EU-293 user's manual
STEP 3 – ASSIGN COMFORT TEMPERATURE OR ECONOMICAL TEMPERATURE TO PARTICULAR HOURS
An hour which is being edited is displayed on the controller screen. In
order to assign comfort temperature, press
economical temperature, press
moves on to editing the next hour.
The parameters of the weekly program are displayed at the bottom of the screen: hours to which comfort temperature
has been assigned are displayed whereas hours to which economical temperature has been assigned are not displayed.
Example:
The following screenshot presents daily settings of program no. 7 for Monday
24⁰⁰-01⁵⁹- economical temperature
02⁰⁰-06⁵⁹- comfort temperature
07⁰⁰-14⁵⁹- economical temperature
15⁰⁰-21⁵⁹- comfort temperature
22⁰⁰-00⁵⁹- economical temperature
NOTE
When the user finishes the editing process by pressing EXIT button, the controller returns to the main
screen view and this program is selected as the current program.
4.10.

PRE-SET COMFORT TEMPERATURE

Pre-set comfort temperature is used in weekly control mode and
day/night mode. Press MENU button until the comfort temperature
change screen opens up. Press
temperature.
Press MENU to confirm and move on to the next parameter or press
EXIT to confirm and return to the main screen view.
4.11.

PRE-SET ECONOMICAL TEMPERATURE

Pre-set economical temperature is used in weekly control mode and day/night mode. Press MENU button until the
economical temperature change screen opens up. Press
Press MENU to confirm and move on to the next parameter or press
EXIT to confirm and return to the main screen view.
. In order to select
. The controller automatically
or to set the desired
or
19
Edited hour
to set the desired temperature.
