  • Page 1 INSTRUCTION MANUAL & REFERENCE GUIDE...
  • Page 2 - Avoid using this car in wet conditions as the water will cause adjustments, which will give you a good initial setup corrosion on for your Serpent S100 LTR. Fine-tuning the initial setup the metal parts and bearings and these parts will cease to is an essential part of building a high-performance function properly.
  • Page 3 USING THE MANUAL Each step contains a variety of numbers, lines, and symbols. The numbers represent the order in which the parts should be assembled. The lines and symbols are described below. Step number; the order in which you should assemble the indicated parts Length after assembly Assembly path of one item into another...
  • Page 4 CA Glue To prevent the risk of the carbon fibre splitting in the event of a crash you should apply CA Glue around the chassis’ edge and the power pod plate external and internal edge as shown in red below. STEP FRONT ASSEMBLY Nylock Nut M3...
  • Page 5 STEP 0.5mm Ride Height Spacer 1mm Ride Height Spacer M3x8 M3x8 M3x8 STEP M3x8 M3x8 M3x8 M3x8 Page...
  • Page 6 3.2 mm STEP M3x3 M3x3 Front suspension brackets up INSIDe OUTSIDe Default setup Steering block King pin inserts STEP Default ackermann position in King pin angle adjustable from 0 to 4 the steering degrees. Note orientation Nylock Nut block lever. of the king pin 0º...
  • Page 7 R2.3 3x5x0.3 3x5x1 3x5x2 R2.3 REAR ASSEMBLY STEP Nylock Nut Note the correct ball type to use here NOTE Do not overtighten to ensure free rotation of the pivot ball. M3x8 Page...
  • Page 8 STEP M3x6 M3x6 M3x6 M3x6 STEP M3x6 M3x6 Page...
  • Page 9 M2x6 STEP M2x6 M2x6 M2x6 Note the correct ball type to use here M3x5 NOTE: The links should move free without play. Adjust movement and play with these screws. M3x5 M3x5 M3x5 STEP Note the correct ball type to use here M2.5x5 M2.5x5 M3x5...
  • Page 10 A) OUTSIDE SIDE SPRING CONFIGURATION (DEFAULT) STEP M3x6 M3x10 M3x6 M3x10 B) INSIDE SIDE SPRING CONFIGURATION STEP M3x6 M3x16 M3x16 STEP 3x5x0.3 M3x6 M3x6 Page...
  • Page 11 M3x6 Note the correct ball STEP type to use here M3x5 M3x6 3x6x0.5 M3x6 16.1 STEP M3x10 Apply the silicone oil on the inner tube, see CST value in the setup sheet 16.2 Page...
  • Page 12 BALL DIFF ASSEMBLY Note spring washer orientation STEP 1/4x3/8 Apply silicone grease Note thrust 1/4x3/8 bearing adapter orientation Note insert orientation. For insert number see default setup sheet. STEP M3X8 6.5x8x0.25 M3X8 1/4x3/8 Flanged 6.5x8x0.25 1/4x3/8 Flanged Rear ride height inserts The rear ride height is adjustable in steps of 0.5mm increments using different rear axle bearing adapters.
  • Page 13 SERVO AND BATTERY ASSEMBLY NOTE: Serpent S100 LTR is designed to create two different battery/servo configurations: A) Detail view shorty battery and laydown servo configuration (default) B) Detail view standard battery and standing servo configuration. Below you can see a detail view of both configurations. Please follow the right steps for the choosen configuration: A or B A) Shorty battery and laydown servo configuration (default) B) Standard battery and standing servo configuration.
  • Page 14 20.1 31.8 mm STEP 20.2 STEP INCLUDeD M3X6 Flanged M3X6 M3X6 Page...
  • Page 15 STEP Check how many teeth your servo spline has M3X5 (23, 24 or 25) and use the right inserts. M3X8 23.1 STEP 23.2 NOTE Use glass-tape (not included) STEP to fix the battery to the chassis. INCLUDeD M2.5X5 M2.5X5 M2.5X5 M2.5X5 Page...
  • Page 16 B) Standard battery and standing servo configuration. FUTABA MINI SERVO STD LOw PROFILE SERVO STEP M3x8 INCLUDeD INCLUDeD M3x8 3x6x0.5 M3x5 3x6x0.5 M3x5 JR SERVO M3x8 INCLUDeD M3x6 3x6x0.5 FUTABA MINI SERVO STD LOw PROFILE SERVO STEP M3x6 Flanged LefT M3x6 Flanged RIGhT...
  • Page 17 22.1 31.8 mm STEP 22.2 STEP NOTE Use glass-tape (not included) INCLUDeD to fix the battery to the chassis. M2.5X5 M2.5X5 M2.5X5 M2.5X5 Page...
  • Page 18 SHOCK ASSEMBLY 25.1 25.2 25.3 STEP Use some silicone oil NOTe during assembly For the correct piston check the set-up sheet. 25.4 25.5 M3X10 M3X3 25.7 25.6 Close the shock slowly. Important: crossthread! will overflow through Filling: built-in bleed channel. Fill the shock body with shock absorber oil.
  • Page 19 STEP NOT INCLUDeD Tip: Use double sided tape to mount STEP the ESC and RX to the chassisplate. NOT INCLUDeD M3X5 STEP Pinion is NOT INCLUDeD in the INCLUDeD kit. Assemble the proper pinion for your set-up M3X10 Page...
  • Page 20 FINAL ASSEMBLY STEP Nylock nut M3 M3X10 M3X10 STEP M3X10 M3X10 M3X10 M3X10 Page...
  • Page 21 STEP Body, wheels and STEP tyres are NOT included 1/8X5/16 Flanged M3X8 Nylock Nut Low M3 Page...
  • Page 22 REFERENCE GUIDE Page...
  • Page 23 FRONT ASSEMBLY 110116 411049 411049 411320 411142 401058 411230 411321 110104 411081 411229 110104 411059 411084 411163 110406 110408 411181 411042 401042 411086 411085 401043 411323 110402 110160 401025 411042 411322 411033 411230 411064 411142 411034 110108 411218 Front spring 22lbs S120L (2) 411324 411219 Front spring 18lbs S120L (2)
  • Page 24 REAR ASSEMBLY 411187 110122 411188 110128 110415 411207 411061 110122 110122 110154 411331 411238 110122 401025 411259 411207 411074 411224 401025 411061 110122 411072 411279 411325 110166 110128 411201 411328 110122 110154 401025 411072 110402 411202 411074 411224 110206 411329 110128 411326 411199...
  • Page 25 STEERING ASSEMBLY A 411346 411308 1070 110172 411206 411206 804322 110128 401356 411236 401025 411206 110104 411206 110108 401025 1312 411335 401025 110108 110128 1312 411374 110166 110166 110122 Please click here to check all the Optional Parts STEERING ASSEMBLY B 411308 110172 1070...
  • Page 26 FINAL ASSEMBLY 411040 1606 411239 411040 401025 401413 411040 401043 1667 110109 411243 110109 411239 500360 411040 411350 1667 411243 411291 110104 411291 411242 411241 110109 411240 110129 110402 110122 411061 110100 411077 110100 411077 110402 Please click here to check all the Optional Parts Page...
  • Page 27 TEAM SERPENT NETWORK S100 lTR SPARE PARTS S100 lTR OPTiONAl PARTS SERPENT TOOlS SERPENT MERCHANdiSiNg WEbSiTE ANd blOg SOCiAl MEdiA Page...
