04 =Power stable to PERST# inactive =ISOLATE >100ms XTAL2 XTAL1 PERST# TPERST LED0 =PERST# active time AVDD33/700mA...

  • Page 93: Titan Ridge

    Schematic Diagrams Titan Ridge RTD3 Support: U22A In order to support RTD3, DG_PERST# PET0_P C1112 0.22u_10V_X5R_04 and DG_PEWAKE# [35] PCIE_TXP17_TBT PCIE_RX0_P PCIE_TX0_P PCIE_RXP17_TBT [35] PET0_N C1111 0.22u_10V_X5R_04 signals should reserve connections to [35] PCIE_TXN17_TBT PCIE_RX0_N PCIE_TX0_N PCIE_RXN17_TBT [35] dedicated PCH GPIOs PET1_P C1114 0.22u_10V_X5R_04...

  • Page 94: Titan Ridge Pwr

    Schematic Diagrams Titan Ridge PWR VCC3V3_SX_SYS VCC3V3_S0_SYS C1436 C1469 C1433 C1435 1u_6.3V_X5R_02 1u_6.3V_X5R_02 U22B 1u_6.3V_X5R_02 1u_6.3V_X5R_02 W / TBT W / TBT W / TBT W / TBT VCC0P9_SVR_PAB_AN VCC3P3_SVR VCC0V9_SVR VCC3V3_S0_SYS VCC0P9_SVR_PAB_AN VCC3P3_SVR VCC0P9_SVR_PAB_AN VCC3P3_SVR VCC0P9_SVR_PAB_AN VCC3P3A VCC0P9_SVR_PAB_AN C1460 C1448 C1451 C1457...

  • Page 95: Tps65987D

    Schematic Diagrams TPS65987D VCC5V0_SYS Short 80Ohm, 0.01Ohm DCR, 8A Idc HCB2012KF-800T80 VCC3V3_FLASH TBTA_VBUS C1404 C1383 C1382 U52B 1u_6.3V_X5R_04 CSOD140BSH 10u_6.3V_X5R_04 10u_6.3V_X5R_04 20191205 Follow common LDO_1V8 VBUS1 VBUS1 LDO_3V3 600mA VBUS2 VCC5V0_SYS VBUS Source 5V,3A VCC5V0_SYS PP_CABLE VBUS2 C976 C979 PP_HV1 PP_HV1 DRAIN1 C1388...

  • Page 96: Ps8330B

    Schematic Diagrams PS8330B 3.3VS mDP REDRIVER R193 100K_04 From NV Port_A To TBT W / TBT PS8330 DIFF=90ohm, Total L<6" DIFF=100ohm, L<2" PS8330B_AUXn C882 0.1u_10V_X7R_04 W / TBT PS8330 [26] MDP_A_AUX#_SDA PS8330B_AUXn_SDA [46] PS8330B_AUXp_SCL [46] PS8330B_AUXp C898 0.1u_10V_X7R_04 W / TBT PS8330 [26] MDP_A_AUX_SCL 3.3VS...

  • Page 97: Usb

    Schematic Diagrams From PCH CO-lay TOP,BOT overlay DIFF= 80ohm, L<5" TBTA_RX_1_N R783 0_1%_02 W / USB3.1 (W/O TBT) C1098 0.33u_6.3V_X5R_02 [37] USB3_RX3# TBTA_RX_1_P R787 0_1%_02 W / USB3.1 (W/O TBT) C1099 0.33u_6.3V_X5R_02 [37] USB3_RX3 TBTA_TX_1_N R772 0_1%_02 W / USB3.1 (W/O TBT) C1085 0.22u_10V_X5R_02 [37]...

  • Page 98: Anx7440

    Schematic Diagrams ANX7440 Layout rules: USB3.1/DP MUX ANX7440 1. Place ANX7440/30/90/96 and USB Type-C/Type-A connector in an open area for easier routing. 2. High-speed trace should be routed with high-priority. 3. If using internal DC/DC, create a dedicated DC/DC VGND 4.

  • Page 99: Anx7411

    Schematic Diagrams ANX7411 TYPE-C (USB3.1 Gen2+DP) close to connector TYPE-C_VBUS 20191022 W/O PD VOUT 3.3V 10u_6.3V_X5R_06 SOURCE_CTRL_7411 SY6288E1AAC HCB1005KF-121T20 PCB Footprint = m-sot23-5a 5V/3A/50m ohm ANX7411_AVDD33 20191022 W/O PD C1229 1u_6.3V_X5R_02 0.1u_6.3V_X5R_02 1000p_50V_X7R_04 20191206 Follow common 374uA AUXP R511 *100K_04 AUXN Sheet 52 of 85 VCONN_POWER is the power source for VCONN:...

  • Page 100: Usb Type-A

    Schematic Diagrams USB Type-A USB3.1 REDRIVER ASM1464 3.3V 3.3V *0_04 *4.7K_04 C1183 2K_1%_04 *4.7K_04 C1184 C1185 0.1u_6.3V_X5R_02 1u_6.3V_X5R_02 0.01u_16V_X7R_04 From PCH DIFF=85ohm, MS=L<7", SL=L<9" SCK_P1 SDA_P1 R484 *4.7K_04 *4.7K_04 SMB_SCK SMB_DATA USB3_TX6# C1186 0.1u_10V_X7R_04 TXN6 [37] USB3_TX6# RX1- TX1- USB3_TX6 C1188 0.1u_10V_X7R_04 TXP6...

  • Page 101: M.2 Pciex4 Sata

    Schematic Diagrams M.2 PCIEX4 SATA NGFF_M SSD_1 (PCIE 9,10,11,12 PORT & SATA1A PORT) SSD1_RST# >120 mil J_SSD1 3.3VS_SSD1 C1538 C1537 C1140 W/O RTD3 GND13 R764 100K_04 3.3VS GND12 3.3V8 0.1u_6.3V_X5R_02 0.1u_6.3V_X5R_02 22u_6.3V_X5R_06 R836 0_04 GND11 3.3V7 [41,42,43,45,46,54,55,58] BUF_PLT_RST# SATAGP_SSD1 W/O RTD3_M2_SSD R778 1K_04 [35]...

  • Page 102: M.2 Wlan+Bt

    Schematic Diagrams M.2 WLAN+BT WLAN+BT/CNVi POWER VDD3 W LAN_3.3V >120 mil >120 mil VOUT C1156 VIN/SS 1u_6.3V_X5R_02 W LAN_3.3V UP7553PMA5-25 [42] W LAN_PW R_EN NCT3522U P/N: 6-02-03522-9C0 G5243A P/N: 6-02-05243-9C0 C1082 C1155 AP2821KTR-G1 P/N: 6-02-02821-9C0 J_W LAN1 WLAN+BT/CNVi >40 mil GND13 3.3V3 W LAN_3.3V...

  • Page 103: Hdd, Ccd, Fingerprint, Lid

    Schematic Diagrams HDD, CCD, Fingerprint, LID 3.3VS CCD_PW R FINGER PRINT CONN CCD CONN >40 mil >40 mil VOUT C1287 C1255 0.5 Pitch CCD_EN 1u_6.3V_X5R_02 2.2u_6.3V_X5R_04 J_FP1 >30 mil UP7553PMA5-25 FCM1005KF-121T03 3.3VS M-SOT23-5 J_CCD1 DIFF= 85ohm [42] CCD_EN L=3"~12" DIFF= 85ohm USB_P7# [34] *WCM2012F2S-161T03-short...

  • Page 104: Led Keyboard Ctrl

    Schematic Diagrams LED Keyboard Ctrl RGB LED KEYBOARD 17" RGB LED KEYBOARD RGBKBSW _R KBZONE_R R740 0_06 KB RGB RGBKB_PW R MTA90N03ZN3 [42] EC_PW M_LEDKB_R KB RGB KBZONE_G R743 0_06 RGBKBSW _G KB RGB J_LEDKB2 MTA90N03ZN3 [42] EC_PW M_LEDKB_G KB RGB KBZONE_B LED_KB_PIN4 R741...

  • Page 105: Conn_To Extend Board

    Schematic Diagrams Conn_to Extend Board LED BOARD CARDREADER BOARD AMP_PW R 3.3VS M2M_SSD2_LED#R [35,54] J_CRBD1 SATAHDD_LED# [35,54] LED_HDD# J_LED1 R458 100K_04 3.3VS 3.3VS 3.3VS 74AHC1G08GW 3.3V AMP_TYPE_DET (TO PCH) HIGH : NORMAL AMP M2M_SSD1_LED#R [54] LOW : SMART AMP RB751S-40H AMP_TYPE_DET [41] LED_HDD#...

  • Page 106: 3.3Va, 3.3V, 3.3Vs, 5Vs

    Schematic Diagrams 3.3VA, 3.3V, 3.3VS, 5VS VDD3 C1131 C1129 C1142 C1130 R459 1000p_50V_X7R_04 1000p_50V_X7R_04 0.01u_50V_X7R_04 0.01u_50V_X7R_04 100K_04 DD_ON# DD_ON# [53] C1169 DD_ON [10,42,50,58,60,62] DD_ON *0.1u_6.3V_X5R_02 2SK3018S3 R445 100K_04 VDD3 VDD3 C1533 C1500 FA7601 0.1u_6.3V_X5R_02 10u_6.3V_X5R_06 3.3VA NV3V3 VDD3 Only source: FA7601 3.3VA NV3V3...

  • Page 107: Vdd3, Vdd5

    Schematic Diagrams VDD3, VDD5 PR288 PR319 13K_1%_04 34.8K_1%_04 PJ10 [42] XLP_OUT DEFAULT SHORT EN_3V EN_5V PC295 *CV-40mil 1000p_50V_X7R_04 VREG3 PC77 PC76 PC74 PC73 PC75 PC69 PC248 PC196 PU27 PC289 1u_6.3V_X5R_04 VREG3 PGOOD PC279 PR286 PR317 PC306 0.1u_16V_X7R_04 0_06 0_06 0.1u_16V_X7R_04 VDD3 VDD5 VBST2...

  • Page 108: Pwr 2.5V, Vddq, Vtt

    Schematic Diagrams PWR 2.5V, VDDQ, VTT VTT_MEM (0.675V) PU25 PD10 *RB0540S2 PC259 PC62 PC61 G5616BRZ1U 0.1u_25V_X7R_06 4.7u_25V_X5R_08 4.7u_25V_X5R_08 VDDQ_R PC241 PC265 10u_6.3V_X5R_06 0.1u_16V_X7R_04 VDDQ_VBST VDDQ (1.2V) VLDOIN VBST VTT_MEM PR251 VDDQ_DRVH 0_06 PL22 DRVH VDDQ BCIHP0730-1R0M PJ29 PC271 PC274 PR283 PCB Footprint = BCIHP0735A VDDQ_L VDDQ_R...

  • Page 109: 1.8Va, 1.05Va

    Schematic Diagrams 1.8VA, 1.05VA VREG5 PR57 PU14 AOZ2261NQI-11 0_06 PC147 PC32 PC150 PC31 3.3VA PR167 4.7u_6.3V_X5R_06 180K_1%_04 PR148 PR176 PC155 PR172 *10K_1%_04 0_04 0.1u_16V_X7R_04 10K_1%_04 1.8VA_PG PGOOD 1.8VA PS_1V8_PFM PFM* PR169 1.8VA 10K_1%_04 PL11 *CV-40mil BCIHP5420HC-1ROM PS_1V8_EN_R PR54 100K_04 PR184 *6.8K_1%_04 PC172 PC173...

  • Page 110: Vccio

    Schematic Diagrams VCCIO PR202 3.3_06 GPP_J1 PR199 PC215 0_04 0.22u_16V_X7R_06 VCCIO PU16 PC200 PC198 PC202 PL14 VCCIO PJ18 BCIHP-0735-0R68M-NL VCCIO_R PCB Footprint = BCIHP0735A PC217 PC203 PC208 PC204 PC201 PC199 DEFAULT SHORT PR188 NB681GD-Z VOUT 100_04 PJ22 *CV-40mil VCCIO_EN_R PR191 100K_04 3.3VS PJ19...

  • Page 111: Vcore

    Schematic Diagrams VCore VR_VDD18 VDD3 VCORE VRACPU_PW M1 VRACPU_PW M1 [65] PJ16 *CV-40mil VRACPU_PW M2 PR99 10K_04 3.3V VRACPU_PW M2 [65] VRACPU_PW M3 PJ17 VRACPU_PW M3 [65] PC15 *0.1u_16V_X7R_04 [4,10,41,42] ALL_SYS_PW RGD VRACPU_PW M4 GND_SIGNAL VRACPU_PW M4 [65] DEFAULT SHORT VRAGT_PW M1 VRAGT_PW M1 [66]...

  • Page 112: Vcore Output Stage

    Schematic Diagrams VCore Output Stage VCORE OUTPUT STAGE E-CAP 100u_25V EPC11 PC118 PC109 PC103 4th Phase For CPU 6+2 EPC14 PC116 PC102 PC108 PC29 PC27 PC28 3.3V CPU_DR_VCC 140A CPU_DR_VCC PU10 MP86941GQVT-Z VDD3 PR56 0_06 MP86941GQVT-Z 0V~1.52V VIN1 PR55 *0_06 PC134 VCORE 4 Phase VIN1...

  • Page 113: Vccgt, Vccsa

    Schematic Diagrams VCCGT, VCCSA VCCGT & VCCSA OUTPUT STAGE EPC13 PC121 PC107 PC113 VR recommend GT 330uF*1 PU12 MP86903-CGLT-Z VCCGT 1Phase CPU_DR_VCC PCB Footprint = tqfn21-3x4mm VCCGT VCCGT VIN1 PC125 VIN2 ICCMAX=16A , OCP=30A 1u_6.3V_X6S_04 BST_GT 0V~1.5V AGND PC136 PR144 0_04 1u_16V_X7R_06 VCCGT...

  • Page 114: Nvvdd-1

    Schematic Diagrams NVVDD-1 PD11 NVVDD PHASE 6 BAT54AS3 W / PROGRAM SW From EC PR282 1.5K_04 MP2884A_EN_1 [70] NVVDD FOR N18E-G2_VGA W / PROGRAM SW [42,64] POW ER_IC_EN MP2886A_EN PR281 1.5K_04 PR271 10K_04 VDD3 W / PROGRAM SW W / PROGRAM SW PR270 10K_04 PR275...

  • Page 115: Nvvdd-2

    Schematic Diagrams NVVDD-2 PWR_SRC_NV PWR_SRC_NV PWR_SRC_NV PR74 0_04 [67] VINSEN_NVVDD PC260 PC254 PC238 EPC7 EPC8 PC251 PC255 PC236 EPC34 *0.1u_25V_X7R_06 *0.1u_25V_X7R_06 0.1u_25V_X7R_06 20191219 Power modify PU23 PC232 20191219 Power modify PU20 PC231 1u_25V_X7R_06 1u_25V_X7R_06 NVVDD NV3V3 NVVDD NVVDD PL21 PL18 NVVDD_DRMOS_VCC NVVDD_DRMOS_VCC PR234...

  • Page 116: Pex_Vdd

    Schematic Diagrams PEX_VDD Cold boot/Optimus:1V8_AON→ 1V8_RUN→ NVVDD→ NVVDDS→ PEX_VDD→ FB V D D Q GC6 2.1 Exit:1V8_RUN→ NVVDD→ NVVDDS→ PEX_V D D PR174 NV power off seq need < 2ms PEX_VDD PU13 0_06 AOZ2261NQI-11 PC34 PC33 PC152 PR60 PR64 PR63 PR61 PR62 PC149...

  • Page 117: Fbvddq

    Schematic Diagrams FBVDDQ FBVDDQ PHASE 2 PR97 0_04 [28,67] I2CC_SDA PR92 0_04 FBVDD [28,67] I2CC_SCL PWR_SRC_NV_FB [67] MP2884A_EN_1 PR18 10K_04 [32] FBVDDQ_EN ----- IccMax PC98 PC100 PC87 PR87 *10K_1%_04 1V8_AON 3.3VS 1u_25V_X7R_06 Vboot ----- PR90 0_04 [28] GPIO25_FBVDD_PSI# *R_04 AGND_MP2884A Load Line 0m ohm PR53...

  • Page 118: Charger

    Schematic Diagrams Charger SMART CHARGER TI24780S Battery=3S2P HCB2012KF-800T80 min=9V JDC_AC J_DC_JACK1 HCB2012KF-800T80 V_BAT 20191031 PC94 change to 0.1u_25V_X7R_06 J_BAT1 GND1 PC96 PC95 PC94 GND2 PR20 PR19 SMC_BAT PL27 HCB1005KF-121T20 [42,64,67] SMC_BAT 2DC-G213-B80F 4.7_06 4.7_06 SMD_BAT PL28 HCB1005KF-121T20 [42,64,67] SMD_BAT PCB Footprint = 2DC-G213-B48 [42] BAT_DET SMAJ20A...

  • Page 119: Led Board

    Schematic Diagrams LED Board L_3.3VS 220_04 220_04 220_04 220_04 220_04 220_04 LED BD LED BD LED BD LED BD LED BD LED BD RY-SP190YG34-5M RY-SP190YG34-5M RY-SP190YG34-5M RY-SP190YG34-5M RY-SP190YG34-5M RY-SP190YG34-5M dGPU LED SCROLL LOCK LED CAPS LOCK LED NUM LOCK LED AIRPLANE LED HDD LED LED BD...

  • Page 120: Power Board

    Schematic Diagrams Power Board B3.3VS BJ_BTN1 BM_BTN# B3.3VS B3.3VS BGND 20mil 20mil FP226H-004S10M BGND P/N = 6-20-94A40-004 PCB Footprint = fp226H-004xxxm_l 220_04 220_04 20mil 20mil B_SW1 20mil 20mil *0.1u_6.3V_X5R_02 POWER BUTTON *0.1u_6.3V_X5R_02 B_SW 1 BGND BGND BM_BTN# PB50xx TJE-532-Q-T/R PCB Footprint = tje-53x-q P/N = 6-53-3050B-B41 Sheet 73 of 85 BGND...

  • Page 121: Hdd Board

    Schematic Diagrams HDD Board SATA HDD PORT HJ_SATA1 HJ_MB1 HSATA0B_TXP_HDD HSATA0B_TXP_HDD HSATA0B_TXN_HDD HSATA0B_TXN_HDD Sheet 74 of 85 HSATA0B_RXN_HDD HSATA0B_RXN_HDD HSATA0B_RXP_HDD HSATA0B_RXP_HDD HGND HDD Board HGND H_3.3VS H_5VS FP225H-010S10M P/N = 6-20-94K10-010 PCB Footprint = FP225H-010-xxxM H_5VS HGND 0.1u_6.3V_X5R_02 1u_6.3V_X5R_02 10u_6.3V_X5R_06 *22u_6.3V_X5R_06 HGND *0_04...

  • Page 122: Audio Board 1/3

    Schematic Diagrams Audio Board 1/3 CPU FAN AJ_AUDIO1 AVDD5 A5VS A3.3V AAMP_PWR W/ CPU FAN_5V stuff A5VS AC21 10u_6.3V_X5R_06 AGND >1A AC22 10u_6.3V_X5R_06 AUSB3_TXN5 [76] AGND AUSB3_TXP5 [76] AC33 100p_25V_NPO_02 AJ_CFAN1 AGND AUSB3_RXN5 [76] ACPU_FAN_PWM AUSB3_RXP5 [76] ACPU_FANSEN Sheet 75 of 85 ACPU_FAN_GND AUSB_PN5 [76]...
  • Page 123 Schematic Diagrams Audio Board 2/3 USB3.0 REDRIVER ASM1464 A3.3V AR43 *0_04 AR44 *4.7K_04 20191205 Follow common AR40 *0_04 AR38 *4.7K_04 20191205 Follow common AR34 *0_04 AR36 *4.7K_04 AR32 2K_1%_04 AGND AGND A_SCK_P5 A_SDA_P5 AR30 *4.7K_04 AR45 *4.7K_04 AGND AGND SMB_SCK SMB_DATA AUSB3_TXN5 AC32...
  • Page 124 Schematic Diagrams Audio Board 3/3 Headphone AMP A3.3V AHEADPHONE_L AR25 22_04 AAMP_EN [75] AC18 AC17 AC16 AR24 10u_6.3V_X5R_06 0.1u_6.3V_X5R_02 0.1u_6.3V_X5R_02 10K_04 A_AUDG A_AUDG A_AUDG A_AUDG A_AUDG BYPASS TPA6132A2 AMPLIFIER AHEADPHONE-L AC15 2.2u_16V_X5R_06 INL- PVDD AHEADPHONE_L AHEADPHONE-L AR23 *0_04 [75] AHEADPHONE-L INL+ AC14 AHEADPHONE_R...

  • Page 125: Per Key Board

    Schematic Diagrams Per Key Board R5VS PER KEY LED KEYBOARD BOARD RJ_PERKB1 ROUTR0 RLED_R0 RLED_R1 RRN24 ROUTR1 RRN12 RLED_R2 100K_8P4R_04 ROUTR2 22_8P4R_04 R3.3VS RLED_R3 ROUTR3 RC12 RC10 RLED_R4 ROUTR4 RRN23 ROUTR5 RRN11 RLED_R5 RLED_R6 100K_8P4R_04 ROUTR6 22_8P4R_04 RLED_R7 ROUTR7 GND1 RLED_R8 ROUTR8 GND2...

  • Page 126: Rts5250S

    Schematic Diagrams RTS5250S RTS5250S_SD4.0 TAuxMain =Power-on timing between AUX_PWR to MAIN_PWR XSDREG2 XC125 1u_6.3V_X5R_02 XGND =0~10ms NEAR PIN24 (XCR_3.3VS) XDV33_18 +3V3 Main XC123 1u_6.3V_X5R_02 XGND NEAR PIN18 +3V3 Aux TPVPGL 20191031 change to XCR_3.3VS_IN (XCR_3V3_AUX) =Power valid to PERST# input inactive >1ms XR1_LEDN XR79...

  • Page 127: Internal Amp

    Schematic Diagrams Internal AMP XAMP_5VS X5VS XL17 AMP FOR INTERNAL SPEAKER HCB1608KF-121T30 XC103 XC69 XC109 0.1u_6.3V_X5R_02 0.1u_6.3V_X5R_02 22u_6.3V_X5R_06 XAMP_EN_SPK SHUTDOWN ROUTP XAUDG XAUDG XAUDG 20 mil XC104 2.2u_6.3V_X5R_04 XAUDG BYPASS PVDDR1 XFRONT_R XR66 33K_1%_04 XC106 0.1u_25V_X5R_04 RINN ROUTN Speaker wire length less than 8000mils , It don't need LC Filter. XR65 1K_04 XAUDG...

  • Page 128: Subwoofer

    Schematic Diagrams Subwoofer SUBWOOFER_FILTER XAMP_PW R XR59 100K_04 XAMP_PW R XAMP_PW R XC82 XC55 XC89 XC93 XC97 XC90 XC94 XR57 0.1u_25V_X5R_04 45.3K_1%_04 4.7u_25V_X5R_06 4.7u_25V_X5R_06 0.1u_25V_X5R_04 0.1u_25V_X5R_04 0.1u_25V_X5R_04 0.1u_25V_X5R_04 [80] XFRONT_R XR56 XAUDG XU6A 100K_04 LM324APW R XAUDG XAUDG XSUB_R FILTER-1 FC: 3KHz XC108 0.01u_50V_X7R_04...

  • Page 129: Smart Amp

    Schematic Diagrams Smart AMP AUDIO AMP FOR SPEAKER XL16 HCB1608KF-121T30 X5VS XAMP_3.3VS XL14 HCB1608KF-121T30 XC83 XC85 XC87 XC84 XC96 20191029 Stuff X3.3VS 1u_25V_X5R_06 10u_25V_X5R_08 10u_25V_X5R_08 10u_25V_X5R_08 10u_25V_X5R_08 XC79 XC80 XC73 NEAR 5825 PIN21/PIN22 0.1u_6.3V_X5R_02 0.1u_6.3V_X5R_02 22u_6.3V_X5R_06 XAUDG XL15 *HCB1608KF-121T30 XAMP_PW R XAUDG XC86 XC88...

  • Page 130: Smart Subwoofer

    Schematic Diagrams Smart Subwoofer SMART AMP FOR SUBWOOFER XAMP_PW R XAMP_3.3VS_2 XL13 HCB1608KF-121T30 XC43 XC62 XC56 XC63 XC57 X3.3VS 1u_25V_X5R_06 10u_25V_X5R_08 10u_25V_X5R_08 10u_25V_X5R_08 10u_25V_X5R_08 XC40 XC41 XC32 NEAR 5825 PIN21/PIN22 0.1u_6.3V_X5R_02 0.1u_6.3V_X5R_02 22u_6.3V_X5R_06 XAUDG XAMP_PW R XAUDG XC50 XC64 XC33 XC51 XC52 10u_25V_X5R_08...

  • Page 131: Speaker Conn

    Schematic Diagrams Speaker Conn XAUDG XC129 1000p_50V_X7R_04 XC128 0.1u_25V_X5R_04 XR83 0_04 XR84 0_04 XAUDG XGND Speaker wire length less than 8000mils , It don't need LC Filter. SPKOUTR+,R-,L+,L- Trace width 40mils, Via hole --> C40D20. SPK R From AMP Co-lay TOP,BOT overlay XJ_SPK1 HCB1608KF-121T30...

  • Page 132: Power Sequence

    Schematic Diagrams Power Sequence VA_EC_EN 243.96us ( rise :101.62us ) 3.3VA 230.05us ( rise :55.41us ) VCCPRIM_1P8 = PCH Internal voltage, test R274 VCCPRIM_1P8 949.03us ( rise :355.98us ) 1.05VA 1.83ms ( rise :2.52ms ) VDD5 SLP_SUS_EC# to DD_ON 30.00ms DD_ON 8.49us SUSBC_EN#...

This manual is also suitable for:

Pb70df1Pb70df2Pb71ddsPb71df1Pb71df2

Table of Contents
