EDGE 3D Printer
REPAIR:
INTERNAL MEMORY REPLACEMENT
Revision 5/28/2022

Advertisement

loading
Need help?

Need help?

Do you have a question about the EDGE and is the answer not in the manual?

Questions and answers

Related Manuals for Fusion3 EDGE

Summary of Contents for Fusion3 EDGE

  • Page 1 EDGE 3D Printer REPAIR: INTERNAL MEMORY REPLACEMENT Revision 5/28/2022...
  • Page 2 REMOVE OLD MEMORY (SD CARD) 1. Locate the single board computer towards the front of the electronics bay. 2. On the front edge of the PCB you will see a microSD card sticking out from the bottom face of the board.
  • Page 3 3. Using your fingers or a gentle tool such as plastic tweezers, pull the microSD card out of its slot. This is not a push-to-release card reader, so just pull it straight out. 4. Place the card aside in a location where you won't lose it, and won't confuse it with the new card. INSTALL NEW MEMORY (SD CARD) 1.
  • Page 4 2. Position the card centered on the ribbon cable connector. The card slot is on the bottom of the PCB, so aim the card underneath the PCB.
  • Page 5 3. Use your fingers to get the card started in the slot. 4. Push gently until the card is fully inserted.
  • Page 6 5. If you lose the card under the PCB, pick up the rear of the printer and shake it gently so the card slides out from underneath.
