Characteristic
Operating temperature
Operating humidity
Operating altitude

Power requirements

Characteristic
Power source voltage
Power source frequency
Power consumption
CAUTION: A ground connection through the power cord grounding conductor is essential for safe operation.

Installation

Powering the oscilloscope

Grounding the oscilloscope is necessary for safety and to take accurate measurements. The oscilloscope must share the same ground as
any circuits that you are testing. You connect the oscilloscope to ground by plugging the three-pronged power cord into an outlet grounded
to earth ground.
To power the oscilloscope on:
1. Connect the power cord supplied with the instrument to the oscilloscope power connector.
2. Connect the power cord to the appropriate AC main source.
3. Push the front panel Power button.
Description
0 °C to +50 °C, with 5 °C/minute maximum gradient, noncondensing, up to 3000 meter altitude
5% to 95% relative humidity (% RH) up to +30 °C
5% to 60% RH above +30 °C up to +50 °C, noncondensing
Up to 3000 meters (9842 feet)
Description
Full Range: 100 to 240 VAC RMS ±10%, Installation Category II (covers range of 90 to 264 VAC)
Sine wave crest factor must be between 1.30 and 1.41.
47 to 63 Hz over entire source voltage range. 360 to 440 Hz, 100 to 132 VAC RMS Source Voltage.
All models: 80 W maximum
Installation
