- Page 1 SuperReel ™ Operator’s HandBook w w w . t t i . c o m . a u Manufacturer of “The Safest Tanks in Motion”...
-
Page 2: Table Of Contents
General Safety Instructions General Information Specifications Description Machine Limitations Driving Stability SuperReel Operating Instructions Before first use Filling the SuperReel Sprayer Tank Operating Instructions Petrol Pump Operation Clean-up and Decontamination Maintenance Periodic Checks Maintenance Tasks Maintenance Schedule SuperReel Remote Control Pairing... - Page 3 All TTi SuperReel sprayer tanks are rotationally moulded from quality polyethylene, purpose designed and manufactured to high standards. The SuperReel sprayer is a slip-on unit for the back of a utility or trailer and designed for herbicide or pesticide spraying.
-
Page 4: Safety
SuperReel™ Product HandBook Safety This manual is intended for use by personnel experienced in the use of this and similar equipment. Read and understand this manual before attempting to operate or perform routine maintenance on this equipment. Your safety is of prime priority. -
Page 5: General Safety Instructions
Australian Standard for Respiratory protection devices AS1715 8. Ensure the capacity of the vehicle is suitable for the loaded mass of the SuperReel sprayer. Refer to the vehicle’s operator manual for safe working loads, correct securing points and relevant safety instructions. Do not exceed the carrying and braking capacity as specified by the vehicle manufacturer. -
Page 6: General Information
Remote control auto rewind SuperReel with 150m FrictionFree™ nylon hose and Turbo spray gun Description The TTi SuperReel sprayer is designed to carry and distribute herbicides, pesticides or water using a self- contained petrol driven pump, refer to Figure 1. The SuperReel sprayer is configured in two different styles: •... - Page 7 The electrically operated SuperReel hose reel contains 100m of FrictionFree™ hose connected to a trigger actuated Turbo spray gun with adjustable nozzle. The hose is pulled out manually from the SuperReel and electrically retracted using the supplied remote control. An Anderson plug is fitted to the rear of the SuperReel, ready for connection to a 12-volt power supply.
-
Page 8: Machine Limitations
Product HandBook Pump Options The SuperReel sprayer is fitted with a Honda GX200 petrol pump coupled to a Bertolini pump. The pump is rated for 34 L/min for the Single SuperReel sprayer, and 54 L/min for the Twin SuperReel sprayer unit. -
Page 9: Superreel Operating Instructions
Product HandBook SuperReel Operating Instructions Before first use Your SuperReel Field Sprayer is delivered fully assembled and ready to be fitted onto the vehicle. Before use, it needs to be set up using the following instructions: • Complete the warranty registration online at www.tti.com.au/warranty-registration, or use the Warranty Registration Card at the back of this handbook. -
Page 10: Filling The Superreel Sprayer Tank
Follow the instructions provided with the chemicals or the applicable Safety Data Sheet. Mixing and filling the SuperReel sprayer should be undertaken at a carefully chosen site, away from any risk of spillages draining into water courses or into environmentally sensitive areas. Children and animals must always be kept away from mixing and filling operations. -
Page 11: Operating Instructions
SuperReel™ Product HandBook Operating Instructions The SuperReel sprayer is started and operated as follows: WARNING: Suitable PPE must be worn by the operator when conducting hose spraying operations. WARNING: Do not spray in windy conditions, where spray drift contamination may occur. - Page 12 • Pull the hose to unwind it from the SuperReel. For the twin SuperReel sprayer, if both hoses are to be used, pull the hose to unwind it from the second SuperReel. •...
-
Page 13: Petrol Pump Operation
To retract the hose, apply a little tension to the hose, to ensure the hose does not flip off the spool upon starting. • Press the button on the remote control supplied with the SuperReel to start retracting the hose, refer to Figure 5. The hose will wind on to the reel’s spool, guided by the integrated fairlead. •... -
Page 14: Clean-Up And Decontamination
• When the engine needs to be stopped, turn the ignition switch to the OFF position. If the SuperReel sprayer is not going to be used within the next few hours, shut the system down as follows: • Set the engine throttle lever to the idle position. -
Page 15: Maintenance
Ensure that the tank’s basket strainer is free from chemical residue or debris. If the SuperReel sprayer is to be stored for an extended period, thoroughly clean and decontaminate the unit as described above. Ensure it is allowed to dry, the tank and all lines are empty and not pressurised, then store it in a well ventilated area. -
Page 16: Maintenance Tasks
The frequency of these activities will depend on the nature of the operating environment and the operational hours of the SuperReel sprayer unit but as a minimum, the following tasks should be undertaken annually. Pump System •... - Page 17 TTi recommends photocopying these schedules in order to keep a detailed log of all maintenance tasks. A copy of these schedules will be required to support any warranty claim. Daily tasks The following tasks are to be undertaken daily, or prior to each use, of the SuperReel™ sprayer. Task Notes...
- Page 18 Check securing system used to fastener unit to vehicle Check guards and fairlead rollers on SuperReels Check the SuperReel bearings for any noise or friction monthly. * Change pump engine oil (and filter, if fitted) (first...
-
Page 19: Superreel Remote Control Pairing
TTI on 1800 816 277. The replacement unit will be configured for the SuperReel but the operator will need to pair the new remote control unit with the SuperReel. Pairing is the process to obtain a unique assignment between the remote control unit and the SuperReel. - Page 20 Reinstall the receiver unit, the electrical box cover and the back cover in reverse order to removal. • Fully retract the hose onto the SuperReel, allowing enough slack to place the spray gun into its holder. Figure 8 – SuperReel Remote Control Pairing w w w.tti.com.
-
Page 21: Trouble Shooting
SuperReel™ Product HandBook Trouble Shooting If a fault develops with your SuperReel sprayer, the following trouble shooting tables provides guidance to identify and rectify the problem. SuperReel Sprayer Pump Problem Possible Cause Remedy Pump will not prime Insufficient motor speed... -
Page 22: Risk Assessment
SuperReel™ Product HandBook Risk Assessment Task Hazard Risk Control Measure/Mitigation Check weather Manual handling; • Wear PPE as per chemical conditions slips, trips or falls requirements SDS – coveralls, gloves, safety footwear, glasses & respirator • Follow safe manual handling techniques: don’t lift on your own... -
Page 23: Warranty
SuperReel™ Product HandBook Warranty Warranty Policy TTI will, at its option, repair or replace without charge any part covered by this warranty which is found to be defective in material and/or workmanship within one (1) year after date of sale to the original retail purchaser. - Page 24 Scan to view our PDF Handbook online www.tti.com.au 1800 816 277 sa l e s@ tt i.c om.au P O B ox 1 37, N at ha li a , V I C , 3 63 8 M ur ray Va l l ey H w y, N ath a l i a , V I C 363 8 Quality Checked By: Proudly Built By: Signature...
