- Page 1 MINI CB RADIO USER MANUAL KNOW ABOUT THIS RADIO Squelch control, SQ, ASQ switch key Mode/Scan key RF Gain control CH9/CH19/Keypad lock Power On/Off Volume control External speaker Jack Antenna Jack...
- Page 2 HOW TO USE THIS RADIO Power On/Off the radio Turn VOL switch clockwise to power on the radio, the LCD displays the Norms and then displays channel number. Turn VOL switch anti-clockwise, until hear Ka Ta, the radio is powered off. Volume control Turn clockwise to increase volume, anti-clockwise to decrease volume.
- Page 3 RF Gain contro Short press key, LCD displays R and the present RF gain level flashes. Short press microphone [ UP ] or [ DN ] to change level. Short press key to exit RF gain level control. Note：When RFG function is on the LCD displays R if RFG level is 6 means the attenuation is 6dBm.
- Page 4 SPECIFICATION GENERAL Modulation Mode AM/FM Frequency Range 26.565-27.99125MHz Frequency Tolerance 0.005% Input Voltage 13.2V 104x108x25cm Dimensions(in mm) Weight 416g Ferquency Control PLL Synthesizer Operating Temperature -20℃ to +50℃ Range Transmit with push-to-talk /UP/DN and coiled cord Current Drain Receive 2A MAX VOL Max Squelched 0.3A Weight...
