Phone Screen Projection; Ios - RGBlink ASK nano User Manual

Exit and Continue Projection
Press the button on TX to exit projection and press the button again to continue the projection.

3.3 Phone Screen Projection

3.3.1 iOS

Select two modes of projection: "Mirror" and "Streaming" which can be done on the web menu, as mentioned in
3.5<Menu>
If Airplay is set as Mirror, keep RX in TX/DLNA/AirPlay Mode.
●See the current mode above the TV graphic on the display/product
2.Connect iOS device to ASK nano RX from Wi-Fi Settings.
●Wi-Fi Network: ASK nano-XXXXXX
● Password: 12345678
3.From Quick Settings,select Screen Mirroring to mirror the display.
ASK nano User Manual
12
