1.2.1 Interface
TX(Transmitter )Illumination
1
HDMI plug, connect to laptop
3
Indicator light
5
Micro USB for power interface
RX (Receiver) Illumination
1
HDMI interface,connect display or projector
3
Indicator light
Indicator light
TX
Static Red
Flashing Red
Flashing Blue
ASK nano
2
Cast button, short press to start or stop
prejecting
4
Antenna, unfold to enhance signal
2
Mode switch key,switch TX/DLNA/AirPlay Mode
and Miracast Mode
4
Micro USB power interface
Illumination
TX is opening
TX is searching for RX
Waiting for the connection
User Manual
7
