Riden RD6024 Instructions Manual

Constant voltage and constant currentdc
Hide thumbs Also See for RD6024:

Advertisement

声明:本说明书著作权归杭州睿登科技有限公司所有,未经允许任何单位或个人不得用于商业用途。
恒压恒流数控电源使用说明
Constant Voltage and Constant CurrentDC
Power Supply Instruction
型号: RD6006/ RD6006-W/ RD6006P/ RD6006P-W /RD6024/ RD6024-W
Model: RD6024/R26024-W
修订时间:2022.3.7
Date: 2022.1.7
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RD6024 and is the answer not in the manual?

Questions and answers

Lens Makeke
March 4, 2025

Good Day. Where can i buy this in South Africa?

Summary of Contents for Riden RD6024

  • Page 1 声明:本说明书著作权归杭州睿登科技有限公司所有,未经允许任何单位或个人不得用于商业用途。 恒压恒流数控电源使用说明 Constant Voltage and Constant CurrentDC Power Supply Instruction 型号: RD6006/ RD6006-W/ RD6006P/ RD6006P-W /RD6024/ RD6024-W Model: RD6024/R26024-W 修订时间:2022.3.7 Date: 2022.1.7 - 1 -...
  • Page 2: Constant Voltage And Constant Current

    声明:本说明书著作权归杭州睿登科技有限公司所有,未经允许任何单位或个人不得用于商业用途。 Constant Voltage and Constant Current DC Power Supply Instruction Model: RD6024/RD6024-W Date: 2022.1.7 Dear users, thank you for purchasing the constant voltage constant current DC power supply produced by Hangzhou Ruideng Technology Co., Ltd. In order to let you know more about the full function of this product, get a better experience and avoid misuse.
  • Page 3: Table Of Contents

    声明:本说明书著作权归杭州睿登科技有限公司所有,未经允许任何单位或个人不得用于商业用途。 CONSTANT VOLTAGE AND CONSTANT CURRENT ................38 DC POWER SUPPLY INSTRUCTION ....................38 1.1 T ......................... 41 ECHNICAL ARAMETER 1.2 C .......................... 42 UNCTION 1.3 P ........................43 ANEL NSTRUCTION 1.3.1 Front Panel ........................43 1.3.2 Back Panel ........................44 1.4 O ......................
  • Page 4 声明:本说明书著作权归杭州睿登科技有限公司所有,未经允许任何单位或个人不得用于商业用途。 4.3.4 RS485 Multiple Devices Communication ................69 4.3.5 Firmware Update ......................70 4.3.6 Boot Logo Update ......................71 4.3.7 Version Update Detection ....................72 4.3.8 Language Setting ......................73 4.3.9 About ..........................73 APPENDIX ............................75 1: C ..............75 PPENDIX OMMON ATTERY...
  • Page 5: Technical Parameter

    声明:本说明书著作权归杭州睿登科技有限公司所有,未经允许任何单位或个人不得用于商业用途。 1.1 Technical Parameter Model RD6024 RD6024-W Input voltage range 6-70.00V Output voltage range 0-60.00V Output current range 0-24.00A Output power range 0-1440W Input voltage measurement resolution 0.01V Output voltage setting measurement resolution 0.01V Output current setting measurement resolution 0.01A Battery voltage measurement resolution 0.01V...
  • Page 6: Core Function

    · 2.4 inch HD color display · Dedicated terminal for battery charging · Firmware update, support more functions later · Brand new PC software · Support WiFi communication(RD6024-W) /USB communication · Support Android/ IOS APP · Support multiple display interfaces...
  • Page 7: Panel Instruction

    声明:本说明书著作权归杭州睿登科技有限公司所有,未经允许任何单位或个人不得用于商业用途。 1.3 Panel Instruction 1.3.1 Front Panel A: Power button B: SHIFT Second function button C: Quick storage button D: Current/Over current protection setting E: Voltage/Over voltage protection setting F: Micro USB port G: Power supply output negative terminal/ H: Battery charging positive terminal Battery charging negative terminal (Dedicated terminal for battery charging) I: Power supply output positive terminal...
  • Page 8: Back Panel

    声明:本说明书著作权归杭州睿登科技有限公司所有,未经允许任何单位或个人不得用于商业用途。 1.3.2 Back Panel P: Input fuse Q: Output fuse(only for under 10A short time usage) R: Power source input interface S: External temperature sensor interface T: CR1220 battery socket U: Communication module interface( wifi or RS485 board) V: Fan interface(cannot add or replace other fan) NOTE: Power source input interface must be connected to 6-70V constant DC power source.
  • Page 9: Operation Instruction

    声明:本说明书著作权归杭州睿登科技有限公司所有,未经允许任何单位或个人不得用于商业用途。 1.4 Operation Instruction After power-on, it will show boot image first, and then enters the main page. 1.4.1 Main Page AA: Actual output voltage value AB: Actual output current value AC: Output power AD: Current data group AE: Constant voltage Constant AF: Protection status indication current status AG: Battery charging indication...
  • Page 10 声明:本说明书著作权归杭州睿登科技有限公司所有,未经允许任何单位或个人不得用于商业用途。 Traditional Style Detail Style Curve Style At main page you can press button to change the display style between Traditional Style, Detail Style and Curve Style, the display style will not be saved automatically, you need to set default boot display at section 1.4.2.6 Main Page Style Setting.
  • Page 11: Operation Introduction

    1.4.2.1 Battery Charging Function Introduction The device in the instruction video may not be RD6024, but the operation way of them are similar. Battery charging operation video:...
  • Page 12 声明:本说明书著作权归杭州睿登科技有限公司所有,未经允许任何单位或个人不得用于商业用途。 1.4.2.2 Main Page Output Voltage and Current Setting Output voltage and current setting operation video: https://www.youtube.com/watch?v=KPnXiwCGSFg Press button to set the output current value, you can use encoder potentiometer to adjust the output value directly. And you will not set the value which exceeds the limit in this way, press button to move the cursor.
  • Page 13 声明:本说明书著作权归杭州睿登科技有限公司所有,未经允许任何单位或个人不得用于商业用途。 then press to confirm, it will show bottom left, you can press button and choose “X”, then press ENTER to cancel, after change the setting value it will show Press + keypad button 1-9 to quick call out the saved data (as shown above in figure 3) from the figure 2 corresponding data group.
  • Page 14 声明:本说明书著作权归杭州睿登科技有限公司所有,未经允许任何单位或个人不得用于商业用途。 https://www.youtube.com/watch?v=ml15mX4u5bE Press to enter the system setting menu, the icon in Red shows the menu being chosen, press to enter the sub-menu, the option in blue is the option being chosen, you can rotate the encoder potentiometer to change setting, and you can press button to select menu.
  • Page 15 声明:本说明书著作权归杭州睿登科技有限公司所有,未经允许任何单位或个人不得用于商业用途。 decrease the output current setting value. When used together with low power power source, it is recommended to set the value as the rated power of the power source*95%; unit is ℃ by default, it can be Temperature switched between ℃ and ℉(figure 6); Battery Charger Sub-menu(figure 7): CutOff Current is set to 100mA by default and it...
  • Page 16 声明:本说明书著作权归杭州睿登科技有限公司所有,未经允许任何单位或个人不得用于商业用途。 1.4.2.6 Main Page Display Style Setting Main interface display style setting operation video: https://drive.google.com/drive/folders/1gMkuCZr r_G-PlyHqO-i6fxdS-XRvuOIG?usp=sharing figure 9 You can press to enter the system setting menu, then press and it will be switched to display style menu(as shown in figure 10): you can press to enter the sub-menu.
  • Page 17 声明:本说明书著作权归杭州睿登科技有限公司所有,未经允许任何单位或个人不得用于商业用途。 press to confirm, and it will save the set value and set current range, if you set a value exceeds the limit, it will prompt like what shows in Figure 1. If you set the wrong value, you can press encoder potentiometer to cancel.
  • Page 18: Android App Instruction

    Android APP Instruction 2.1 Mobile Phone APP Installation Only RD6024-W supports WIFI connection. This App only supports Android 5.0 to Android 10.0 operating system, and there may be incompatibilities problems between APP and operating system, please install and test the software before buying the product.
  • Page 19: App Operation

    2.2.3.1 Network Distribution Connect Wi-Fi for the first time, please insert the WiFi board to the right position, then power on RD6024, you will see the blue LED blinks once. Set the communication interface to WIFI, restart RD6024, then place the RD6024 and the mobile phone close to the 2.4G router...
  • Page 20 声明:本说明书著作权归杭州睿登科技有限公司所有,未经允许任何单位或个人不得用于商业用途。 function). RD6024 will wait for the phone to connect as shown in Picture 16. Press “BA” (add device) and choose “RD power series”, it will show like Picture 17, then enter the WiFi password and confirm you are using 2.4G network as shown in Picture 18.
  • Page 21 MAC address function. 2.2.3.2 Proper Wi-Fi Connection When power on RD6024, it will connect Wi-Fi first, and then detect if it can be connected to APP, and it may not be connected successfully if the phone is under screen-lock status or the APP is running at the background.
  • Page 22 声明:本说明书著作权归杭州睿登科技有限公司所有,未经允许任何单位或个人不得用于商业用途。 document can be recorded. NOTE: 1. There are many kinds of Android phone, so the user interfaces maybe different on some brand phones or different scales of the same brand. 2. Application permission requirements, allow the necessary permissions when the APP is installed (allow background running, using Bluetooth, operation on the folder, reading the application list, etc.) and also set the permissions of the APP after installation: Allow background running, never shut down when lock screen, allow...
  • Page 23: Ios App Instruction

    声明:本说明书著作权归杭州睿登科技有限公司所有,未经允许任何单位或个人不得用于商业用途。 IOS APP Instruction 3.1 Mobile Phone APP Installation Wifi connection only supported for RD6024-W. 3.1.1 APP Download Apple APP only supports IOS10.0-14.3, iphone6 and above models, search for "RDPower" in the Apple store to download. If you must use the software function, please pre-install the test first.
  • Page 24: App Update

    声明:本说明书著作权归杭州睿登科技有限公司所有,未经允许任何单位或个人不得用于商业用途。 figure 21 figure 22 When the software is started for the first time, the system may apply for positioning (as shown in Picture 21), select "Allow when using APP", and apply for data when the software is running (as shown in Picture 22), select "Wireless LAN and cellular mobile network". Apple APP installation and connection process video: https://www.youtube.com/watch?v=Ryy9ko3gqYg After the installation is complete, the mobile APP icon is shown...
  • Page 25: App Operation

    3.2.3.1 Network Distribution Connect Wi-Fi for the first time, please insert the WiFi board to the right place, then power on RD6024, you will see the blue LED blinks once. Set the communication interface to WIFI, restart RD6024, then place the RD6024 and the mobile phone close to the 2.4G router (the mobile phone must also be under the...
  • Page 26 3.2.3.2 Proper Wi-Fi Connection When power on RD6024, it will connect Wi-Fi first, and then detect if it can be connected to APP, and it may not be connected successfully if the phone is under screen-lock status or the APP is running at the background.
  • Page 27 声明:本说明书著作权归杭州睿登科技有限公司所有,未经允许任何单位或个人不得用于商业用途。 IOS APP operation video: https://www.youtube.com/watch?v=Ryy9ko3gqYg Click “DH” / ”DI” text label and enter the value to set the output voltage/ output current, then click at the blank area to return, if you enter a value exceeds the limit, it cannot be applied. Click “DB”...
  • Page 28: Pc Software Installation And Operation Instruction

    CH341SER to install the driver, right click PC-management-device management-port, see if there is USB-SERIAL CH340(COMXX), if you see that, it means installation is successfully, then insert a Micro USB cable into RD6024 and wait for the computer to install the driver.
  • Page 29: Software Operation

    (figure 29), click "Initialize" and wait for about 5 -10 seconds, after the RD6024 displays the local IP address (as shown in figure 28), click "Next" and enter the WiFi name and password, then click "Network distribution", wait for about 20 seconds, the PC software prompts that the connection is successful, and then Click "Connect".
  • Page 30: Pc Software Operation Instruction

    声明:本说明书著作权归杭州睿登科技有限公司所有,未经允许任何单位或个人不得用于商业用途。 figure 27 figure 28 4.2.2 PC Software Operation Instruction Choose the right communication port, baud rate, slave address (default 001), click “CONNECT” to start communication. If the communication succeeds, the power supply button will be locked automatically, the buttons will automatically unlock after 3 seconds of accidental disconnection, and the “CONNECT”...
  • Page 31: Basic Functions

    声明:本说明书著作权归杭州睿登科技有限公司所有,未经允许任何单位或个人不得用于商业用途。 FA: Voltage-Current Curve FB: Battery information/ Data Group Quick Call Out FC: Calibration FD: RD/DPS series switch FE: Language FF: Software Update FG: About FH: Input voltage FI: Actual Output Voltage FJ: Actual Output Current FK: Actual Output Power FL: System Temperature(℃) FM: System Temperature(℉) FN: Constant Voltage/ Constant Current Status...
  • Page 32: Calibration

    Set the output voltage at 1V and calibrate the actual output voltage zero point to make the actual output voltage displayed on RD6024 close to the value on multimeter. You can set 30V and calibrate the proportional value of actual output voltage.
  • Page 33: Advanced Function

    4.3.4 RS485 Multiple Devices Communication Use USB to 485 module to connect the AB of the 485 module, if you have multiple device, connect their AB together. Each RD6024 needs a different device...
  • Page 34: Firmware Update

    Press and hold and power on RD6024, enter the boot mode, then connect it to computer, there will be “boot mode” in the mode information text box, then click “Firmware Update”, a firmware update prompt will pop up on the interface, and click “Now”...
  • Page 35: Boot Logo Update

    声明:本说明书著作权归杭州睿登科技有限公司所有,未经允许任何单位或个人不得用于商业用途。 During the firmware upgrade process, the interface is displayed as follows: 4.3.6 Boot Logo Update Boot logo setting video: https://drive.google.com/drive/folders/1J0iOyxZ8DSJaDQD2xgrlukBwJBELQBzf?usp= sharing Click “Start Logo Update”, a Logo upgrade prompt will pop up on the page, please select a picture. Some logo samples can be used in the installation package.
  • Page 36: Version Update Detection

    声明:本说明书著作权归杭州睿登科技有限公司所有,未经允许任何单位或个人不得用于商业用途。 Click “Picture Import” and RD6024 will reboot automatically. 4.3.7 Version Update Detection Click “FF”(“Software Update”), the software will automatically detect if there is a new version, if so, an update prompt will pop up on the interface.
  • Page 37: Language Setting

    声明:本说明书著作权归杭州睿登科技有限公司所有,未经允许任何单位或个人不得用于商业用途。 4.3.8 Language Setting Click “FE”(“Language”), a language setting prompt will pop up on the interface, you can choose Simplified Chinese, English, France and German. 4.3.9 About Click “FG”(“About”), you can check the version number, publish time and copyright Information...
  • Page 38 声明:本说明书著作权归杭州睿登科技有限公司所有,未经允许任何单位或个人不得用于商业用途。...
  • Page 39: Appendix

    声明:本说明书著作权归杭州睿登科技有限公司所有,未经允许任何单位或个人不得用于商业用途。 Appendix Appendix 1: Common Battery Voltage Comparison Table Final Final Nominal Battery Charge Discharge Voltage Application Characteristics Type Voltage Voltage LiCoMn Digital Device High capacity NiO2 Electric bike/ Large discharge LiFePO4 3.65 electric tool current, inexpensive Lead Car/ Inexpensive Storage 14.4 10.5...
  • Page 40: Appendix 2: Common Electric Car /Bike Battery Voltage Comparison Chart

    LiCoMnNiO2 LiFePO4 43.8 Lead Storage 31.5 43.2 Battery LiCoMnNiO2 29.4 LiFePO4 29.2 Lead Storage 28.8 Battery Note: if the final discharge voltage of the battery is higher than 60V, you cannot use RD6024 to charge, it will damage the device.
