EDGE 3D Printer
MAINTENANCE:
AIR FILTER REPLACEMENT
Revision 5/28/2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EDGE and is the answer not in the manual?

Questions and answers

Related Manuals for Fusion3 EDGE

Summary of Contents for Fusion3 EDGE

  • Page 1 EDGE 3D Printer MAINTENANCE: AIR FILTER REPLACEMENT Revision 5/28/2022...
  • Page 2 AIR FILTER REPLACEMENT How to replace the EDGE air filters. Your EDGE printer shipped from the factory with a print chamber filter pre-installed. The HEPA and carbon filter elements must be replaced regularly to maintain correct performance and effective filtration of the exhaust air from the print chamber.
  • Page 3 3. Using your fingers, pry up the front or back release tab on the filter carrier. 4. Slightly shift the carrier forward or backwards to disengage the other latch. Remove the assembly from the printer. 5. Remove the spent HEPA and carbon filter elements from the carrier and discard them. 6.
  • Page 4 7. The carbon element goes in first. 8. IGNORE the airflow direction arrow on the filter; install it as shown so that the foam lip sticks out of the carrier. 9. Position the assembly over the filter base and gently press down on both ends to engage the latches.
  • Page 5 11. On the LCD, go to Menu > Utilities > Maintenance > and reset the filter timer. WHERE TO PURCHASE REPLACEMENTS Replacement filter kits can be purchased through our replacement parts store: https://store.fusion3design.com/...
