Summary of Contents for LumiRing ICON-PE

  • Page 1 ICON-PE 2 Doors Network Access controller. Wi-Fi+Ethernet+POE supported Manual...
  • Page 2: Table Of Contents

    One door. Two directions. Wet mode. _____________ 12 Two doors. One direction. Wet mode. _____________ 12 WEB-BASED INTERFACE ___________________________ 13 Main network settings ___________________________ 13 Local Wi-Fi Access point settings _________________ 14 Cloud Connection settings _______________________ 14 Maintenance __________________________________ 15 Security _______________________________________ 15 v.4.0 ICON-PE...
  • Page 3: Purpose And General Information

    All inputs can work both for closing and opening, depending on the settings in the access control system The ICON-PE controller is designed to work as part of the UNIMACS cloud access control system. There is a specialized version of the controller for integrators and developers; it has a limited set of commands (SimpleAPI) and can be very easily integrated into any ACS.
  • Page 4: Specifications

    * Maximum identification time, with the number of keys 10,000 - no more than 1.5 s. The controller can work with a large number of user keys, which will lead to an increase in the identification time. v.4.0 ICON-PE...
  • Page 5: Indication Description

    If your actuator needs a different power supply. To use external power, select DRY and use NO or NC and C, and wire to the external supply. That gives a possibility to control the actuators (lock and etc.), which use different power sources. v.4.0 ICON-PE...
  • Page 6 NC and GND (for fail-safe locks). In this work mode, relay out works in the same algorithm as open collector out. If you need more examples about relay modes, please study the chapter «Typical wiring diagrams.» v.4.0 ICON-PE...
  • Page 7: Hardware Reset

    3. Install the RESET jumper 4. Power ON the device. Wait for indicator D4 to turn on. 5. Remove the RESET jumper Description of connection ICON-PE terminal block description Figure 2. Factory Network settings Интерфейс Параметр SSID: LR_ICONxxxx, where хххх is device serial number...
  • Page 8: Installation Recomendation

    The maximum permissible load on the built-in POE module in the ICON-PE model is no more than 1.5A 12V. Your POE equipment should be capable of delivering 30W of power.
  • Page 9: Rs485 Connection

    The controller supply line wires should be kept as short as possible in order to avoid significant voltage drops across them. After laying the wires, make sure that the supply voltage of the controller with the locks turned on is not lower than 12 V. v.4.0 ICON-PE...
  • Page 10: Protective Diode

    1N5821, HER301, and similar. Instead of diodes, varistors can be used, for which there is no need to observe polarity. Varistors VCR-07D101K S07K60, TVR07101, GNR-07D101K, or similar are suitable. Heavy load switching Figure 7. Example of using a 12V relay for switching a load exceeding the output parameters. v.4.0 ICON-PE...
  • Page 11: Typical Wiring Diagrams

    Relay is used in the "Wet Contact" operating mode. Figure 8. Dry mode. With an additional apart power source for the lock. Figure 10. Different power supply Figure 9. Relay in "Dry contact" mode. for the lock. v.4.0 ICON-PE...
  • Page 12: One Door. Two Directions. Wet Mode

    2022 One door. Two directions. Wet mode. Figure 11. Two doors. One direction. Wet mode. Figure 12. v.4.0 ICON-PE...
  • Page 13: Web-Based Interface

    2022 WEB-BASED INTERFACE The initial configuration of ICON-PE is done through the web-based interface. To connect to the interface, the User must connect to the device's Wi-Fi access point, which has the "ICON" prefix and does not have a password. After connecting to the device, the User must enter the factory IP address of the controller - 192.168.4.1 in the browser line.
  • Page 14: Local Wi-Fi Access Point Settings

    SSID name (3) and SSID password (4) during the initial setup. Cloud Connection setting The ICON-PE controller is designed to work as part of the UNIMACS ACS but can also be used with any third-party service based on the MQTT service.
  • Page 15: Maintenance

    This menu is used to change the login and password for access to the built-in website of the device. Enter new login name (1) Enter the old password (2) Enter a new password (3) Repeat new password (4) v.4.0 ICON-PE...
