Specifications

Display
Maximum data points
Channels
Sample rate
Transient capture
Data output
Open input indication
Low battery indication
Power supply
Battery life
AC Adaptor
Standards
Operating Temperature
Operating Humidity
Current Clamp Jaw opening
Dimensions
Weight
Voltage
40Hz to 1kHz
Current
50/60Hz
Peak Measurement
Multi-function LCD
100,000
Single channel, TRMS AC Voltage or Current
1s to 24h selectable
>0.244mS
USB port
"LO" appears on the LCD
Empty battery symbol appears on the LCD
4 AAA Batteries
5 days (approximately)
9V, 0.5A
CAT III 600V
32 to 122°F, 0 to 50°C
<70% RH
0.5" (12.7mm)
4.5 x 2.5 x 1.3" (114 x 63 x 34mm)
8.7oz. (248g)
Range
10VAC to 600.0VAC
10A to 200.0A
8.0 to 850.0V
Accuracy
±2.0%±1V
±2.0%±1A
±5.0%
6 DL150-en-US_V2.7 6/22
