Configuration

Network settings

Use the following commands to configure the unit with an IP address as part of an existing network.
Note The DHCP server still operates unless it is disabled.
Command
ETH 0 IPADDR XXX.XXX.XX.XXX
ETH 0 MASK XXX.XXX.XX.XXX
For example, enter the following commands:
ETH 0 IPADDR 192.168.10.254
ETH 0 MASK 255.255.255.0
Note When you set the mask to 255.255.255.0 value, it doesn't appear in the output of the CONFIG C
SHOW command, as it is a default value.
Use the following command to stop the DHCP server from serving addresses:
Command
DHCP 0 IPMIN X
For example, enter the command DHCP 0 IPMIN ! to stop the DHCP server from receiving DHCP
requests. The ! variable removes a value or sets it back to its default.
To retain the DHCP server, but on a different subnet, you must configure the following parameters:
Command
DHCP 0 IPMIN x.x.x.x
DHCP 0 IPRANGE
DHCP 0 GATEWAY x.x.x.x
DHCP 0 MASK x.x.x.x
DHCP 0 DNS
For more information on CLI commands, the the Digi TransPort User Guide on www.digi.com.
Digi Utility Communication Hub for TransPort® WR21 Installation Guide
Description
Sets the Eth 0 IP address
Sets the Eth 0 subnet mask
Description
Removes the minimum IP address that will be server via DHCP, disabling the
DHCP server
Description
Minimum IP address to assign, the start of the DHCP pool
The number of IP addresses in the DHCP pool
The IP gateway address the DHCP clients should use (normally this
router's LAN IP address)
The subnet mask DHCP clients should use
The DNS server DHCP clients should use
Command line interface (CLI)
