- Page 1 Box 9430(‐w ) User Manual Hardware www.korenix.com 0.0.1 ...
-
Page 2: Acknowledgments
Copyright Notice Copyright© 2010 Korenix Technology Co., Ltd. All rights reserved. Reproduction without permission is prohibited. Information provided in this manual is intended to be accurate and reliable. However, the original manufacturer assumes no responsibility for its use, or for any infringements upon the rights of third parties that may result from its use. The material in this document is for product information only and is subject to change without notice. While reasonable efforts have been made in the preparation of this document to assure its accuracy, Korenix assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. Korenix reserves the right to make changes in the product design without notice to its users. Acknowledgments Korenix is a registered trademark of Korenix Technology Co., Ltd. All other trademarks or registered marks in the manual belong to their respective manufacturers. 2 Overview | Korenix ... -
Page 3: Table Of Contents
SD card slot ...................... 9 3‐3‐7 Digital IO ....................... 1 0 3‐4 Indicators ........................ 1 1 3‐4‐1 Power LED per unit .................... 1 1 3‐4‐2 Ethernet LED on the port .................. 1 1 3‐4‐3 System Memory .................... 1 2 Chapter 4 System Login ........................ 1 2 Chapter 5 Appendix ........................ 1 3 5‐1 Customer Service ...................... 1 3 Korenix | Overview ... -
Page 4: Chapter 1 Overview
Chapter 1 Overview The advantage of adopting Korenix JetBox series is ready‐to‐use. Korenix is devoted to improve the usability of embedded computer in industrial domain. Besides operating system, Korenix provides device drivers, protocol stacks, system utilities, supporting services and daemons to make system integration simple. Further, Korenix provides application development toolkits for users to build up their own applications easily. The stylish JetBox 9400 series is an industrial layer‐3 router with power‐over‐Ethernet technology and Linux computing. It is a gateway to connect different network groups (Ethernet, fieldbus, serial or IO control) in a complex networking architecture and manage peripherals at the front‐end site through its Linux programs or Java applications. It is reliable (network redundancy, system recovery) and robust (passive cooling, protected against the dusts and spills, shock & vibration resistance) to adopt in severe industrial vertical markets, such as transportation, substation, or hazardous environment. 4 Overview | Korenix ... -
Page 5: Chapter 2 Hardware Specification
Storage SD card slot x1 CF card slot x1 Ethernet 10/100 Base‐Tx RJ45 x5 Built‐in 15KV ESD protection of all signals USB Host USB v2.0 Host Port x3 DIO DIO x8 (configured by users, default: DI) Console 3‐pin header (RS232 interface) LED per Ethernet port Link/ Activity (Green on/ Green blinking) (on the port) LED per unit Power on/ off (Green on/ off) x1 Power Switch x1 Power input DC 12~48V Power Consumption 25W OS support Embedded Linux 2.6.20 Net Weight 900g Dimensions 160(H) x 112(W) x 56(D) mm Construction Rugged aluminum alloy chassis, IP31 protection Color Silver Mounting DIN rail Korenix | Hardware Specification ... - Page 6 Feature JetBox9430 ‐40℃ ~ 80℃, 5 to 95% RH Operating Temp. (JetBox9430‐w) Storage Temp. ‐40℃ ~ 80℃, 5 to 95% RH Regulation FCC class A, CE, UL EN55022 class A EN55024 EN61000‐3‐2, 3 EN61000‐4‐2, 3, 4, 5, 6, 8, 11 IEC60950 Shock IEC60068‐2‐27 (50g peak acceleration) Vibration IEC60068‐2‐6 (5g/ 10~150Hz/ operating) Greater than 200,000 hours@25℃ MTBF 6 Hardware Specification | Korenix ...
-
Page 7: Chapter 3 Hardware Feature
Chapter 3 Hardware Feature 31 Mechanical Outline JetBox9430 appearance JetBox9430 mechanical outline Korenix | Hardware Feature ... -
Page 8: Power Connectors
33 I/O Connectors 331 Ethernet (RJ45) Standard RJ‐45 jack sockets. 10/100 BaseT Signal Name P48V (only for PoE port) P48V (only for PoE port) N48V (only for PoE port) N48V (only for PoE port) 8 Hardware Feature | Korenix ... -
Page 9: Usb
DATA+ 4 GND 333 Console The JetBox provides one Console port 3‐pin connector for debug use. Console 334 Reset button This button is used to reset the CPU causing the system reboot or reset to the factory default. Press 3 seconds for system reboot. Press 7 seconds to reset the JetBox to the factory default. 335 CF card slot This socket is used for the type I/II CF Card and reserved for system extension. 336 SD card slot This socket is used for a SD Card and is for the users’ applications. There is a external blanket to cover the SD card slot. Korenix | Hardware Feature ... -
Page 10: Digital
337 Digital IO The JetBox supports 8 digital channels and users can configure them as digital outputs or digital inputs. Following is the connector pin assignments. (The default setting is digital input) Digital input Below figures show 2 ways to use digital input function. The digital input channels can support max. 5V. Dry connect for digital input Wet connect for digital input Digital Output Below figure shows how to use digital output function. The digital output channels can support max. 3.3V. 10 Hardware Feature | Korenix ... -
Page 11: Indicators
34 Indicators 341 Power LED per unit This LED indicator is used to indicate the power on / off status. Power on/off: Green on/ off 342 Ethernet LED on the port The LED indicators show their Active/Link status (Green on/ blinking) and Col/Fdx status (Yellow on/ blinking). Korenix | Hardware Feature ... -
Page 12: System Memory
SD Card User application files 32MB Flash CF Card Application Security Boot Loader System extension Setting 32MB Flash There is 32M Byte of Flash ROM for the Boot Loader program. 128MB DDR2 RAM The JetBox supports 128 MB of DDR2 SDRAM. The DDR2 SDRAM is arranged for Linux 2.6 Object Store and applications. Chapter 4 System Login Users can enter the JetBox Linux environment via the user name: root and no password is required. login : root password : (none) 12 System Login | Korenix ... -
Page 13: Chapter 5 Appendix
Chapter 5 Appendix 51 Customer Service Korenix Technology Co., Ltd. Business service: sales@korenixembedded.com, sales@korenix.com Customer service: koreCARE@korenix.com Web Site: http://www.korenixembedded.com, http://www.korenix.com Korenix | Appendix ...
