U-Line H-9774 Manual

H-9774
STAINLESS STEEL
LEVER ACTION PUMP
TOOLS NEEDED
Pump Type
Flow
Maximum Fluid Temperature
Bung Adapter
Suction Tube Length
Inlet
Outlet
Wetted Parts
Maximum Viscosity
9
26
2
1
4
3
PAGE 1 OF 9
1-800-295-5510
uline.com
Flathead 5/16" Wrench
Screwdriver
SPECIFICATIONS
Lever Action – Self-Priming
9 GPM at 135 RPM (Adjustable: 6, 8, 10 or 12 oz./stroke)
170°F
1.5" and 2" NPT
34.5" Maximum
1" O.D.
0.75" O.D. Curved Spout
PTFE, PVDF and 304 Stainless Steel
2,000 cps
10
12
5
23
15
22
8 14
13
7
24
22
12
11
6
PARTS
20
21
20
12
12
19
18
25
17
16
Para Español, vea páginas 4-6.
Pour le français, consulter les pages 7-9.
# DESCRIPTION
1
Extend Tube
2 Bushing
3 Extend Tube Piston
4 Upper Extend Tube
5
Screw Nut
6 Base
7 Washer
8 Washer Block
9 Spout
10
Long Screw
11 Pump Body
12 Nut
13 Piston Cover
14
Piston
15
Cover
16 Packing Gland
17 Packing Nut
18 Piston Rod
19
Pivot Airs
20 Short Screw
21 Handle
22 Gasket
23 Spout Gasket
24
Spring Washer
25 Handle Cover
26 Barb Spout
0222 IH-9774
QTY.
1
1
1
1
1
1
1
1
1
1
1
4
1
1
1
1
1
1
1
2
1
2
1
1
1
1
