Reach Drive Pump Control Kit
3
5
ATTENTION: To prevent electrical shock, disconnect from power source before installing or
servicing. Failure to observe this precaution could result in severe bodily injury or loss of life.
!
Number
1
2
3
4
5
6
7
8
*The recommended torque for the Din Rail Screws is 17 in/lbs.
©2006 Rockwell Automation. All rights reserved.
Reach Drive Pump Control Kit
Instruction Manual D2-3563
1
2
4
Recommended Order of Assembly
Recommended Order of Assembly
8
7
6
Part Description
Din Rail
M4 Washer
M4 Screw*
End Anchors
Fuse Block
Contactor
Overload Contactor
Panel Mount Adapter
