Ceres – Arm Pad Replacement Instructions

Tools Required:

1 New Arm Pad (P/N 95-3925)

Arm Assembly

1/8" Allen Wrench or Equivalent

1. Push the arm pad to its furthest depth position, with the majority of the arm pad

positioned towards the back of the arm.

2. Adjust the width position of the arm pad to expose the two fasteners on the right side

of the arm pad (see Figure 1 below). Remove the two fasteners with the 1/8" allen

wrench:

56-0125 Rev. A

Page 1

1/8" Allen Wrench

The HON Company

200 Oak Street

Muscatine, IA 52761

800- 833-3964

hon.com

Table of Contents

Do you have a question about the Ceres and is the answer not in the manual?

Page 1 Ceres – Arm Pad Replacement Instructions Tools Required: 1 New Arm Pad (P/N 95-3925) Arm Assembly 1/8” Allen Wrench or Equivalent 1/8” Allen Wrench 1. Push the arm pad to its furthest depth position, with the majority of the arm pad positioned towards the back of the arm.
Page 2 4. Adjust the width position of the arm pad to expose the two fasteners on the left side of the arm pad (see Figure 2 below). Remove the two fasteners with the 1/8” allen wrench: Figure 2 The HON Company 200 Oak Street 56-0125 Rev. A Muscatine, IA 52761...
Page 3 Figure 4 The HON Company © 2011 The HON Company 200 Oak Street H4010 (01/11) 56-0125 Rev. A Muscatine, IA 52761 HON is a registered trademark Page 3 800- 833-3964 of HNI Technologies, under license hon.com to The HON Company.
