POWER-SOURCE REQUIREMENTS

The instrument may be operated on 100, 115, 120, 200,
230, or 240 V ac, from 48 to 440 Hz, or from a +12 or +24
V dc source.
The 115 to 230 V Line-Voltage and Regulating Range
Selectors are located on the rear panel, as shown in Fig. 2.
The AC-DC Selector switch is located on the right-side
panel, as shown in Fig. 3.
Fig. 2. L in e V o lta g e and Range S electo r sw itches.
2

AC Power Source Selection

This instrument may be damaged i f operated
with the Line-Voltage and Regulating-Range
Selector switches set fo r the wrong applied
line voltage.
To convert from one nominal line-voltage range to the other,
move the Line-Voltage and Regulating-Range Selector
Fig. 3. A C -D C S elector and DC P ow er-Source in p u t.
314 Operators @
