EDGE 3D Printer

LOADING FILAMENT

Revision 5/28/2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EDGE and is the answer not in the manual?

Questions and answers

Related Manuals for Fusion3 EDGE

Summary of Contents for Fusion3 EDGE

  • Page 1 EDGE 3D Printer LOADING FILAMENT Revision 5/28/2022...
  • Page 2 EDGE - LOADING FILAMENT How to load filament into your EDGE 3D printer 1. Depending on the size of the spool, adjust the rear spool roller to fit the size of spool you are loading. 2. Place the filament spool onto the rollers with the free end of filament paying off...
  • Page 3 3. Open the filament monitoring door on the extruder. 4. Loosen the free end of filament from the spool. Trim the end at a diagonal as shown.
  • Page 4 5. Feed the end into the extruder, through the inlet guide, over the wiper, over the monitoring wheel, and into the liner. Gently push until you feel it bottom out. 6. Grasp the manual advance knob on the side of the extruder, and rotate it slowly away from you as you continue to push on the filament.
  • Page 5 7. Continue to turn the manual advance wheel until you see the filament protrude into the bowden tube at the exit of the extruder. You need to see 1.5-3 inches protruding into the tube. 8. On the control panel, select the "Load Filament"...
  • Page 6 If you're changing from a high temperature material (such as PC, PC-PBT) to a flexible, this is a situation where your odds of encountering a misfeed are higher. One workaround is to load PLA, then unload it, then load your flexible. Tags: edge, load filament Related Articles / Resources:...
