Summary of Contents for LumiRing AIR CR
- Page 1 AIR CR Network Access Controller RFID Reader MANUAL Lumiring.com...
-
Page 2: Table Of Contents
One door. Control of passage of one direction with galvanic isolation................... 7 Using Bluetooth keys AIRKEY................................ 7 MACS Lite app and AIR CR ................................ 7 Using Bluetooth keys AIRKEY to control passage in two directions..................7 System installation recommendations ............................8... -
Page 3: Purpose And General Information
AIR CR programming can be carried out from the Mobile Access Control System "MACS Lite" or the cloud service "UNIMACS". Initial settings are made through the built-in AIR CR site. Always install the latest firmware with every new installation. -
Page 4: Description Of Connection Methods
Description of connection methods A wired interface is used to connect the AIR CR to any peripheral or executive equipment. Figure 1 - Color designation of interface wires Hard reset To reset the device to factory settings, you must: 1. Remove power from the device. -
Page 5: Specifications Air Cr
Specifications AIR CR Parameter Value Electrical Supply voltage 9-24 V Average rated current consumption (at voltage 12V): - No load output, not more 0,11А Maximum current consumption (at voltage 12V): - No load output, not more 0,5А Maximum switching current: - Output 1 (Lock) 3А... -
Page 6: Typical Wiring Diagrams
Typical wiring diagrams One door. Control of the passage of one direction. Figure 2 One door. Control of the passage of two directions. Figure 3 AIR CR 0.18... -
Page 7: One Door. Control Of Passage Of One Direction With Galvanic Isolation
Метод подключения NC или NO выбирается в зависимости от типа замка. Using Bluetooth keys AIRKEY. MACS Lite app and AIR CR Figure 5 Using Bluetooth keys AIRKEY to control passage in two directions. Figure 6 To organize passage in two directions, the... -
Page 8: System Installation Recommendations
Wi-Fi signal strength. The signal strength can be seen on the info page of the embedded site (see the section “Embedded AIR CR website”). The minimum allowable signal level is -75dB. If your signal strength is lower (the value is higher), then this can have a strong impact on the interactivity of the device with a mobile application or cloud service. - Page 9 The diode must be installed directly on the contacts of the lock. Suitable diodes 1N5400, 1N5408, 1N5821, HER301 and similar. Varistors can be used instead of diodes, for which polarity is not required. Varistors VCR-07D101K S07K60, TVR07101, GNR-07D101K or similar are suitable. Mounting template for marking Figure 19 AIR CR 0.18...
