Final Power Adjustments; Technical Assistance; 15 Watt Settings; 30 Watt Settings - Valcom PagePac V-5331200 Quick Start Manual

15/30 watt horn (70v)
Table of Contents

Advertisement

5. Do not replace the plastic cover until final
power adjustments have been made.

FINAL POWER ADJUSTMENTS

While a page is in process, adjust the power tap
setting control with a screwdriver. Turn clockwise
to increase the volume (see Figure 2).
NOTE: Protect hearing when working around
horns.
MOUNTING ON FLAT SURFACE
MOUNTING
BRACKET

TECHNICAL ASSISTANCE

When calling, have a VOM and a telephone test
set available and call from the job site. Call (540)
427-3900 and ask for PagePac Technical Sup-
port, or call (540) 427-6000 for Valcom 24-hour
Automated Support or visit our websites at
http://www.pagepac.com and www.valcom.com.
Should repairs be necessary, attach a tag to the
unit clearly stating company name, address,
phone number, contact person, and the nature of
the problem. Send the unit to:
Roanoke, VA 24019-5056
Technical Manuals Online! - http://www.tech-man.com
Technical Manuals Online! - http://www.tech-man.com
WING NUT
FIGURE 1
Valcom, Inc.
®
PagePac
Repair Dept.
5614 Hollins Road
firealarmresources.com
FIGURE 2
Table 1: 15 WATT SETTINGS
SWITCH
SETTING
SETTINGS
1
2
3
4
5
6
7
Table 2: 30 WATT SETTINGS
SWITCH
SETTING
SETTINGS
1
2
3
4
5
6
2
70V
25V
TAP
TAP
SETTINGS
0.25
--
0.50
--
0.90
--
1.80
.225
3.80
.475
7.50
.93
15.0
1.87
70V
25V
TAP
TAP
SETTINGS
1.2
.15
2.5
.31
5.0
.62
7.5
.93
15.0
1.87
30
3.75
947167
