- Page 1 Instruction manual School and training throwing circle S16-508 File: 2016-10-26 PRODUCT SUPPORT Agnieszka Szymczyk-Bystrońska a.szymczyk@polanik.com...
- Page 2 The throwing circle is designed for installing in the foundation of the discus throwing facility. The producer reserves the right to introduce without warning changes in product constructions and colours. II. Technical specification Code S16-508 Inside dia. [mm] 2135 Weight [kg] 23,6 Number of seg.
- Page 3 Do not roll the assembled circle, it must be transported carefully to the place of the installation! IV. Installation in concrete foundation The assembled circle is to be embedded in the concrete foundation approx. 30 cm thick, made of concrete class C20/25, and approximate diameter 2,9 m. Instruction manual S16-508...
- Page 4 The circle surface and the surrounding area should be kept clean and protected against humidity, sand and dirt using a special cover PC16-S0512 (available separately). IV. Packing Parts of the circle are wrapped with foil and fastening to the pallet Instruction manual S16-508...
