    INTRODUCTION SafETy The Serpent SRX2 Gen3 Team is a state of the art 1/10 scale 2wd buggy which will give you Read and take note of the ‘Read this First section’ before proceeding to assemble the car-kit. the true Serpent racing experience. The assembly manual will guide you through all the steps This car-kit is intended for persons aged 16 or older.
  • Page 3 how to use the manual lines DESCRIpTION ICONS DESCRIpTION Each step contains a variety of numbers, lines, and symbols. The numbers represent the Each step contains a variety of symbols described below. order in which the parts should be assembled. The lines are described below. Step number;...

  • Page 4: Chassis Assembly

    chassis assembly STEp 1 STEp 2 BaG 1 M3x8 M3x8 M3x12 M3x12 M3x8 M3x12...

  • Page 5: Steering Assembly

    steering assembly STEp 3 STEp 4 STEp 5 M3x10 4x8x3 4x8x3 4x8x3 3x6x0.5 3x6x0.5 4x8x3 M3x12 3x6x0.5 Nylock Nut M3 M3x10 3x6x0.5 M3x12 4X8X3 4X8X3...
  • Page 6 STEp 6 STEp 7 BaG 2 Check many teeth your M3x10 servo spline has (23, 24 or 25) and use the right lever. 2- Make sure to put the M3x10 M3x8 servo in neutral before 3.2x7x0.5 mounting the lever. M3x12 3x5x1 STEERING LINK LENGTH The length may differ...

  • Page 7: Front End Assembly

    fRONT aSSEmBly STEp 8 STEp 9 BaG 3 Place the caster shims and the bushings M3x10 in the steering block first. Then slide the assembly onto the casterblock. M3x16 M3x12 M3x8 M3x16 M3x4 5x13x4 5x10x4 M3x12 STEERING ARMS CHART STEERINGBLOCK ASSEMBLY MORE LESS ACKERMANN ACKERMANN M3x14...
  • Page 8 STEp 10 STEp 11 BaG 4 3x24 M2.3x4 M3x6 CASTER BLOCK INSERTS CHART Front default caster angle 3x33 is 25º using the 0º default - Caster insert. You can add or M3x3 remove caster using the M3x3 different inserts included in the kit. 3x33 It is possible to adjust M3x14...
  • Page 9 STEp 12 12.1 12.2 CAMBERLINK OUTER DEFAULT POSITION 18.65mm 16.65mm FRONT CAMBERLINK LENGTH 25 mm 3X6X1 3X6X1 CAMBERLINK INNER BALLSTUD LENGTH DEFAULT POSITION 18.65mm 16.65mm 3x6x1...
  • Page 10 STEp 13 STEp 14 M3x3 M3x3 M3x3 M2.5x6 M3x3 M2.5x6 BALLSTUD LENGTH VIEW DETAIL Do not overtighten the M3x3 setscrews and ensure that the front antiroll bar and front suspension moves freely. M3x3 M3x3 M2.5x6...
  • Page 11 STEp 15 STEp 16 15.1 STEERING TRACKROD LENGTH M3x20 29.5 mm M3x10 15.2 M3x10 15mm FRONT SHOCKS DEFAULT POSITION 3x6x1 BALLSTUD LENGTH 3x6x1 16.65mm 15mm 16.65mm 3x6x1 M3x10 M3x20...

  • Page 12: Transmission Assembly

    transmission assembly STEp 17 STEp 18 BaG 5 18.1 5x10x4 5x10x4 5x13x4 5x13x4 18.2 M3x14 M2.3x4 M2.3x4 M3x14 5x10x4 5x13x4...
  • Page 13 STEp 19 STEp 20 Nylock Nut M3 3.2x7x0.5 1.5x8 M3x12 SLIPPER INITIAL SETTING 1.5 - 2 mm 1.5x8 Nylock Nut M3 M3x12 3.2x7x0.5...
  • Page 14 STEp 19 STEp 21 M3x8 M3x8...

  • Page 15: Differential Assembly

    gear diff assembly STEp 22 STEp 23 diff bag rr 22.1 23.1 23.2 23.3 1.5x8 Add just enough oil to cover the large gear before assembling the small satellite gears and cross pins. Use the silicone oil supplied in the kit. For the correct cst value please check the default se- tup-sheet.
  • Page 16 STEp 24 STEp 25 24.1 24.2 Fit the o-ring before Fill the differential to the brim with silicone oil , do NOT overfill. M2x10 finishing the filling of the differential. Use the silicone oil supplied in the kit. For the correct cst value please check the default setupsheet.

  • Page 17: Rear Suspension Assembly

    rear suspension aSsEmBly STEp 26 STEp 27 BaG 7 SUSPENSION INSERTS Please find qty. 2 Centered Inserts. These 0 inserts are the default setup and should be installed into this RR FR Toe block. Additional information can be found on page 20, for how you can use the in- serts to adjust toe-in, anti-squat, and pivot width.
  • Page 18 STEp 28 STEp 29 Diff inserts 10x15x4 10x15x4 M3x10 M3x25 M3x25 M3x25 M3x10 M3x25 10x15x4...

  • Page 19: Rear End Assembly

    rear aSsEmBly STEp 30 BaG 8 REAR AXLE HEIGHT AND OFFSET INSERTS Wide Offset Narrow 10x15x4 0.5mm 0.5mm 2x10 5x13x4 1.5mm 1.5mm 2x10 M2x5 2.5mm 2.5mm REAR WHEEL-AXLE PIN FOR DRIVESHAFT POSITION The axle has 3 pivoting 1) The axle height adjustment will give you the ability to adjust the roll choices.
  • Page 20 STEp 31 STEp 32 BaG 9 Notice, the uprights are symmetrical, but the camber link mount has to have the proper 3x6x1 orientation for Left and Right. Please check below the proper orientation. 3x6x0.5 FRONT LEFT RIGHT 3x6x1 3x6x0.5 REAR 3x33 M3x12 M2.3x4...
  • Page 21 STEp 33 SUSPENSION INSERTS Below is a diagram of every possible orientation of the compete 7 inserts system. You are able to move 0.5 or 1 degree in any direction from center. We also have 2 special inserts to fill 0.5° left and right offset, by 1°...
  • Page 22 STEp 34 34.1 34.3 M3x3 4x7x2.5 M3x14 Flanged M3x3 1.3mm 4x7x2.5 Flanged 34.2 M3x3 BALLSTUD LENGTH M3x3 4x7x2.5 Flanged...
  • Page 23 STEp 35 35.2 35.1 18.65mm 14.65mm 3x6x1 3x6x0.5 REAR CAMBERLINK LENGTH 27.9 mm CAMBERLINK INNER CAMBERLINK OUTER DEFAULT POSITION DEFAULT POSITION BALLSTUD LENGTH 18.65mm 14.65mm M3x14 3x6x0.5 3x6x1...
  • Page 24 STEp 36 M3x25 M3x12 M3x25 M3x22 FRONT SHOCKS DEFAULT POSITION M3x12 M3x25 M3x22...

  • Page 25: Shock Assembly

    shocks assemby STEp 37 STEp 38 BaG 10 fr shocks / bag 11 rr shocks 37.1 38.1 Note the correct orientation of the Use some silicone oil 2.5x6x0.5 shock spacers . during the assembly. Nut M2 For the correct piston holes and size please check the default setupsheet.
  • Page 26 STEp 39 STEp 40 39.1 39.2 SHOCKS LENGTH: Measure the Assemble the spring and spring- cup (align correctly) to complete shock length fully extended. 1-Bleed: push the shock- 1- Fill up with sillicone oil the shock. FRONT REAR rod all the way in slowly, fully using the silicone to allow excessive oil to oil supplied in the kit.
  • Page 27 STEp 41 STEp 42 BaG 12 Do not overtighten and Do not overtighten and M3 Plastic smash bushing with the smash bushing with the Nut Flanged nut and note orientation of nut and note orientation of the lower shock pivot ball. the lower shock pivot ball.

  • Page 28: Final Assembly

    fINal assembly STEp 43 STEp 44 Provided in the kit are long and short battery posts. Use long posts with STANDARD SIZE shorty batteries. M3x25 M3x25 Use short posts with LOW PROFILE / THIN batteries. M3x8 3.2x7x0.5 Pinion is not included in the kit.
  • Page 29 STEp 45 The SRX2 GEN3 TEAM allows the battery position to be adjusted in six different locations. In order to use the three rearward positions the battery brackets have to be assembled as shown in configuration A. To use the three forwards positions the battery brackets have to be assembled as shown in the configuration B. 45A REARWARD BATTERY CONFIGURATION 45B FORWARD BATTERY CONFIGURATION M3x8...
  • Page 30 STEp 46 Use double sided tape to mount the ESC and RX to the chassis.
  • Page 31 STEp 47 BATTERY DEFAULT POSITION...

  • Page 32: Exploded Views

    STEp 48 BaG 13 M3x12 ANGLED WING SPACERS CHART 0º 2º 4º 6º 8º FRONT REAR M3x12...
  • Page 33 Follow the cleaning & painting instructions supplied by the polycarbonate paint supplier you choose. 3- Apply the Serpent and SRX2-Gen3 logo-decals on the body and wing. 1- Rims included in the kit. 2- Rubber tyres not included in the kit.
  • Page 34 EXplODED VIEWS INDEX: Differential exploded view central and steering exploded view front exploded view transmission exploded view rear exploded view shocks exploded view final exploded view team serpent network...
  • Page 35 differential exploded view 500781 opt 500257 500246 500793 opt 500290 110220 500248 500247 500794 opt 500253 500246 500877 opt 110220 500249 500876 opt 110188 500246 500253 500248 500780 500290 500246 500249 110188 500876 opt 411107 Diff balls. 1/8 ceramic (12) 500782 Diff pully balldiff 51T LF SRX2 Gen3 500876 Geardiff outdrive SRX2 (2) V2 500259 Differential balls carbide 1/8...
  • Page 36 CENTRal aND STEERING EXplIDED VIEW 110132 500741opt 110104 500742 500743 opt 500710 110116 110116 110130 500775 500769 110130 500118 500708 opt 500769 500197 opt 500769 411187 500799 opt 500775 110401 411187 110109 500775 411187 110124 500119 500719 500706 110409 110109 500756 opt 110117 500714...
  • Page 37 front exploded view 110140 500736 opt 500684 500146 500146 110109 110109 110109 500696 500719 500726 500719 500162 xxxxxx 500162 110449 500719 500697 500719 110449 110112 500695 500725 500262 opt 500698 500366 500144 110449 500151 opt 500683 opt 500721 500800 500681 500113 opt 110500 500717...
  • Page 38 transmission exploded view 500727 500729 110124 110503 500213 opt 110503 500214 opt 500215 opt 500729 500216 500217 opt 500218 opt 500707 500219 opt 500220 opt 500701 500221 opt 500790 500788 opt 500791 opt 500158 500159 500158 110401 110402 110111 110153 500730 500779 opt 500871 opt...
  • Page 39 rear exploded view 110111 500276 110449 500685 500969 500737 opt 500713 opt 500755 opt 110449 110112 500770 110142 500534 500754 opt 500753 opt 500752 opt 110116 500750 opt 110109 500776 500748 opt 110116 500703 110141 411187 500347 500161 500776 1310 500534 110142 500162...
  • Page 40 shocks exploded view 500183 500183 500184 110153 500178 500176 500487 500222 opt 500179 500177 500223 opt 500180 opt 500224 opt 500487 500225 opt 500226 opt 500227 opt 500228 opt 500174 Front 500229 FRONT 500175 Rear 500230 opt 500231 opt 500232 opt 500233 opt 500234 opt 500235 opt...
  • Page 41 final exploded view 500360 500165 opt 500879 110127 500492 opt 500594 1667 1667 500712 500374 500189 opt 500252 opt 500375 opt 110124 500773 opt 500419 500774 opt 500878 110112 500878 110142 500678 500679 opt 500136 500199 opt 500136 500137 500199 opt 500105 500106 opt 500137...

  • Page 42: Team Serpent Network

    TEam SERpENT NETWORK SRX2 Gen3 Team SPARE PARTS SRX2 Gen3 Team OPTIONALS PARTS SERPENT TOOLS SERPENT MERCHANDISING...
  • Page 43 SERPENT WEBSITE AND BLOG www.serpent.com www.teamserpent.com www.dragon-rc.com SERPENT PROMO PAGES http://promo.serpent.com SERPENT SOCIAL MEDIA www.facebook.com/SerpentMRC...
  • Page 44 Manual SRX2 Gen3 team #89767-1...
