H-11956
1/2 HP SUBMERSIBLE
UTILITY PUMP – MANUAL
Carefully read, understand and follow all safety
instructions.
Read these warnings carefully. Know the application
and limitations of this pump. Failure to follow these
warnings could result in serious bodily injury and/or
property damage.
DANGER! Risk of electric shock. Disconnect
and lock out power supply before removing
old pump or installing or servicing this pump.
DANGER! Risk of electric shock. This pump
is supplied with a grounding conductor
and grounding type attachment plug. To
reduce the risk of electric shock, ensure that
it is connected only to a properly grounded,
grounding type receptacle. For added
safety, it is highly recommended to connect
this pump to a GFCI (Ground Fault Circuit
Interrupter) outlet.
WARNING! The installation of this pump must
be in accordance with the National Electric
Code (NEC), Uniform Plumbing Code (UPC),
International Plumbing Code (IPC) as well as all
applicable local codes and ordinances.
CAUTION! Do not install this pump in any
location classified as hazardous by the
National Electric Code, ANSI/NFPA70.
CAUTION! Do not use this pump to pump
flammable or explosive fluids such as gasoline,
kerosene, etc. Do not use this pump in
flammable or explosive environments. Use only
with liquids compatible with pump component
materials.
PAGE 1 OF 13
1-800-295-5510
uline.com
SAFETY
WARNING! Risk of electric shock. This pump has
not been investigated for use in swimming pool
or marine areas.
WARNING! Risk of electric shock. Do not use the
power cord to install or carry the pump. Always
use the handle. The cord may pull apart,
exposing bare wires which could cause a fire
or electric shock. Use the handle supplied with
the pump for installing and transporting the
pump.
WARNING! Do not run pump dry. This pump
relies on water for cooling. Running the pump
dry can cause the pump to overheat and the
possibility of burns to anyone that handles
the pump. Running the pump dry will void the
warranty.
WARNING! Do not use this pump for
potable/drinking water. Use only in applications
for which the pump is designed.
WARNING! Ensure that the electric outlet is
within the reach of the power supply cord. Do
not use an extension cord. Extension cords
that are too long or too light do not deliver
sufficient voltage to the pump motor. More
importantly, they present a safety hazard if the
insulation were to become damaged or the
connection end were to fall into the water.
CAUTION! This pump motor is equipped with
an automatic resetting thermal protector and
may restart unexpectedly.
Para Español, vea páginas 5-8.
Pour le français, consulter les pages 9-13.
0325 IH-11956
