OPERATING INSTRUCTIONS
TOA INTERCOM SYSTEM
TELEPHONE LINE INTERFACE
TD-600
Please follow the instructions in this manual to obtain the optimum results from
this manual.
We also recommend you to keep this manual handy for future reference.
TOA Corporation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TD-600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Toa TD-600

Summary of Contents for Toa TD-600

  • Page 1 All manuals and user guides at all-guides.com OPERATING INSTRUCTIONS TOA INTERCOM SYSTEM TELEPHONE LINE INTERFACE TD-600 Please follow the instructions in this manual to obtain the optimum results from this manual. We also recommend you to keep this manual handy for future reference.

  • Page 2: Table Of Contents

    Installation Specifications Accessories GENERAL DESCRIPTION By using the TD-600 telephone interface in conjunction with TOA' s intercom exchange, a pushphone (*DTMF) can be used as a handset intercom station. Two pushphones can be connected per interface. DTMF=Dual tone multi-frequency – 2 –...

  • Page 3: Part Description

    All manuals and user guides at all-guides.com PART DESCRIPTION [Front view] Power indicator CH1 telephone CH2 telephone hook-off indicator hook-off indicator [Rear view] Power supply terminal Earth terminal (Be sure to ground.) CH2 intercom line terminal CH2 telephone line terminal CH1 intercom line terminal CH1 telephone line terminal –...

  • Page 4: Connections

    All manuals and user guides at all-guides.com CONNECTIONS 1. Power connection TD-600 24V DC power supply [AD-242A ( 2 . 5 A ) etc] 2. Intercom line connection 2.1 When using EXES-6000 exchange TD-600 CH2 intercom line terminal CH1 intercom line terminal Twisted pair cable etc.

  • Page 5: Telephone Line Connection

    All manuals and user guides at all-guides.com When using EX-200 exchange TD-600 CH2 intercom line terminal EX-200 exchange intercom line terminal LM-20 Twisted pair cable etc. Perform jumper wire settings as instructed in page 9. Note: Telephone line connection TD-600...

  • Page 6: Facsimile Connection

    Usable facsimiles are restricted that selecting signal is transmitted a pushphone. EXCHANGE DIP SWITCH SETTING AND PROGRAMMING All the lines or exchanges to connect the TD-600 should be set to the continuous call tone. 1. When using EX-200 exchange Perform the handset station registration with the station No. 24.

  • Page 7: Signal Mode Adjustment And Setting

    All manuals and user guides at all-guides.com SIGNAL MODE ADJUSTMENT AND SETTING Perform the signal mode setting before the final installation or wiring work because the setting requires the removal of the top cover. Remove side plate screws (four places). Detach the top cover.

  • Page 8: Adjustment Of Current Supplied To Telephone

    All manuals and user guides at all-guides.com 2. ADJUSTMENT OF CURRENT SUPPLIED TO TELEPHONE The distance between the TD-600 and telephone can be made greater by making switch positions of both SW1 and SW2 identical to adjust the current to be supplied to the telephone.

  • Page 9: Jumper Wire Connection

    All manuals and user guides at all-guides.com JUMPER WIRE CONNECTION (When using the EX-200 exchange) Referring to Table 1, change settings of jumper wires JP1-JP3. All jumpers are factory-preset to the EXES-6000' s settings. Table 1 Exchange EXES-6000 EX-200 Jumper Jumper installed Cut jumper J P 1...

  • Page 10: Polarity Reverse Signal Control

    All manuals and user guides at all-guides.com 4. POLARITY REVERSE SIGNAL CONTROL When connecting the telephone line terminal to equipment that must not receive the polarity reverse signal, install the jumper wire in place marked with JP4 in the figure. Jumper JP4 is not factory-preset because the polarity reverse signal is set to transmit from the CH1 or CH2 telephone line terminal.

  • Page 11: Installation

    All manuals and user guides at all-guides.com INSTALLATION Rack mounting Attach supplied brackets to the TD-600 to mount it in the rack. M3 Washer M3 Binding head screw M5 Rack mounting screw Rack mounting bracket Fiber washer Unit can not be built in the inside of EX-610/620 exchanges.

  • Page 12: Specifications

    3 . 3 k g ( 7 . 3 l b . ) ACCESSORIES Rack mounting bracket Rack mounting screw (M5x12 tapping screw) Fiber washer Binding head screw (M3x6) M3 washer Rubber foot Installation manual TOA Corporation KOBE, JAPAN 133-06-171-00...
