Commissioning
• Refit to front cover to the product using the supplied
screws.
Operational check
• Please note that the unit will not illuminate in
emergency mode until the mains has been switched
on and subsequently failed.
• Restore the mains supply for at least 30 minutes and
then turn it off. The LED lamp should illuminate for at
least 30 seconds.
Fitting/replacing bulbs
• The LED's in this product are non replaceable.
Care and cleaning
We recommend cleaning with a soft dry cloth.
Do not use solvents or abrasive cleaners as these could
damage the finish.
Recycling advice
Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or retailer for recycling advice.
Safety information
Under no circumstances must the connecting lead be modified for use as a power lead. This would make the
exposed input socket live. For your safety, always switch off the supply before cleaning.
www.saxbylighting.com
• Replace fuse or circuit breaker and switch on. Your
light is now ready for use.
• Switch on the Mains Supply and note the indicator
LEDs on the side of the unit have illuminated. This
indicates that the unit is operating correctly e.g. the
lamp continuity is correct and that the battery is being
charged.
• The unit has built in High Discharge Protection and
this should operate when the battery voltage fails to
approximately 8V DC, whilst in emergency mode
Iss.2 20112015
Saxby Lighting Ltd. BH23 3PE
Instruction leaflet
Panther Wall
52016
Advertisement
Related Manuals for Saxby Lighting Panther Wall 52016
Summary of Contents for Saxby Lighting Panther Wall 52016
- Page 1 Commissioning Instruction leaflet • Refit to front cover to the product using the supplied • Replace fuse or circuit breaker and switch on. Your screws. light is now ready for use. Panther Wall 52016 Operational check • Please note that the unit will not illuminate in • Switch on the Mains Supply and note the indicator emergency mode until the mains has been switched LEDs on the side of the unit have illuminated. This on and subsequently failed. indicates that the unit is operating correctly e.g. the lamp continuity is correct and that the battery is being • Restore the mains supply for at least 30 minutes and charged. then turn it off. The LED lamp should illuminate for at least 30 seconds. • The unit has built in High Discharge Protection and this should operate when the battery voltage fails to approximately 8V DC, whilst in emergency mode Fitting/replacing bulbs • The LED's in this product are non replaceable. Care and cleaning We recommend cleaning with a soft dry cloth. Do not use solvents or abrasive cleaners as these could damage the finish.
- Page 2 Installation Thank you for purchasing this light fitting. Please read the instructions carefully before use to ensure safe and satisfactory operation of this product. Please retain these instructions for future reference. Existing fittings must be completely removed before plugs (suitable for masonry only - for other surfaces installation of a new product. Before removing the use appropriate fixings). Fix product to the wall using existing fitting, carefully note the position of each set the supplied screws. Take care to avoid damaging Warning of wires. any concealed wiring and pipes. • Undo the two screws that hold the front cover and • Pierce a hole in the rubber grommet at either side This light fitting is Class 1 and must be connected to This light fitting should be connected to a fused circuit. remove the lid by lifting and sliding it out. of the product and feed the incoming supply cable an Earth circuit through it.
