GlassProtect User manual
Updated January 24, 2022
GlassProtect is a wireless indoor glass break detector recognizing the sound of
shattering the glass at a distance of up to 9 meters. GlassProtect can operate
up to 7 years from a pre-installed battery and has a socket for connecting a
third-party wired detector.
GlassProtect connects to the Ajax security system via the protected
Jeweller
radio protocol. The communication range is up to 1,000 meters in line of sight.
Also, GlassProtect can be connected to third-party security systems using the
Ajax uartBridge
or
Ajax ocBridge Plus
integration modules.
Users can con gure GlassProtect via the
Ajax app
for macOS, Windows, iOS, or
Android. The system noti es users of all events through push noti cations, SMS,
and calls (if activated).
The user can connect the Ajax security system to the central monitoring station
of a security company.
Buy breakage detector GlassProtect

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GlassProtect and is the answer not in the manual?

Questions and answers

Related Manuals for AJAX Systems GlassProtect

Summary of Contents for AJAX Systems GlassProtect

  • Page 1 GlassProtect is a wireless indoor glass break detector recognizing the sound of shattering the glass at a distance of up to 9 meters. GlassProtect can operate up to 7 years from a pre-installed battery and has a socket for connecting a third-party wired detector.

  • Page 2: Functional Elements

    6. Device switch 7. Tamper button Operating Principle GlassProtect uses a sensitive electret microphone to detect the sound of glass breaking, consisting of a low-frequency hit sound and high-frequency crashing sound of glass shatters. Such two-stage glass break detection decreases the risk of false triggering.
  • Page 3 DoorProtect Plus wireless opening detector with shock and tilt sensors. If triggered, GlassProtect immediately transmits the alarm signal to the activating the sirens (if connected) and notifying the user and security company.
  • Page 4 3. Tap Add — the countdown will start. 4. Switch on the device. For detection and pairing to occur, the detector should be located within the coverage area of the wireless network of the hub (at a single protected object). The connection request is transmitted for a short time: at the moment of switching on the device.
  • Page 5 States The states screen contains information about the device and its current parameters. Find the GlassProtect states in the Ajax app: 1. Go to the Devices tab. 2. Select GlassProtect from the list.
  • Page 6 How battery charge is displayed in Ajax apps The tamper state, which reacts to the detachment of or damage to the detector body Entry delay (alarm activation delay) is the time you have to disarm the security system after entering the room. Functions for the connected wired detector Delay When Entering, sec only.
  • Page 7 The sensitivity level is selected based on the detection zone test results of the Status of the external detector connection to External contact GlassProtect If the option is active, the detector is always in armed mode and noti es about alarms Always Active Learn more...
  • Page 8 The name can contain up to 12 Cyrillic characters or up to 24 Latin characters Selecting the virtual room to which GlassProtect is assigned. The name of the Room room is displayed in the text of SMS and noti cations in the event feed Selecting delay time when entering.
  • Page 9 Delay When Leaving, sec Selecting the delay time when exiting. Delay when exiting (alarm activation delay) is the time you have to exit the room after arming the security system. Functions for the connected wired detector only. What is delay when leaving If active, the detector will switch to armed mode Arm in night mode when using Night mode...
  • Page 10 (available in detectors with rmware version 3.50 and later) Signal Attenuation Test What is Attenuation Test User Guide Opens GlassProtect User Guide in the Ajax app Temporary Deactivation Allows the user to disconnect the device without removing it from the system.
  • Page 11 Learn more about Chime GlassProtect settings Before con guring the chime, make sure that a wired opening detector is connected to GlassProtect and that the External contact option is enabled in the GlassProtect settings in the Ajax app.

  • Page 12: Functionality Testing

    1. Go to the Devices menu. 2. Select the GlassProtect detector. 3. Go to its settings by clicking the gear icon in the upper right corner. 4. Go to the Chime Settings menu. 5. Select the siren noti cation for the event If external contact is open (available if the External contact option is enabled).

  • Page 13: Testing The Detector

    Having de ned the location of the detector and having xed the device with the bundled adhesive tape, test the detection zone. GlassProtect does not react to clapping! Testing the detector Hit the glass with your st without breaking it. If the detector catches a low- frequency sound, the LED blinks.

  • Page 14: Installing The Device

    Installing the device Selecting the Location In some cases, the household activity can cause false alarms The location of GlassProtect depends on its remoteness from the hub, and obstacles hindering the radio signal transmission: walls, oors, large objects inside the room.
  • Page 15 5. inside premises with the temperature and humidity beyond the range of permissible limits; 6. closer than 1 m to the hub. GlassProtect recognizes glass break at a distance of up to 9 meters. Its microphone should be positioned no more than 90 degrees relative to the window(s).
  • Page 16 GlassProtect using the in-built terminal clamp. We recommend installing the wired detector at a distance no longer than 1 meter to GlassProtect. Longer wire length increases the risk of its damage and reduces the quality of communication between the detectors.

  • Page 17: Maintenance

    Maintenance Check the operational capability of the detector regularly. Clean the detector body from dust, spider web, and other contaminants as they appear. Use soft dry napkin suitable for tech equipment. Do not use any substances containing alcohol, acetone, gasoline, and other active solvents to clean the detector.

  • Page 18: Complete Set

    Security Grade 2, Environmental Class II in Certi cation conformity with the requirements of EN 50131-1, EN 50131-2-7-1, EN 50131-5-3 Compliance with standards Complete Set 1. GlassProtect 2. SmartBracket mounting panel 3. Battery CR123A (pre-installed) 4. Outside-mounted terminal clamp 5. Installation kit 6. Quick Start Guide...
  • Page 19 Warranty for the “AJAX SYSTEMS MANUFACTURING” LIMITED LIABILITY COMPANY products is valid for 2 years after the purchase and does not apply to the pre-installed battery. If the device does not work correctly, you should rst contact the support service — in half of the cases, technical issues can be solved remotely!
