Roroshetta SENSE User Instructions page 72

EN DESCRIPTION
External engine + Central ventilation (EC)
D
Sensor panel – sensors, buttons and indicators
1 Air quality sensor, intake.
2 Air quality sensor, exhaust.
3 Stove monitoring sensor.
4 Fan speed indicator: Lights up white when the fan is running.
Speed 1–3*/4, Ventilate mode.
In Ventilate mode: Constantly flashing all indicator lights.
5 Auto indicator: Lights up white when the cooker hood is
running automatically.
Off when fan speed is changed manually via push of a button.
6 Lamp button: Pressing the button switches the lighting on/
off.
Pressing the button turns off the automatic light control.
Hold down the button: Cycle between the presets defined in
the smartphone App.
7 Plus button: Increases the fan speed. Pressing the button
turns off the automatic ventilation.
Hold down the button: Activates Ventilate mode (closes the
valve and runs the fan in highest speed for 60 minutes).
72
1 2 3
10 9
8 Minus button: Reduces the fan speed alternatively
deactivates Ventilate mode. Pressing the button turns off the
automatic ventilation.
When deactivating Ventilate mode: The valve and the fan
speed jumps back to the level that was present before the
Ventilate mode.
9 OK button: Start bluetooth pairing.
In the event of a stove alarm: Dismiss the alarm.
10 OK indicator
See separate section.
4 5
8 7 6
403100, 2022-06-07
