Logik L7PDVD10E Quick Start Manual

7" Portable DVD Player
Quick Start Guide
L7PDVD10E
Congratulations
on the purchase of your new Logik
Portable DVD Player.
Your new Portable DVD Player incorporates the latest technology to
enhance your viewing experience. We would suggest that you allow
about 20 mins for initial setup.
Please follow this guide for a successful rst time installation.
1 1

Unpacking

Remove all packaging from the DVD player. Retain the packaging. If you
dispose of it please do so according to any local regulations.
DVD Player x 1 Remote Control x 1
Car Power Adapter x 1 Mains Adapter x 1
Instruction Manual x 1 Quick Start Guide x 1
2 2

Operating Your Remote Control

Remove the Insulating Strip from the Remote Control
Remove the insulating mylar strip from the battery
if the battery is being used for the rst time. It is
located at the bottom back side of the remote
control.
Battery Installation for the Remote Control
1. Press and hold the battery release
tab and pull out the battery
holder completely.
Install the batteries correctly by following the polarity (+ and -)
indications in the battery compartment.
3 3

Power Supply

Using the Mains Adapter
(for indoor use)
To Mains
Socket
Using the Car Power Adapter (for in-car use)
Earphone x 1
The 12V car power adapter allows the unit to be used with vehicles that have
a 12V electrical system.
To Cigarette
Lighter Socket
Car Power Adapter (included)
2. Remove the old battery, and place
a new battery in the holder.
Left Side of Unit
Mains Adapter (included) To DC IN 9V-12V Socket
Left Side of Unit
To DC IN 9V-12V Socket
4 4

Connections

Connecting a TV
If your TV has audio/video inputs, you can connect the unit to your TV using
a standard Audio/Video cable.
Left Side of Unit
White Red Yellow
To AUDIO /
VIDEO OUT Sockets
Audio / Video Cable (not included)
Do not connect the TV and the DVD player to the mains supply
until you have completed all the connections.
5 5

Basic Operation

1. Slide the CHARGE / STANDBY / ON switch on the left side of the unit to
the ON position.
2. Slide the open switch to open the disc door.
3. Hold the disc by its sides and carefully place onto the spindle with the
label side facing up. Gently push the disc down until you hear a "click".
4. Close the disc door. It takes a short while for your unit to load the disc.
After loading, the unit will automatically display the main menu of the DVD
or start playing the DVD.
5. If the unit does not automatically start playing the DVD, press the
button.
Well done,
your new DVD player is now ready to use.
You will nd that there are many exciting features available. To get to
know all these features, please take some time to read the instruction
manual provided with your DVD player.
TV
PLAY
(P.N.: 810-837395W040)
