SIXTY0
DIRECT-VENT LOG SET KIT
PART: LGS-60
INSTALLATION MANUAL
ONLY FOR USE ON SÓLAS MODELS: 60N-SSL, 60P-SSR, 60N-ST, 60P-SSL, 60P-SSR, 60P-ST
SÓLAS BIRCH LOG SET KIT
WARNING
This log set kit shall be installed by a qualified service agency in
accordance with the manufacturer's instructions and all applicable
codes and requirements of the Authority Having Jurisdiction. If
the information in these instructions is not followed exactly, a fire,
explosion or production of carbon monoxide may result causing
property damage, personal injury or loss of life. The qualified
service agency is responsible for the proper installation of this kit.
The installation is not proper and complete until the operation of the
converted appliance is checked as specified in the manufacturer's
instructions supplied with the kit.
NOT FOR USE WITH VENT-FREE OR OUTDOOR FIREPLACES
INSTALLER: Leave this manual with appliance | CONSUMER: Retain this manual for future reference
1
solasfires.com
Advertisement
Related Manuals for Solas SIXTY0
Summary of Contents for Solas SIXTY0
- Page 1 SIXTY0 DIRECT-VENT LOG SET KIT PART: LGS-60 INSTALLATION MANUAL ONLY FOR USE ON SÓLAS MODELS: 60N-SSL, 60P-SSR, 60N-ST, 60P-SSL, 60P-SSR, 60P-ST SÓLAS BIRCH LOG SET KIT WARNING This log set kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable...
-
Page 2: Kit Contents
• METAL LOG SET BURNERS BURNER SUPPORT LOCATIONS Unless the SIXTY0 Slim-Line Built-In Gas Fireplace was originally ordered with the Birch Log Set, your fireplace will have shipped from the factory with Glass Media burners in place. Before installing the log set burners, you will need to remove the glass burners. -
Page 3: Log Set Installation
LOG SET INSTALLATION 3. Remove pilot hood. 4. Lift the end of each burner up and move towards the end of the firebox until the burner inlet tube is off of the burner orifice. Lift the burner out of the fireplace. 5. - Page 4 LOG SET INSTALLATION 7. Install the left logset burner within the firebox by lowering the burner into the firebox. (while keeping the burner pressed toward the left side of the firebox) then sliding the burner right towards the center of the firebox to engage the burner orifice.
- Page 5 LOG SET INSTALLATION 8. Install the right logset burner within the firebox by lowering the burner into the firebox. (while keeping the burner pressed toward the right side of the firebox) then sliding the burner left towards the center of the firebox to engage the burner orifice.
- Page 6 INTALLATION OF BIRCH LOG SET > Start HERE if the SIXTY0 Slim-Line Built-In was originally ordered with a Log Set Burner 10. Install the 3-rock cluster on the 2 pins located to the right of the pilot assembly as shown below in Figure 10.
- Page 7 LOG SET INSTALLATION 12. Install the single rock as shown below in Figure 12 on the 2 pins projecting up from the rear edge of the burner top, left of the center log installed in Step 11. 13. Install the pair of single rocks as shown in Figure 13 on the 2 sets of pins projecting up from the left side of the left burner as shown in below right image (Figure 13).
- Page 8 LOG SET INSTALLATION 15. At the midpoint of the left burner, centered between the rock and log features installed during steps 10-14, are 2 pins to locate the rock shown in Figure 15-A. Note the orientation of the tab on the top surface of the rock (identified by the arrow in Figure 15-A).
- Page 9 It is ok if small amounts of lava rock are lost over the edge of the burner. Installation of the Birch Log Set is now complete, refer to the SIXTY0 Installation and Operation Manual for instructions on final assembly and lighting of the appliance.
- Page 10 We recommend that our gas hearth products be installed and serviced by professionals who are certified in the U.S. by the National Fireplace Institute® (NFI) as NFI Gas Specialists. www.NFIcertified.org RECORD YOUR PRODUCT INFORMATION Model #: ________________________ Serial Number: ______________________________ Date Purchased: __________________ Date Installed: _______________________________ THANK YOU FOR CHOOSING solasfires.com...
