Amico BARCHLD2 Quick Installation And Maintenance Manual

Barcode Dock Mount - BARCHLD2
Quick Installation and Maintenance Instructions
BARCDHLD2-(M/F/A/E25/R125/RMC/V/D/G/S/LCD)
Medical Facility Responsibility
Preventive maintenance checks must be performed regularly to maintain the quality and performance of this product. Any parts that may be broken, missing, worn,
distorted or contaminated in any way should not be used and all affected parts should be replaced immediately. Should the necessity of any repair be suspected; please
contact your local Amico distributor.
!
WARNING: It is the responsibility of the end user to ensure all aspects of installation are covered.
Installation Tool
Hex Key: 1/8"
Pre-installation Information
Determine the preferred orientation of the barcode charging base and refer to the below illustrations for mounting. Note the illustrations shown may not portray the configuration
purchased. Use this guide as a reference to pair hardware and mounting hole pattern with respective barcode scanner base (not provided).
H-FHMS-440-114
H-ANUT-440
Barcode charging base with 1 hole, such as Honeywell 2020
for barcode scanners: 3820, 4620, 4820, or 5620
Installation to Device
1. Before mounting the barcode scanner onto the mounting plate, determine the mounting pattern on the barcode scanner base. If the barcode scanner base is too larger to mount
onto the BARCODE SCANNER HOLDER, proceed to step 2 for installation of secondary plate.
If the secondary extension plate is required, determine the preferred orientation (refer to section 2: Pre-installation Instructions) and secure by inserting 2x or 3x H-FHMS-832-12
FOR USE WITH: BARCDHLD2-(M/F/A/E25/R125/RMC/V/D/G/S)
through EXTENSION PLATE, BARCODE SCANNER HOLDER, 2x or 3x STEEL LOCK WASHERS, 2x or 3x ACORN NUTS, ensuring that the MOUNTING SCREWS do not interfere with the mounting
1. BEFORE MOUNTING PRODUCT ONTO MOUNTING PLATFORM, DETERMINE THE MOUNTING PATTERN ON THE BARCODE SCANNER
BASE TO BE MOUNTED. IF THE BARCODE SCANNER BASE IS TOO LARGE TO MOUNT ONTO X-BRCDHLD-LBKT, PROCEED TO STEP 2 FOR
pattern of the BARCODE SCANNER BASE.
INSTALLATION OF SECONDARY PLATE.
2. IF THE SECONDARY PLATE, X-BRCDHLD-PLT, IS REQUIRED, DETERMINE THE PREFERRED ORIENTATION AND SECURE BY INSERTING 2X OR
3X H-FHPMS-832-38 THROUGH X-BRCDHLD-PLT, X-BRCDHLD-LBKT, 2X OR 3X H-WLM-08, 2X OR 3X H-ACNUT-8-32, ENSURING THAT THE
MOUNTING SCREWS DO NOT INTERFERE WITH THE MOUNTING PATTERN OF THE BARCODE SCANNER BASE
EXTENSION PLATE
(OPTIONAL)
[X-BRCDHLD-PLT]
X-BRCDHLD-PLT
2 X
2x
2 X
H-ACNUT-8-32
FIGURE 1
FOR USE WITH: BARCDHLD2-(M/F/A/E25/R125/RMC/V/D/G/S)
1. BEFORE MOUNTING PRODUCT ONTO MOUNTING PLATFORM, DETERMINE THE MOUNTING PATTERN ON THE BARCODE SCANNER
BASE TO BE MOUNTED. IF THE BARCODE SCANNER BASE IS TOO LARGE TO MOUNT ONTO X-BRCDHLD-LBKT, PROCEED TO STEP 2 FOR
INSTALLATION OF SECONDARY PLATE.
2. IF THE SECONDARY PLATE, X-BRCDHLD-PLT, IS REQUIRED, DETERMINE THE PREFERRED ORIENTATION AND SECURE BY INSERTING 2X OR
3X H-FHPMS-832-38 THROUGH X-BRCDHLD-PLT, X-BRCDHLD-LBKT, 2X OR 3X H-WLM-08, 2X OR 3X H-ACNUT-8-32, ENSURING THAT THE
MOUNTING SCREWS DO NOT INTERFERE WITH THE MOUNTING PATTERN OF THE BARCODE SCANNER BASE
Barcode charging base with 2 holes, such as Honeywell
CCB01-010BT for the Honeywell Xenon 1900, 1910, 1902, 1912
X-BRCDHLD-PLT
2 X
2x
FLATHEAD SCREWS
2 X
[H-FHPMS-832-12]
H-FHPMS-832-12
BARCODE SCANNER HOLDER
[X-BRCDHLD-LBKT]
X-BRCDHLD-LBKT
2x
ACORN NUTS
[H-ACNUT-8-32]
3 X
H-FHPMS-832-12
4x
H-PMHS-M4-14
2x
2x
H-MPP-0805-SS
Barcode charging base with 4 holes, such as code reader CRA-A101 or CRA-A104 for CR2600
2 X
H-FHPMS-832-12
X-BRCDHLD-LBKT
2 X
H-ACNUT-8-32
FIGURE 1
H-FHPMS-832-12
3x
3 X
FIGURE 2
FIGURE 3
Installation Reference
2x
H-PMHS-M4-14
4x
4x
ACORN NUTS
[H-ACNUT-8-32]
CUSTOMER
FIGURE 2
3x
FLATHEAD SCREWS
3 X
[H-FHPMS-832-12]
3x
ACORN NUTS
[H-ACNUT-8-32]
3 X
H-ACNUT-8-32
PRIVATE AND CONFIDENTIAL
THIS PRINT IS PROPERTY OF AMICO ACCESSORIES
AND IS LOANED IN CONFIDENCE SUBJECT TO RETURN
UPON REQUEST AND WITH THE UNDERSTANDING THAT
NO COPIES ARE TO BE MADE WITHOUT THE CONSENT
OF AMICO ACCESSORIES
ALL RIGHTS TO DESIGN OR INVENTION ARE RESERVED
BARCDHLD2-M
2x
16 mm PANHEAD
SCREWS
[H-PMHS-M4-16]
CUSTOMER
FIGURE 4
