Sim-Lab EVO Instruction Manual page 3

500MM Corner M8 X 16 Slot-Nut M8
Parts re-used (R) from your existing
Bracket (re-used) (re-used)
(re-used)
GT1-EVO build.
The corner brackets are from the Front
Mount hardware kit since they need to
retain their aligning tabs.
Brackets from your existing GT1-EVO build
with their tabs broken off, can be re-used
1X 4X 4X
4X
as well. We'll show this on Page 6.
