Logik L1HDVD10E Quick Start Manual

DVD Player With HDMI
Quick Start Guide
L1HDVD10E
Congratulations
on the purchase of your new Logik DVD Player.
Your new DVD Player incorporates the latest technology to enhance your
viewing experience. We would suggest that you allow about 20 mins for
initial setup.
Please follow this guide for a successful rst time installation.
1 1
Unpacking
Remove all packaging from the DVD player. Retain the packaging. If you
dispose of it please do so according to any local regulations.
Remote Control x 1
DVD Player x 1
Instruction Manual x 1 Quick Start Guide x 1
2 2
Operating Your Remote Control
1. Press and hold the battery release tab in the direction of arrow
2. Pull out the battery holder completely in the direction of arrow
3. Place a new CR2025 battery (not supplied) in the holder.
4. Push the holder back into the remote control.
3 3
Connections
STANDBY OSD MENU OPEN/CLOS
CLEAR
1 2 3
SUBTITLE
4 5 6
TITLE
7 8 9
PROG SEARCH To SCART output
0 10+
SETUP ZOOM ANGLE
PREV
F.REV F.FWD NEXT
STOP PAUSE/STEP VOLUME
MUTE REPEAT A-B RPT AUDIO
Stereo system
CR2025
2
1
1 .
2 .
Television
To SCART input
Method 2 Method 1
SCART cable
HDMI cable
Method 3
AUDIO cable
To audio inputs of the ampli er
4 4
Connecting to the Mains Socket
1. Plug in the mains plug into the mains socket after you have completed
all the connections.
2. Press the STANDBY / ON
button on the remote control to switch on
the DVD player.
3. Turn on the TV, select the video input connected to the DVD player.
5 5
Basic Playback
1. Press the OPEN / CLOSE button to open the disc tray, place a disc
with the label facing up.
2. Press the OPEN / CLOSE button again to close the disc tray.
3. If the disc does not start playing automatically, press the ENTER / PLAY
button.
4. Some discs may start playback with a menu. Use the
on the remote control to select menu options and press the ENTER /
PLAY
button to start, or press digits to select a menu options directly.
5. To eject the disc, press the OPEN / CLOSE
button.
If you have any di culties, please refer to the instruction
manual.
Well done,
your new DVD player is now ready to use.
You will nd that there are many exciting features available. To get to
know all these features, please take some time to read the instruction
manual provided with your DVD player.
buttons
(P.N.: 1-3010-A655-0002-R)
