- Page 1 Sinewave Inverter with Transfer Switch 120V Model 1000W (SWXFR1210) 2000W (SWXFR1220) 3000W (SWXFR1230) 230V Model 1000W (SWXFR1210i) 2000W (SWXFR1220i) 3000W (SWXFR1230i) Owner’s Manual Preliminary Updated Version Rev: 3.2...
- Page 2 PLEASE KEEP THIS MANUAL FOR FUTURE REFERENCE Disclaimer While every precaution has been taken to ensure the accuracy of the contents of this guide, KISAE Technology assumes no responsibility for errors or omissions. Note as well that specifications and product functionality may change without notice.
-
Page 3: Table Of Contents
Table of Contents INTRODUCTION ....................4 PRODUCT DESCRIPTION ................. 5 INSTALLATION ....................5 UNIT OPERATION .................... 11 FEATURE SETTING ..................13 TROUBLESHOOTING ..................14 SPECIFICATIONS ..................... 18 WARRANTY ....................... 18 APPENDIX I ........................ 20 APPENDIX II ....................... 20 INTERCHANGEABLE TERMS The following interchangeable terms are used in this manual and in the inverter argot to mention the operating mode of an inverter with a built-in transfer switch. -
Page 4: Introduction
1. INTRODUCTION Thank you for purchasing the KISAE Sinewave Inverter with Transfer Switch unit. With our state of the art, easy-to-use design, this product will offer you reliable service by providing AC power and 5V USB power for your home, cabin, boat, RV, Caravan or Trailer using battery power. -
Page 5: Product Description
On/Off button AC Output strain relief 15A thermal breaker for the GFCI AC Input strain relief Socket & AC Output L2 (Port 2) Common (Input/Output) AC Select button Ground AC Output GFCI Socket AC Input port Model SWXFR1210 Page 5... - Page 6 AC Input strain relief receptacle AC Output GFCI Socket Common (Input/Output) AC Select button Ground AC Output receptacle AC Input port Model SWXFR1210i-EU, SWXFR1220i-EU, SWXFR1230i-EU DC Input Rear Panel DC Input Terminals opening Model SWXFR1210/1220/1210i/1220i DC Input Terminals opening Model SWXFR1230./1230i Page 6...
- Page 7 Preparing for Installation Typical Wiring block diagram of the Power Inverter: DC Disconnect DC Fuse or AC Output Switch Circuit Breaker Inverter with Ports & 12 V Battery Bank Transfer Switch USB Output Unit AC Input AC Input Branch Source Breaker 12V Battery Bank: ...
- Page 8 4/0 (0000) 2000W 300A SWXFR1220i * 2/0 (00) 3/0 (000) 4/0 (0000) 5 (recommended) SWXFR1210 1/0 (0) SWXFR1210i * 1000W 2/0 (00) 150A 1/0 (0) Notes: * The suffix "i" stands for International units (@ 230Vac, single-phase, 50Hz) with different outlets as per the specific country.
- Page 9 Use the mounting template below to mark the positions of the mounting screws. Drill the 4 mounting holes and place the Inverter in position and fasten the unit to the mounting surface. Important : Field wiring DC terminals tightening torque 12-13 Nm Chassis Grounding Connection: DANGER: The unit chassis has to be grounded properly.
- Page 10 Connect the AC Input ‘N’ (Neutral) wire between the unit AC Input Port and the AC source ‘N’ terminal. Connect the AC Input ground wire to the Common AC Ground connection on the unit. If a solid ground wire is used, the wire can be connected directly under the bolt head. If stranded, ring terminals must be used.
-
Page 11: Unit Operation
Install the 6-pin RJ12 cable in your desired location and connect the RJ12 cable to the unit and the other end of the cable to the Display Panel. See appendix II for more details. Test the Inverter Connection: Turn the DC disconnect switch ON to provide battery power to the unit. ... - Page 12 Status LED Display LED Display Function/Status Green Bypass Mode. Display shows battery voltage e.g. ’12.5’ Green (solid) in DC volts Battery/Inverter Mode. Inverter is running. e.g. ‘12.5’ Green Display shows battery voltage in DC volts Amber Battery/Inverter Mode. Inverter is running, (solid) Amber e.g.
-
Page 13: Feature Setting
AC Load on Inverter Although the Power Inverter can provide high surge power up to two times the rated (continuous) output power, some high surge loads like sump-pumps, heavy duty motors etc. may still trigger the inverter protection system even though the load falls within the power rating of the inverter. -
Page 14: Troubleshooting
Note: In PS0, PS1, and PS2 settings, the unit turns on automatically when getting shore power. Once having shore power, the unit cannot be turned off. To do so, you have to first disconnect the shore power (forcing Inverter mode) and then push the Power button. Same function as PS1 and the ‘Power’... - Page 15 (pass-through) battery is not connected at mode all. However, the unit Note: The unit has a small DC power supply to keep (SWXFR1210 continues supplying AC- its control electronics working even after /1220/1210i Output power in spite of disconnecting the battery. However, do NOT use the /1220i only) ②...
- Page 16 In the the following current ratings on the receptacles: 15A/ SWXFR1230 unit, that rating 20A for the SWXFR1210/1220 models respectively. can be exceeded in Battery On the SWXFR1230 and 230V models: for (Inverter) mode as well. maximum capacity use the AC-Output Port 1 which is out of the tripping influence of the unit thermal breaker.
- Page 17 “PS” setting differ- Get into the setting mode and set the “PS” Undefined value reserved for ent to PS0, PS1, manufacturing process only. parameter to any of the defined ones, so the unit PS2, or PS4 Someone there forgot to starts working and the undefined value will never change it to the PS1 default appear anymore.
-
Page 18: Specifications
The limited warranty program is the only one that applies to this unit, and it sets forth all the responsibilities of KISAE Technology. There is no other warranty, other than those described herein. Any implied warranty of merchantability of fitness for a particular purpose on this unit is limited in duration to the duration of this warranty. - Page 19 Any defective unit that is returned to the manufacturer within 30 days of the date of purchase will be replaced free of charge. If such a unit is returned more than 30 days but less than one year from the purchase date, the manufacturer will repair the unit or, at its option, replace it, free of charge.
- Page 20 APPENDIX I Setting Mode Flow: APPENDIX II Detachable Display Panel Cable: The display panel can be installed away from the unit, using the included 25’ RJ12 cable. You would need to remove the two screws indicated below. Even though the unit can operate with the cable plugged in whatever direction, we suggest plugging the end with the ferrite bead EMI/RFI filter into the main unit.
