Features
Simple and low cost
•
4 channel receiver module
•
Range up to 500 metres
•
4 digital input/outputs
•
Minimal external components
•
Secure data protocol
•
Ultra low power 1.8—3.6V
•
Easy pairing process
•
869.5MHz spot frequency
•
+13dBm transmit power
•
SMT or SIL package
•
Incorporates self test mode
•
CE compliant for EU licence free use
•
Description
The KAPPA-T receiver module provides a reliable radio link directly compatible
with any of the RF Solutions handheld transmitter range on 868MHz such as
the compact FOBBER key fob, the multi-buttoned ELITE-T8 as well as the long
range ELITE-XT and the rugged, industrial SABRE.
KAPPA-T868 can be used with the BRAVO-T868 as a module to module
solution.
Ordering Information
Part No
KAPPA-T868
KAPPA-T868-SO
Smart Radio Telemetry Module
Radio telemetry module SIL package 868MHz band
Radio telemetry module SMT package 868MHz band
DS-KAPPA-T868-2
KAPPA-T868
Applications
Remote control
•
Sensors
•
I/O Telemetry devices
•
Remote switching
•
Remote traffic lights
•
Description
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for RF SOLUTIONS DS-KAPPA-T868-2
Summary of Contents for RF SOLUTIONS DS-KAPPA-T868-2
- Page 1 Description The KAPPA-T receiver module provides a reliable radio link directly compatible with any of the RF Solutions handheld transmitter range on 868MHz such as the compact FOBBER key fob, the multi-buttoned ELITE-T8 as well as the long range ELITE-XT and the rugged, industrial SABRE.
-
Page 2: Pin Description
Solutions transmitters. Operating range will be dependent on the transmitter used. The versatile KAPPA-T868 module is able to be used to create systems which are module to module (using BRAVO-T868 or as a receiver for existing RF Solutions range of 868MHz transmitters such as:... - Page 3 The LED will illuminate while the button is held and after release will flash 3 times to confirm memory erase is complete. Above assumes LED connection as per schematic example on Page 5 Outputs Outputs are LVTTL / LVCMOS at Vcc and are Active high. DS-KAPPA-T868-2...
- Page 4 Bit1 shows learn status of Tx - where 1 = Learnt Bespoke versions Customised versions of the all transmitters, receivers and chipsets are available to provide a bespoke remote chipset for OEM applications. Please contact our sales or support teams for further information. DS-KAPPA-T868-2...
- Page 5 This example shows a KAPPA module receiver with all 4 outputs connected. Note: The external learn switch and learn LED are both shown connected in this example. KAPPA connected with Serial data output via MAX232 10 11 12 560R Learn 100nF 100nF 100nF 100nF 100nF Data MAX232 DS-KAPPA-T868-2...
-
Page 6: Mechanical Dimensions
RF signal received (from any carrier operating at the appropriate frequency (869.50MHz ). 4 Outputs on being maximum strength. A reset will be required to exit DS-KAPPA-T868-2... -
Page 7: Technical Specifications
Max Current Sourced / Sunk (Total) Parameter Typical Units Operating Temperature Operating Frequency 869.5 Operating Freq for 915MHz version 915.00 915.27 Operating Temperature KAPPA- Rx Sensitivity -121 Temperature Time from TX button press to output activation Minimum on time for outputs DS-KAPPA-T868-2... - Page 8 It also has an auto shut off feature for battery saving. Recommended Antenna 868MHz We have a range of antennas on 868MHz that are suitable for use with the KAPPA modules. To view our range please visit our website: www.rfsolutions.co.uk DS-KAPPA-T868-2...
- Page 9 RF Solutions Ltd shall not be liable for any loss or damage caused as a result of user’s own determination of how t o deploy or use RF Solu- tions Ltd’s products.
