Summary of Contents for LumiRing AIR-B
- Page 1 AIR-B No-Touch Button Manual...
- Page 2 Device settings ..........................4 The IR Remote buttons description ..............4 Indication ........................... 4 Proximity distance settings ..................5 Door open delay settings ..................5 Output mode settings ....................5 Buzzer settings ........................5 Save settings ......................... 5 AIR-B V2.0...
-
Page 3: Specifications
Door open delay, s 0.1/3/6/9 1. Open collector 1A Output Operational (D)60x(H)15 mm Overall dimensions (D)2,36x(H)0,59 ft -30 ~ + 70 С Working temperature range -22 ~ 158 F IP Protection Level IP65 Enclosure material ABS Fire Retardant AIR-B V2.0... -
Page 4: Device Settings
Default value: 4 (minimal distance 12 cm) Button «2» - The Door opens delay settings Default value: 2 (3 sec) Button «3» - The Output work mode settings Default value: 1 (NO) Button «4» - The Buzzer settings Default value: 2 (Buzzer On) Indication AIR-B V2.0... - Page 5 After setting the parameter, you must see a blink indication according to the parameter sector of the device. The device is in waiting mode. To confirm settings change, press the Sharp button « ». To exit from settings mode, press start « ». AIR-B V2.0...
