3.

Proper Environment

- Protection class
ƒ Sensor, controller:
and/or installed protective caps)
Optical paths during operation are excluded from the protection class. Contamination of
the paths causes impairment or failure of the function.
The IP40 protection class is a specification that is limited to protection from dust and wa-
ter. Oil, steam and emulsion effects are not included in this protection class and must be
evaluated separately.
- Temperature range
ƒ Operation
• Sensor:
• Controller:
ƒ Storage
• Sensor:
• Controller:
- Humidity:
- Ambient pressure:
1) Max. permissible operating temperature with 0.7 m/s air blow
4.

Unpacking, Included in Delivery

- 1 Sensor surfaceCONTROL 3D 25x0
- 1 Controller SC2500
- 1 Cable harness/5 m/standard for surfaceCONTROL
- 1 Assembly Instructions
- 1 Calibration protocol
- 1 Table power pack for sensor
- 1 Ethernet patch cable (Cat6A, gray, 5 m)
- 1 DIN-rail mounting kit for controller
- 1 Power supply cable (4-pin terminal strip to open ends)
Carefully remove the components of the measuring system from the packaging and
ensure that the goods are forwarded in such a way that no damage can occur.
Check the delivery for completeness and shipping damage immediately after un-
packing.
If there is damage or parts are missing, immediately contact the manufacturer or
supplier.
surfaceCONTROL 3D SC2500 / SC2510
IP40 (only applies in the case of connected output connectors
5 ... +40 °C
1
-10 ... +60 °C
-10 ... +50 °C
-40 ... +85 °C
20 ... 80 % (non-condensing)
Atmospheric pressure
