4. SCREEN & KEYPAD
TFT screen
On / Off button
ecrease temperature /
Go down button
Main menu button
1 Selected temperature
2 Current time and day
3 Heating element on
4 Comfort mode
5 Eco mode
6 Anti-Frost mode
7 Locked buttonpad
BELIZE SHORT DIGITAL RADIATOR WITH WI-FI
Increase temperature
Programming button
/ Go up button
7
6
4
5
9
1
3
8 Manual mode
9 Automatic mode
10 Preset programs mode
11 Hourly programming
WiFi connection
12
indicator
13 Open Windows indicator
Energy consumption
14
indicator
