7. Test speaker wiring for short circuits.
Measure the resistance of each Home Run wiring
with an ohmmeter. Any pair indicating a value of
less than 15 Ohms must be rechecked for possi-
ble shorted wiring or speakers. Correct any prob-
lems and retest.
8. Make zone connections to Controller and
Z.E.U. (see Figures 5 thru 7).
The zone connectors on the Controller and Z.E.U.
can accommodate up to two 22 AWG wires or four
24 AWG wires per zone output. Check zone
option switch setting with Zone Map and Zone
Configuration tables as you connect each zone.
NOTE: DO NOT over tighten zone connector
screws.
Powering Up System
With all zones wired and connected to the Con-
troller and Z.E.U.(s), initial testing can begin.
Once initial testing is done, you can begin to pro-
gram the Controller with the features for each
zone.
1. Plug the power cord into the AC input connec-
tor on the AmpliCenter®. the following should
happen:
a. The green Power LED on the AmpliCenter
will turn on and stay on.
b. The green Page Access LED on the
AmpliCenter also turns on, but will go out
after a few seconds.
c. On the Controller, verify that the green
Phone System Enabled LED is off.
d. On the Controller, verify that the yellow
Attendant Access Enabled LED is off.
e. The green Power LED on the Z.E.U.(s) will
turn on and stay on.
NOTE: If during power up, the system does not
respond as described, refer to the Troubleshoot-
ing section of this guide, and/or the PagePac®
Plus System Installation and Configuration guide
for detailed troubleshooting.
2. Begin programming the Controller.
A quick reference card for telephone program-
ming, along with detailed programming instruc-
tions, can be found in the PagePac Plus System
Installation and Configuration Guide,
Programming.
Technical Manuals Online! - http://www.tech-man.com Technical Manuals Online! - http://www.tech-man.com

TROUBLESHOOTING

Some common problems encountered when the
paging system is not operating are described
below. Check each item in the order listed.
1. No AC power to AmpliCenter or Controller
2. Host telephone system failure.
3. Host system page port failure.
4. A hardwire disconnect between host system
5. AmpliCenter, Controller, or Z.E.U. zone
If the problem has not been resolved by checking
the preceding items, refer to the troubleshooting
tables in the PagePac Plus Installation and Con-
figuration Guide.
Controls and Indicators, Terminals and
Connectors
Figure 9 shows the controls and indicators, termi-
nals and connectors on the rear panel of the
Z.E.U.(s). Table 1 identifies them by function.
2
firealarmresources.com
(they supply power to the Z.E.U.(s)).
and Controller.
switches or DIP switch settings tampered with.
Table 1: Controls and Indicators, Terminals
and Connectors
1. Zone option 3-position slide switch: 70V
audio out, contact closure input, contact
closure output.
2. Zone connector for expansion zones: plus,
minus, and ground screw terminals.
3. 8-pin Molex connector from controller:
power, control, and audio or previous
Z.E.U.
4. 8-pin Molex connector to additional
Z.E.U.: power, control and audio.
5. DIP switch to be set when one, two, or
three Z.E.U.(s) are used.
