- Page 1 Device version before revision MANUAL Instr 1.7 Fw. v. 1.107 July 2023...
-
Page 2: Table Of Contents
Wire Designation Installation Recommendations Wiegand Interface (Connection Diagram) Wiegand Interface with Additional Power Supply (Connection Diagram) Open Supervised Device Protocol Reader via RS-485 (Connection Diagram) Connecting to the Built-in Wi-Fi Access Point Login System Network Main Maintenance For Notes AIR-R Pro... -
Page 3: Introduction
Introduction This document provides detailed information on the AIR-R Pro reader device structure and steps for installing and connecting it. It also includes instructions for preventing or troubleshooting many common problems. This guide is for informational purposes only, and in the event of any discrepancies, the actual product takes precedence. -
Page 4: Device Specifications
Device version before revision Device Specifications Device info • Model AIR-R Pro • Processor ESP32-S3 • Over-the-air (OTA) update • Built-in web server • Support for 125 kHz identifiers EM-Marin • Support for 13.56 MHz identifiers MIFARE DESFire; MIFARE Plus; MIFARE Ultra Light;... -
Page 5: Device Dimensions
Device Dimensions RFID CARD 125, 65535 3.375" AIR-R Pro... -
Page 6: Wire Designation
Pink Data Led The current hardware version of the AIR-R Pro reader has more wires than is needed for installation and use. This is necessary for future improvements and extensions of the device. The wires required to connect the AIR-R Pro reader are highlighted in color. -
Page 7: Installation Recommendations
The power supply line wires for the reader should be kept as short as possible to avoid a significant voltage drop across them. After cabling, ensure that the power supply voltage to the reader is at least 12 VDC with the locks switched on. AIR-R Pro... -
Page 8: Wiegand Interface (Connection Diagram)
The voltage level at the power supply and at the reader may differ depending on the cable length and the resistance of the conductor. The recommended voltage should be at least +10 VDC. Use a multimeter in the VDC measurement mode to verify that the power supply voltage meets the recommended requirements. Warning AIR-R Pro AIR-R Pro AIR-R Pro... -
Page 9: Wiegand Interface With Additional Power Supply (Connection Diagram)
BE SURE TO CONNECT THE GND OF THE CABLE FROM THE CONTROLLER TO THE GND OF THE AUXILIARY POWER SUPPLY! Warning DO NOT USE POWER SUPPLIES WITH DIFFERENT VOLTAGE LEVELS! Use a multimeter in the VDC measurement mode to verify that the power supply voltage meets the recommended requirements. AIR-R Pro AIR-R Pro... -
Page 10: Open Supervised Device Protocol Reader Via Rs-485 Connection Diagram
BE SURE TO CONNECT THE GND OF THE CABLE FROM THE CONTROLLER TO THE GND OF THE AUXILIARY POWER SUPPLY! Warning DO NOT USE POWER SUPPLIES WITH DIFFERENT VOLTAGE LEVELS! Use a multimeter in the VDC measurement mode to verify that the power supply voltage meets the recommended requirements. AIR-R Pro AIR-R Pro... - Page 11 The nominal resistance of the resistors corresponds to the wave impedance of the cable, and for a twisted-pair cables is typically 100 to 120 ohms. Warning Install a 120 ohm terminating resistor on the outermost reader if the cable runs more than 150 feet. See RS-485 interface specifications for more information. AIR-R Pro...
-
Page 12: Connecting To The Built-In Wi-Fi Access Point
Connecting to the Built-in Wi-Fi Access Point You can use a smartphone, tablet, or other Wi-Fi capable device to connect to the AIR-R Pro. To connect to a device, follow these steps: Step 1: Connect the device to a power source using the wiring diagram provided in the technical documentation. -
Page 13: System
• The Network Information subsection (API) version used by the device. shows the current network settings used by the unit: ◦ Network address of the device. ◦ Network mode - Manual or Dynamic Host Configuation Protocol (DHCP). ◦ Network mask. ◦ Gateway. AIR-R Pro... -
Page 14: Network
Wi-Fi AP is always active. • When the checkbox is unchecked, the set timer for turning off the built-in AP Wi-Fi becomes available. • In the Local Wi-Fi AP Name field, you can change the device's factory name to your own. AIR-R Pro... -
Page 15: Main
MHz identifiers. code is read from the reader connected to • Check the Copy Protection checkbox to the controller. use the 13.56 MHz format ID verification Note: Byte order will be reversed for all identifier types. mode for authenticity. AIR-R Pro... -
Page 16: Maintenance
• Pressing the Restart button will restart the device. This action does not affect the data on the device. • Pressing the Partial Reset button deletes all data from the device memory except for the network settings for connecting to the Internet. AIR-R Pro... -
Page 17: For Notes
For notes AIR-R Pro www.lumiring.com...
