evertz 3406FR-HDBNC User Manual

Fiber optic sfp hd-bnc frame
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
© Copyright 2020
EVERTZ MICROSYSTEMS LTD.
5288 John Lucas Drive,
Burlington, Ontario, Canada
L7L 5Z9
Phone:
Sales Fax:
Tech Support Phone:
Tech Support Fax:
Sales:
Tech Support:
Web Page:
Version 1.0, October 2020
The material contained in this manual consists of information that is the property of Evertz Microsystems and is intended
solely for the use of purchasers of the 3406FR Series. Evertz Microsystems expressly prohibits the use of this manual
for any purpose other than the operation of the device.
All rights reserved. No part of this publication may be reproduced without the express written permission of Evertz
Microsystems Ltd. Copies of this guide can be ordered from your Evertz products dealer or from Evertz Microsystems.
3406FR-HDBNC
Fiber Optic SFP HD-BNC Frame
User Manual
+1 905-335-3700
+1 905-335-3573
+1 905-335-7570
+1 905-335-7571
sales@evertz.com
service@evertz.com
http://www.evertz.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3406FR-HDBNC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for evertz 3406FR-HDBNC

Summary of Contents for evertz 3406FR-HDBNC

  • Page 1 Version 1.0, October 2020 The material contained in this manual consists of information that is the property of Evertz Microsystems and is intended solely for the use of purchasers of the 3406FR Series. Evertz Microsystems expressly prohibits the use of this manual for any purpose other than the operation of the device.
  • Page 2 This page left intentionally blank...
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “Dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
  • Page 4 FIBER OPTIC DEVICES Some modules in this product may have fiber optic outputs. The following safety information applies to the optical outputs of these modules. Consult individual chapters for specific safety information for handling fiber optics. WARNING CAUTION – CLASS 1 VISIBLE & INVISIBLE LASER RADIATION WHEN OPEN DO NOT VIEW DIRECTLY OR WITH OPTICAL INSTRUMENTS.
  • Page 5 INFORMATION FOR NEBS COMPLIANT VERSIONS The intra-building port(s) of this equipment is suitable for connection to intra- building or unexposed wiring or cabling only. The intra-building port(s) of the equipment MUST NOT be metallically connected to interfaces that connect to the OSP or its wiring. These interfaces are designed for use as intra- building interfaces only (Type 2 or Type 4 ports as described in GR-1089- CORE, Issue 4) and require isolation from the exposed OSP cabling.
  • Page 6 WARNING Changes or modifications not expressly approved by Evertz Microsystems Ltd. could void the user’s authority to operate the equipment. Use of unshielded plugs or cables may cause radiation interference. Properly shielded...
  • Page 7 October 2020 Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof or for the rights of third parties, which may be effected in any way by the use thereof. Any representations in this document concerning performance of Evertz products are for informational use only and are not warranties of future performance, either expressed or implied.
  • Page 8 3406 Frame Manual 3406FR-HDBNC Fiber Optic SFP HD-BNC Frame This page left intentionally blank Page -ii Revision1.0...

  • Page 9: Table Of Contents

    3.2.4. Handling and Connecting Fibers ................7 FIBER INPUT AND OUTPUT CONNECTIONS ..............7 3.3.1. Electro Static Discharge (ESD) Precautions ............. 9 3.3.2. 3406FR-HDBNC SFP Module Variants ..............10 3.3.3. Installing an SFP Module ..................11 3.3.4. Removing an SFP Module ..................11 ELECTRICAL INPUT AND OUTPUT CONNECTIONS .............
  • Page 10 3406 Frame Manual 3406FR-HDBNC Fiber Optic SFP HD-BNC Frame SFP ........................... 18 5.4.1. SFP – 3406T-2-12G ....................19 5.4.2. SFP - 3406R-DA4R-12G ..................19 5.4.3. SFP – 3406R-2-12G ....................20 NOTIFY ..........................21 3406 SERIES CWDM PASSIVE OPTICAL MODULES ..............23 OVERVIEW ........................
  • Page 11 Figure 3-3: Front View of 3406FAN ......................5 Figure 3-4: Cooling Fan Installation and Removal .................. 6 Figure 3-5: Reproduction of Laser Certification and Identification Label ..........7 Figure 3-6: 3406FR-HDBNC Front View with Fiber Inputs and Outputs ..........8 Figure 3-7: Evertz SFP Modules ......................8 ®...
  • Page 12 3406 Frame Manual 3406FR-HDBNC Fiber Optic SFP HD-BNC Frame Page left intentionally blank Page -vi Revision1.0...

  • Page 13: Overview

    3406FR -HDBNC Fiber Optic SFP HD-BNC Frame OVERVIEW The Evertz 3406FR-HDBNC Fiber optic SFP HD-BNC is a high–capacity bulk optical conversion platform. With the ability to accommodate 16x Evertz 3406/3405 series SFPs, up to 32x optical–to–electrical or electrical–to–optical conversions may be performed in a single frame.

  • Page 14: Figure 1-2: 3406Fr-Hdbnc Block Diagram

    3406 Frame Manual 3406FR -HDBNC Fiber Optic SFP HD-BNC Frame Figure 1-2: 3406FR-HDBNC Block Diagram Page - 2 Revision1.0...

  • Page 15: Technical Specifications

    3406 Frame Manual 3406FR -HDBNC Fiber Optic SFP HD-BNC Frame TECHNICAL SPECIFICATIONS 3406FR-HDBNC FRAME Density: Up to 32x EO, OE, or a mixture of EO and OE in a 1RU unit,4x MSA- compliant SFP slots for additional SFP to SFP conversions Impedance: 75 Ω...

  • Page 16: Electrical Outputs

    < 0.3UI to 11.88Gb/s PHYSICAL Physical: SFP form–factor Dimensions: 1.8” H x 19” W x 8” D Module Capacity: 16x Evertz SFP modules, 4x MSA–compliant SFP modules Operating Temperature: 0–50°C (with 3406FAN installed) COMPLIANCE Laser Safety: Class 1 laser product, Complies with 24 CFR 1040.10 and 1040.11,...

  • Page 17: Installation

    3406FR -HDBNC Fiber Optic SFP HD-BNC Frame INSTALLATION The 3406FR-HDBNC frames require 1 rack unit (i.e. 1.75 inches (45 mm) of standard 19 inch (483 mm) wide rack space). To firmly fasten the frame to the equipment rack, make sure that all four mounting screws are securely tightened.

  • Page 18: Care And Handling Of Optical Fiber

    CARE AND HANDLING OF OPTICAL FIBER 3.2.1. Safety CLASS 1 LASER PRODUCT 3.2.2. Assembly Assembly or repair of the Evertz SFP modules is done only at Evertz facility and performed only by qualified ® Evertz technical personnel. Page - 6 Revision1.0...

  • Page 19: Labeling

    5 cm to avoid fiber-bending loss that will decrease the maximum attainable distance of the fiber cable. For further information about care and handling of fiber optic cable see the Evertz website. (http://www.evertz.com/resources/) FIBER INPUT AND OUTPUT CONNECTIONS These connections are made using standard LC fiber connector ends on single mode fiber optic cable.

  • Page 20: Figure 3-6: 3406Fr-Hdbnc Front View With Fiber Inputs And Outputs

    3406 Frame Manual 3406FR -HDBNC Fiber Optic SFP HD-BNC Frame Figure 3-5: 3406FR-HDBNC Front View with Fiber Inputs and Outputs Unpopulated SFP slots will remain inactive until the appropriate SFP is installed. Please ensure flat or ultra- flat polished fiber LC connectors are used for the SFPs.

  • Page 21: Electro Static Discharge (Esd) Precautions

    3406 Frame Manual 3406FR -HDBNC Fiber Optic SFP HD-BNC Frame 3.3.1. Electro Static Discharge (ESD) Precautions All semiconductor devices are sensitive to ESD. To prevent any damage or degradation on components of the product caused by ESD, observe these precautions when installing or removing modules from the frame. 1.

  • Page 22: 3406Fr-Hdbnc Sfp Module Variants

    12G/3G/HD/SD/ ASI dual 1310nm SFP optical transmitter, Reclocked 3406Txx/yy–2–12G 12G/3G/HD/SD/ ASI dual CWDM SFP optical transmitter, Reclocked 3406R–2–12G 12G/3G/HD/SD/ ASI dual SFP optical receiver, Reclocked 3406R–DA4R–12G 12G/3G/HD/SD/ ASI dual SFP optical receiver, Reclocked Figure 3-7: 3406FR-HDBNC SFP Module Variants Page - 10 Revision1.0...

  • Page 23: Installing An Sfp Module

    3406 Frame Manual 3406FR -HDBNC Fiber Optic SFP HD-BNC Frame 3.3.3. Installing an SFP Module Note: In most cases, SFP modules will come from the factory preinstalled into its  respective slot. The following steps outline the procedure for replacing or installing a new SFP module.

  • Page 24: Electrical Input And Output Connections

    ELECTRICAL INPUT AND OUTPUT CONNECTIONS 3.4.1. Rear Panel HD-BNC Connections The HD-BNC’s on the rear of the 3406FR-HDBNC are fixed and correspond to a particular SFP module. These HD-BNC connectors are agile and thus configured as inputs or outputs. A HD-BNC will become an electrical input if its corresponding SFP spigot is an optical transmitter (Electrical to Optical converter).

  • Page 25: Status And Leds

    3406 Frame Manual 3406FR -HDBNC Fiber Optic SFP HD-BNC Frame STATUS AND LEDS The 3406FC frame controller card is inserted through the front of the frame and is secured to the 3406FR frame with the one captive screws fastened on either side of the unit. Figure 4-1: Front of 3406FC STATUS LED The two LEDs under the “STATUS”...
  • Page 26 3406 Frame Manual 3406FR -HDBNC Fiber Optic SFP HD-BNC Frame Page left intentionally blank Page - 14 Revision1.0...

  • Page 27: Webeasy ® Configuration

    3406 SFPs using a standard web browser. The 3406FR-HDBNC web interface can be accessed by entering the IP address of the 3406FR-HDBNC into the address bar of an Internet web browser. When first visiting the 3406FR-HDBNC web interface, the user will be asked to enter a Login and Password.

  • Page 28: System

    3406 Frame Manual 3406FR -HDBNC Fiber Optic SFP HD-BNC Frame SYSTEM Figure 5-2: WebEasy - System ® Product Name: This field displays the name of the product. Alias Name: This field allows the user to set an alias for this device. Firmware Version: This field displays the firmware build current installed on the frame controller.

  • Page 29: Network Management

    3406 Frame Manual 3406FR -HDBNC Fiber Optic SFP HD-BNC Frame NETWORK MANAGEMENT Figure 5-3: WebEasy - Network Management ® Networking Control IP Address: This field allows the user to set the IP address of the control port. Control IP Netmask: This field allows the user to set the IP netmask of the control port. Control IP Gateway: This field allows the user to set the IP gateway of the control port.

  • Page 30: Sfp

    3406 Frame Manual 3406FR -HDBNC Fiber Optic SFP HD-BNC Frame Figure 5-5: WebEasy - SFP ® Information SFP: This control allows the user to select SFPs in port 1-20. Presence: This field displays if there is a working SFP present on this port. Connector: This field diplays if a fiber or copper SFP is connected Part Name: This field displays the part name of the SFP in this port.

  • Page 31: Sfp - 3406T-2-12G

    3406 Frame Manual 3406FR -HDBNC Fiber Optic SFP HD-BNC Frame 5.4.1. SFP – 3406T-2-12G Figure 5-6: WebEasy - SFP – 3406T-2-12G ® This SFP has both Ch A and Ch B available Channel Tag: This field allows the user to set a tag for each channel on the SFP. Squelch: Enable/disable squelch on this channel of the SFP.

  • Page 32: Sfp - 3406R-2-12G

    3406 Frame Manual 3406FR -HDBNC Fiber Optic SFP HD-BNC Frame 5.4.3. SFP – 3406R-2-12G Figure 5-8: WebEasy - SFP - 3406R-2-12G ® Channel Tag: This field allows the user to set a tag for this SFP. Optical Power: This field displays the optical power received by the SFP. Squelch: Enable/disable squelch on this channel of the SFP.

  • Page 33: Notify

    3406 Frame Manual 3406FR -HDBNC Fiber Optic SFP HD-BNC Frame NOTIFY Figure 5-9: WebEasy - Notify ® SFP Fault SFP: This control allows the user to select SFP located on ports 1-20. SFP Send Trap: This control will enable sending trap for the fault indicated on this row. SFP Fault Present: This indicator shows if there is a fault (red) or no fault (green).
  • Page 34 3406 Frame Manual 3406FR -HDBNC Fiber Optic SFP HD-BNC Frame This page left intentionally blank Page - 22 Revision1.0...

  • Page 35: Series Cwdm Passive Optical Modules

    In fiber optic transmission systems, it is often necessary to split or combine optical signals. The 3406CWDM series passive CWDM mux/demux modules provide high capacity optical mux and demux for use with the 3406FR-HDBNC frames. There are currently 8 modules in the passive optical module family.

  • Page 36: Installation

    3406 Frame Manual 3406FR -HDBNC Fiber Optic SFP HD-BNC Frame Features: • Bi-directional mux/demux of up to 18 wavelengths in the 1470nm to 1610nm spectrum (ITU-T G.694.2 compliant) • Passive design for any bit rate • Low insertion loss to conserve system power High optical isolation for low crosstalk •...
  • Page 37 Dual 18-channel demux, 1270-1610nm 2 X CB-MTP45CM-LCPC-18 Table 6-2: 3406CWDM Model and The Associated Required Fanout Cable  Note: For 9 channel breakout cable, use Evertz Part number: CB-MTP45CM-LCPC-18 For 18 channel breakout cable, use Evertz Part number: CB-MTP45CM-LCPC-9 Revision1.0 Page - 25...
  • Page 38 3406 Frame Manual 3406FR -HDBNC Fiber Optic SFP HD-BNC Frame End of document Page - 26 Revision1.0...
