Table of Contents
- 1 Install the Pedal into the Crank Arm
- 2 Ensure that the 4Iiii Crank Is up to Date
- 3 Download the 4Iiii App from the Appropriate App Store
- 4 Record the ANT+ ID of the Powermeter that Needs to be Updated
- 5 Open the 4Iiii App and Initiate a Crank Arm Scan
- 6 Spin the 4Iiii Crank Arm of the Target Bike >30 RPM
- 7 Once 4Iiii Is Selected the Console will Enter the Pairing Process
- 8 Once the ANT+ ID Has Been Entered, Pedal the Bike
- Download this manual
Advertisement
Table of Contents
Related Manuals for Schwinn 4IIII
Summary of Contents for Schwinn 4IIII
- Page 1 CORE HEALTH & FITNESS 4IIII POWERMETER INSTALL MANUAL...
- Page 2 Use a small phillips screwdriver to remove the screw securing the battery cover, remove the battery cover, then install the batteries. Once the batteries are installed, replace the cover and screw. Fig. 1 Ensure that the rider’s right crank arm is at the 6 o’clock position then push the crank onto the bottom bracket at the 12 o’clock position.
- Page 3 Ensure that the 4iiii crank is up to date. To do this, check that Bluetooth is enabled on the phone then follow the proceeding directions. Fig. 4 Android Fig. 5 Download the 4iiii app from the appropriate app store BUT DO NOT CREATE A LOGIN.
- Page 4 NOTE: The ANT+ ID is a 4 OR 5 digit number located on the underside of the 4iiii sensor. If the number is 4 digits, the fi rst number of the ANT+ ID is zero (0).
- Page 5 Spin the 4iiii crank arm of the target bike >30 RPM; the 2-5 digit ANT+ ID should show up on the “Bluetooth Scan” screen. Tap on the checkmark to select the crank arm then tap on “Connect”. Fig. 9 After connecting to the crank arm, open the settings menu.
- Page 6 “4iiii” is displayed as the sensor type. If the sensor type is set to “Echelon 2” press the back-light button to select the sensor type, use the AVG/MAX button to select “4iiii” then press the back-light button again. Page 5...
- Page 7 Once “4iiii” is selected the console will enter the pairing process, check the side of the power sensor for a 4 OR* 5-digit ANT+ ID code. Enter this code on the “ENTER ANT ID” screen using AVG/MAX to scroll and the Fig.
- Page 8 PART NUMBER 620-8543, REV L All rights reserved. Star Trac, the Star Trac logo and StairMaster are registered trademarks of Core Health & Fitness, LLC. Schwinn and Nautilus are registered trademarks of Nautilus Inc. used under license to Core Health & Fitness LLC. Throwdown is a registered trademark of Throwdown Industries, LLC.
