Summary of Contents for LumiRing AIR-B
- Page 1 2024-03-21 V 4.0 MANUAL AIR-B (V3.0 Five Wire)
-
Page 2: Table Of Contents
• Structure of the Setup Menu • Connection Diagram: ◦ Connection to the ICON-Pro Controller ◦ Connection to the ICON Controller ◦ Connection to the AIR-CR Controller ◦ Connection to the Magnetic Lock • Hardware Reset • For Notes AIR-B... -
Page 3: Introduction
The user or installer is responsible for complying with local laws and privacy regulations when collecting personal data while using the product. AIR-B... -
Page 4: Device Specifications
IP 65 • 4", 8", 12" or 20" (10, 20, 30, 50 cm) Indication: • Two color LEDs, buzzer Default Device Settings Distance: AUX GND (work mode): • 4" (10 cm) • Delay: Buzzer: • 0.1 second • Enable AIR-B... -
Page 5: Device Dimensions
Device Dimension 2.125" Front view Side view Standard RFID card size 2.91” Thin mounting ring Thick mounting ring 1.61" Mounting ring front view Optional accessory AIR-B... -
Page 6: Wire Designation
Wire Designation +VDC Black Yellow AUX Out Green Reserved Blue G LED AIR-B (V3.0 Five Wire) +VDC Black Blue AUX Out Green G LED AIR-B (V2.0 Four Wire) AIR-B... -
Page 7: Installation Recommendations
• If the laser sensor is dirty or an obstacle is detected, the unit will activate a light and sound an alarm. • In case of contamination, gently clean the surface of the button, first with a damp cloth and then with a dry cloth. AIR-B... -
Page 8: Structure Of The Setup Menu
Structure of the Setup Menu Distance Open Delay AUX GND Mode Buzzer 3.93" (10 cm) 0.1 seconds NC (normally closed) Disable 7.88" (20 cm) 3 seconds NO (normally open) Enable 11.81" (30 cm) 6 seconds Mode Select 19.68" (50 cm) 9 seconds AIR-B... -
Page 9: Connection Diagram
Connection to the ICON-Pro Controller 15.4W TYPE-C LAN PoE+ STATUS +VDC Black 12/24 Yellow AUX Out CONT. 2 Green Reserved Blue G LED REX 2 +VDC BUZZER G LED CONT. 1 REX 1 +VDC AIR-B BUZZER (V3.0 Five Wire) G LED WWW.LUMIRING.COM ICON-Pro AIR-B... -
Page 10: Connection To The Icon Controller
Green Reserved Wi-Fi MODE Blue G LED REX 1 CONT. 1 +VDC OUT GND AIR-B 15.4W (V3.0 Five Wire) LAN PoE+ ICON Connect the blue wire coming from the proximity button to the LED pin of the Wiegand port. AIR-B... -
Page 11: Connection To The Air-Cr Controller
Connection Diagram Connection to the AIR-CR Controller +VDC Black Orange G LED Blue EXIT AIR-CR AIR-B (V3.0 Five Wire) +VDC Black EXIT Yellow G LED Blue • The wire colors of the cable connecting the controller to the proximity button may vary in reality, and are given as an example. -
Page 12: Connection To The Magnetic Lock
AUX GND Green Blue • Specify the NC (normaly close) type in the AUX GND mode AIR-B settings to control the magnetic lock. • Specify the NO (normaly open) type in the AUX GND mode (V3.0 Five Wire) settings to control the electric latch. -
Page 13: Hardware Reset
3. Wait for the device to emit one short beep and a long beep for 5 seconds. 4. Release the buttons immediately after the beep ends. 5. Disconnect the unit from the power source and reconnect it. 6. The hardware reset is complete. The device is ready for operation. AIR-B... -
Page 14: For Notes
For Notes AIR-B...
