RP5-GM32
Rear Seat Entertainment (RSE); If equipped
• Press the power button to turn the RSE Controls on. When Radio is displayed on the RSE Controls, the aftermarket radios rear
speaker output will be heard through the headphone jacks. Putting the aftermarket radio into dual zone mode should change the
output level of the rear speakers to a fixed level. This allows precise user adjustment from the level knobs on the RSE Controls
(refer to aftermarket radio owners manual for model specific dual zone operation).
• The seek arrows and PROG button will control the radio as programmed by the SWC interface. These buttons are mapped to
the SWC buttons as stated above.
• Pressing the SRCE button will toggle between the Factory XM tuner and the Radio as the RSE source. Pressing the power
button will turn the RSE Controls off as well as turning the key off. The seek arrows and PROG button will continue to operate as
stated (with the exception of SRCE which has no function) when the Rear Seat Controls are turned off.
Rear Seat Entertainment (RSE); If equipped
1. Vehicles equipped with an overhead screen only:
In this application the GMRVD2 must be used in order to feed A/V into the factory screen from an aftermarket head unit (head
unit must support A/V out). With the GMRVD2, A/V will be passed from the aftermarket head unit to the rear screen and audio
can be heard through the headphones. The GMRVD2 will also pass the Auxiliary inputs on the rear of the center console to the
aftermarket head unit.
2. Vehicles equipped with an overhead screen AND headrest monitors:
In this application the headrest monitors will function independently from the overhead monitor. Neither video or audio
can be passed to or from the headrest monitors. The overhead monitor will function exactly as described in #1.
OnStar Volume Adjustment for Vehicles w/o SWC
1. When OnStar is active use the adjustment dial on the side
of the module to raise or lower the OnStar volume to the
desired level.
Pacific Accessory Corporation
Using the Radios Dual Zone Source
Radio
Change between Controls the
Factory XM tuner Radio as
and Dual Zone Programmed
Radio Source by the SWC
interface (Mapped
to the Arrow
Up Button)
© 2021 AAMP Global. All rights reserved. PAC is a Power Brand of AAMP Global.
PAC-audio.com
Steering Wheel Control and Telematics Retention
Turns the Controls the Controls the
Rear Seat Radio as Radio as
Controls On Programmed Programmed
or Off by the SWC by the SWC
interface (Mapped interface (Mapped
to the Arrow to the Arrow
Down Button) and Bar Button)
Adjustment Dial
Radio Replacement Interface with
For select General Motors Vehicles
With 29 Bit Data Systems
Rev: V1
Date:
12/17/2021
Page 5
