1.KNOW ABOUT THIS RADIO
6
1
2
3
1
Squelch control, SQ, ASQ switch key
2
Mode/Scan key
3
4
CH9/CH19/Keypad lock/VOX control/VOX setting
5
Power On/Off Volume control
6
LCD
7
External speaker Jack
8
Antenna Jack
Note:
To get the best range from the external whip antenna (50 ) should be used.
Ant : Tx/ Rx 26.965-27.405Mhz ,
0 dBi nominal (3dBi Max)
2.HOW TO USE THIS RADIO
2.1 Power On/Off the Radio
1. Turn VOL switch clockwise to power on the radio, the LCD displays the
Norms and then displays channel number.
2. Turn VOL switch anti-clockwise, until hear Ka Ta, the radio is powered
off.
5
2.2 Volume control
Turn clockwise to increase volume, anti-clockwise to decrease volume.
2.3 Channel Control
4
1. Short press microphone [ UP ] or [ DN ] to change working channel.
2. Hold microphone [ UP ] or [ DN ] can fast change working channel.
8
2.4 Squelch level control(O.F to 3.4 level available)
1. Short press
7
stands for SQ level, the bigger value stands for high squelch level.
2. Short press [ UP ] or [ DN ] to change SQ level.
3. Hold [ UP ] or [ DN ] can fast change SQ level.
4. Short press
» » Note：The» higher» SQ» level» selected,» the» stronger» signal» required» to»
open»speaker»and»hear»the»calling.
2.5 ASQ control(A.1-A.9 level available)
1. Hold
LCD will displays "A.X", "X" stands for the ASQ level, the bigger value
stands for high squelch level.
2. Short press microphone [ UP ] or [ DN ] to change ASQ level
3. Hold microphone [ UP ] or [ DN ] can fast change ASQ level.
Ω
4. Short press
» » Note：The» higher» ASQ» level» selected,» the» stronger» signal» required» to»
open»speaker»and»hear»the»calling.
1
....................................................................
....................................................................................
..................................................................................
...........................
, until LCD displays SQ and then displays X.X, X.X
or wait for 3 seconds to store and exit.
..............................................
key, until LCD displays AQ, the ASQ function turned on. The
or wait for 3 seconds to store and exit.
2
