Serpent Spyder SRX2 SC Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTRUCTION MANUAL
& REFERENCE GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Spyder SRX2 SC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Serpent Spyder SRX2 SC

Summary of Contents for Serpent Spyder SRX2 SC

  • Page 1 INSTRUCTION MANUAL & REFERENCE GUIDE...
  • Page 2 TEAM SERPENT NETWORK expectations for quality and durability, like with every Serpent car. In case you still find You can share your rc experience and learn some issue or have a questions then ask...
  • Page 3 Read this first! this car on public roads, crowded places or near infants. - Before operating this car, always check the mechanical status of the car. Also check that the transmitter and - This is a highly technical hobby product, intended to be used receiver frequencies correspond and are not used by in a safe racing environment.
  • Page 4 FRONT ASSEMBLY STEP 4x8x3 4x8x3 3x6x0.5 Nylock nut M3 Nylock nut M3 M3x12 15.25 mm STEP M3x12 15.25 mm NOTE: Make sure to assemble the ballstud through 4x8x3 the conical shim in the direcction 4.8- 5 mm indicated by the red arrow.
  • Page 5 STEP M3x12 M3x10 STEP INCLUDED 1.25mm 1.5mm 1.75mm Servo Spacer Manufacturer M3x10 Airtronics 1+3+4 3.2x7x0.5 Futaba Hitec KO Propo Spektrum 1+2+3 Use the following servo horns with this brand of servos: M3x8 23 - Sanwa / KO/ JR 24 - Hitec 25 - Futaba / Hitec/ Savox NOTE: Make sure to put servo in...
  • Page 6 M3x18 STEP NOTE Place the caster shims and the bush- M3x10 STEP ings in the steering block first (1). Then slide the assembly onto the casterblock (2) and fix it with the screws (3). M3x12 M3x4 5x10x4 5x10x4 NOTE There are three types of steering arms. Please, assemble number as default M3x12...
  • Page 7 STEP 3x33 M3x12 STEP M3x16 M3x8 3.2x7x0.5 M3x20 11.1 46.1 mm STEP 11.2 17.25 mm 17.25 mm 3x6x0.5 3x6x1 12.8 mm 12.8 mm NOTE: Make sure to assemble the ballstud through the conical shim in the direcction indicated by the red arrow.
  • Page 8 12.1 STEP 46.3 mm 12.2 NOTE: Make sure to assemble the ballstud through the conical shim in the direcction indicated by the red arrow. 12.8 mm 15.25 mm 12.8 mm 3x6x1 15.25 mm STEP M3x22 M3x14 M3x14 M3x10 M3x22 M3x10 Front Shocks position detail view Page...
  • Page 9 REAR ASSEMBLY STEP 2x10 2x10 LEFT 10x15x4 Rear upright and insert assembly detail view M2x6 5x13x4 STEP 3x33 M2.3x4 Front Inserts detail view (use ASSEMBLY CORRECT ORDER: number also in the front block) STEP 1) Introduce the pin in the wishbone 2) Place the rear insert in the rear part of the toe block...
  • Page 10 BALL DIFF ASSEMBLY STEP 5x8x2.5 5x8x2.5 STEP STEP NOTE: 8 balls STEP HOW TO ADJUST THE DIFF As default setting screw all the way in, and back out ¼ turn. Make small adjustments depending on the track condition. NOTE: Lubricate o-ring with grease Page...
  • Page 11 OPTIONAL GEAR-DIFF ASSEMBLY #500192 Use some grease during assembly NOTE: Step 1 and Step 2: 1.5x8 To mount the pin, first put the pin in the purpose made slot as shown, and after slide it through the hole in the shaft. Use some grease during assembly 1.5x8...
  • Page 12 NOTE: 1) Assemble the o-ring before adding the oil. 2) Add oil so the cross pins are just covered (DO NOT overfill). NOTE: The diff assembled as shown here, should weigh max 16.9 grams M2x10 Page...
  • Page 13 Default position mid diff. M3x30 10x15x4 M3x30 M2.5x12 Nylock nut M3 INITIAL SETTING OF THE SLIPPER STEP 1.5 - 2 mm 3x7x0.5 1.5x8 STEP Pinion is NOT INCLUDED in the kit. See Serpent pinion list in the ref- guide. M3x8 3.2x7x0.5 M2.5x6 Page...
  • Page 14 STEP M3x12 M3x10 STEP M3x14 STEP 47.7 mm Page...
  • Page 15 STEP 15.25 mm 17.25 mm 3x6x0.5 3x6x1 17.25 mm NOTE: Make sure to assemble the ballstud through the conical shim in the direcction indicated by the red arrow. M3x12 STEP M3x40 M3x22 M3x18 M3x16 STEP M3x12 M3x10 Page...
  • Page 16 SHOCK ABSORBERS ASSEMBLY 30.1 30.2 30.3 STEP Nut M2 Use some silicone oil during assembly Insert the Note orientation o-ring of the shock inside the cartridge REAR SHOCKS FRONT 30.4 30.4 FRONT SHOCKS REAR SHOCKS SHOCKS Use some silicone Use some oil during silicone assembly...
  • Page 17 30.7 30.8 FRONT SHOCKS Assemble the spring With shockrod fully and spring-cup (align in, mount the o-ring correctly) to complete and screw. M2.3x4 the shock. HIGH REAR SHOCKS NOTE: STEP overtighten and smash bushing with the nut and note M3 Plastic Nut Flanged orientation lower shock pivot ball M3x16 Flanged...
  • Page 18 M2.3x4 M2.3x4 STEP M2.3x4 M2.3x4 M3x10 STEP M3x10 STEP M3x8 M3x8 M3x16 M3x16 M3x16 Page...
  • Page 19 BODY MOUNTS ASSEMBLY 2x12 STEP 2x12 M2.2x12 M3x10 M2.2x12 M3x10 2x12 STEP 2x12 M2.2x12 M3x16 M2.2x12 Page...
  • Page 20 ELECTRONICS ASSEMBLY STEP M3x3 NOT INCLUDED M3x16 M3x16 Tip: Use double sided tape to mount the ESC and RX to the chassis. NOTE: WEIGHT BALANCE To adjust the weight balance, STEP move the batterypads accordingly, more front or backwards as needed. Battery pad thin INCLUDED Battery pad thick...
  • Page 21 Same for the body mounting holes. 3) Remove the body protection film on the outside of the body. 4) Apply the provided Serpent and Spyder decals, and mount the body on the bodyposts, with the provided bodyclips.

  • Page 22: Table Of Contents

    REF GUIDE: EXPLODED VIEWS and PARTS-LIST Contents FRONT ASSEMBLY I FRONT ASSEMBLY II BALL DIFF ASSEMBLY OPTIONAL GEAR DIFF ASSEMBLY 26 TRANSMISSION ASSEMBLY REAR ASSEMBLY SHOCKS ASSEMBLY FINAL ASSEMBLY I FINAL ASSEMBLY II PARTS-LIST Page...

  • Page 23: Front Assembly I

    FRONT ASSEMBLY I Page...

  • Page 24: Front Assembly Ii

    FRONT ASSEMBLY II Page...

  • Page 25: Ball Diff Assembly

    BALL DIFF ASSEMBLY Page...

  • Page 26: Optional Gear Diff Assembly

    GEAR-DIFF #500192 EXPLODED VIEW Page...

  • Page 27: Transmission Assembly

    TRANSMISSION ASSEMBLY Page...

  • Page 28: Rear Assembly

    REAR ASSEMBLY Page...

  • Page 29: Shocks Assembly

    SHOCKS ASSEMBLY Page...

  • Page 30: Final Assembly I

    FINAL ASSEMBLY I Page...

  • Page 31: Final Assembly Ii

    FINAL ASSEMBLY II Page...

  • Page 32: Parts-List

    PARTS-LIST Part nº Description 500339 Shock spring pink 3.2lbs fr (2) SRX2 SC 500004 Serpent Spyder SXR-2 SC 2wd 1/10 500340 Shock spring blue 3.3lbs fr (2) SRX2 SC 500341 Shock spring purple 3.4lbs fr (2) SRX2 SC DECALS 500342 Shock spring green 3.5lbs fr (2) SRX2 SC...
  • Page 33 500134 Rear suspension insert (24) SRX2 500247 Diff pin 14T (2) SRX2 500135 Upright inserts (10) SRX2 500248 Geardiff o-ring (4) SRX2 500138 Balljoint set (14) SRX2 500249 Geardiff outdrive (2) SRX2 500143 Pivot pin rr inner (2) SRX2 RM 500253 Geardiff cap L+R SRX2 500144 Hinge pin fr inner / rr outer (2) SRX2 500254 Geardiff housing 51T SRX2...
  • Page 34 190521 Tool tip ball driver hex wrench 2.5 x 110148 Setscrew allen M5x4 (10) 120mm 110149 Screw allen countersink M2x10 (10) 190522 Tool tip ball driver hex wrench 3.0 x 110150 Screw M6x12 nylon black (2) 120mm 110151 Screw allen cilinderhead M4x10 (10) 190523 Turnbuckle wrench 3mm 110152 Screw allen cilinderhead M3x8 (10) 190524 Turnbuckle wrench 4mm...
  • Page 35 190205 Hoody sweater Serpent black-zip (2XL) 110425 Shim 5X10X0.3 (10) 190206 Hoody sweater Serpent black-zip (3XL) 110426 Shim 5X10X0.5 (10) 190207 Hoody sweater Serpent black-zip (4XL) ) 110428 Shim 6.5X8X0.25 (10) 190215 T-shirt Serpent WC edition black (S) 110429 Shim 6X11.75X0.2 (10) 190216 T-shirt Serpent WC edition black (M) 110431 Shim 8X11X0.1 (10)
  • Page 36 - info@serpent.com...
